OPERATING INSTRUCTIONS AND OWNER'S MANUAL
MR. HEATER
MH35LP
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS HEATER
CAN RESULT IN DEATH, SERIOUS BODILY INJURY AND PROPERTY LOSS OR DAMAGE FROM
HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE POISONING, AND/OR
ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE OR
SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS INSTRUCTION MANUALS, LABELS,
ETC., CONTACT THE MANUFACTURER.
WARNING:
FIRE, BURN, INHALATION AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES SUCH AS
BUILDING MATERIALS, PAPER OR CARDBOARD A SAFE DISTANCE AWAY FROM THE HEATER AS
RECOMMENDED BY THE INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY
CONTAIN VOLATILE OR AIRBORNE COMPUSTIBLES OR PRODUCTS SUCH AS GASOLINE, SOLVENTS,
PAINT THINNER, DUST PARTICLES OR UNKNOWN CHEMICALS.
WARNING: NOT FOR HOME OR RECREATIONAL VEHICLE USE
READ INSTRUCTIONS CAREFULLY: Read and
follow all instructions. Place instructions in a
safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
GAS-FIRED INFRA-RED
PORTABLE CONSTRUCTION HEATER
DO NOT LEAVE HEATER UNATTENDED OR IN OPERATION WHILE SLEEPING
CYLINDER NOT INCLUDED
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500
START SN#0253700 -
HEATSTAR
HS35LP
04/07 Revision B #18675
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mr. Heater HS35LP
Summary of Contents for Mr. Heater HS35LP
- Page 1 OPERATING INSTRUCTIONS AND OWNER’S MANUAL MR. HEATER READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to MH35LP assemble, light, adjust or operate the heater.
-
Page 2: Table Of Contents
SPECIFICATIONS MODEL NO..35LP 35LP GAS TYPE ... LP-Gas MAX. INLET PRESSURE..27.5” W.C. MIN. INLET PRESSURE ... 27.5” W.C. MANIFOLD PRESSURE ... 25.5” W.C. Do not exceed the gas supply pressures shown on rating plate for Model 35LP. The maximum inlet gas supply pressure and the minimum inlet gas supply pressure (for purposes of input adjustment) for LP-Gas are shown as follows: WARNING... -
Page 3: General Information
GENERAL INFORMATION Your portable gas-fired infra-red heater comes fully assembled and is tested at the factory for proper gas and input as stated on the nameplate. Each heater is equipped with a 100% safety shutoff, push button valve which will automatically stop the flow of gas in the event the heater fails to operate for any reason. -
Page 4: Operating Instructions
The connection of Model 35LP to an LP-Gas cylinder must be made in a well ventilated area using the regulator and hose assembly supplied with the appliance. DO NOT attempt to adjust this regulator. It has been preset at the factory to provide safe and proper operation of the appliance. -
Page 5: Maintenance Instructions
Shut-down instructions: To turn the heater OFF: Close the LP-Gas supply cylinder valve. Observe the burner until flame is extinguished. Listen for closure of the safety valve. IMPORTANT: DO NOT re-open the LP-Gas supply cylinder valve before the safety valve closes. MAINTENANCE INSTRUCTIONS This heater (including hose and regulator assembly) must be inspected before each use. -
Page 6: Replacement Parts List
Figure 4 Tip-Over Switch Arrangement NOTE: The purpose of the tip-over Switch is to stop the flow of gas when heater is accidentally knocked over. When and if the heater is knocked over, simply stand heater up. Enerco Group, Inc. | Gas-Fired Infra-Red Portable Construction Heater Magnetic Portion of Control Adaptor... - Page 7 Gas-Fired Infra-Red Portable Construction Heater • Model #35LP IF SERVICE IS REQUIRED PLEASE DO NOT RETURN THIS APPLIANCE TO YOUR STORE For information regarding service, please call our Toll-Free Number: 1-800-251-0001. Our office hours are 8:30 AM to 5:00 PM, Eastern Time Zone, Monday through Friday Please include the model number, date of purchase and description of problem in all communication.
-
Page 8: Warranty
Please include the model number, date of purchase, and description of problem in all communication. WARRANTY MR. HEATER warrants that Infra Red Heaters manufactured and sold will be free from defects in material and workmanship. Parts assemblies, controls, etc. furnished by Enerco Group, Inc. will carry a one (1) year warranty on the applicable warranties of the suppliers. -
Page 9: Garantie
251-0001 (800) détaillant Inc. Group, Enerco ÊTRE DOIVENT L'USINE AUPRÈS PIÈCES MORT. L'UTILISATION FABRICANT. HS35LP fonctionner modèles monter, PERSONNE HEATSTAR sûr endroit d'utilisation. D'UTILISATION INSTRUCTIONS l'utilisateur Manuel fonctionnant reserved rights Inc., d'Enerco déposées marques... - Page 10 d'utilisation instructions l'utilisateur 35LP Modèle • fonctionnant Manuel fonctionnant infrarouge avec communiquez d'achat date l'Est, heure à frais sans numéro à service informations À CHAUFFAGE APPAREIL infrarouge à portatif chauffage appareil à portatif chauffage Appareil Inc. Group, Enerco service. notre vous lorsque problème...
- Page 11 d'utilisation instructions THERMOCOUPLE PARENTHÈSE ASSEMBLY LOWER FRAME MAIN ROUES VERROUILLAGE BARRE POIGNÉE MODÈLE L'ESSIEU, TIGE MODÈLE ESSIEU, MODÈLE ROUE, MODÈLE PIEZO, MODÈLE ALLUMEUR, D'EAU D'ADMISSION PRESSION RÉGULATEUR BASCULE D'ADAPTATEUR/INTERRUPTEUR JOINT (PORT) BASCULE L'INTERRUPTEUR THERMOCOUPLE/18 ENSEMBLE BRÛLEUR POUR ORIFICE/MÈCHE LÉGER/D1096 BRÛLEUR/CADRE 8MPXI/4MP PORTATIF MANUEL,...
-
Page 12: Entretien
Voir approuvée été avoir doit remplacement soit chauffage l'appareil être doit coupé, s'il excessive, d'usure MH35LP/HS35LP modèle tuyau avant inspecté être doit régulation) compris chauffage appareil ENTRETIEN gaz. bonbonne valve nouveau à d'ouvrir avant ferme... - Page 13 été Celui-ci régulateur. régler avec fournis régulation l'ensemble tuyauterie bien endroit dans effectué être doit liquéfié à MH35LP/HS35LP modèle branchement Group, Enerco faites l'alimentation présence d'eau éventuelles. fixations Avant bavure tuyauterie local. appropriés, amples dans à régulation permanente, à...
- Page 14 Appareil Inc. pièces. liste Voir fabricant. avoir doit remplacement tuyauterie marche. l'appareil avant remplacé être doit excessive, d'usure signes montre MH35LP/HS35LP tuyau qualifiée. personne année utilisation chaque avant inspecté être doit l'ensemble tuyau compris chauffage CAN/CGA (Canada) D'INSTALLATION CODES Petroleum...
-
Page 15: Spécifications
(in. d'eau pouces D'ADMISSION...25.5 w.c.) (in. d'eau pouces MINIMALE...27.5 D'ADMISSION w.c.) (in. d'eau pouces MAXIMALE...27.5 D'ADMISSION liquéfié propane GAZ...Gaz HS35LP MH35LP SPÉCIFICATIONS Group, Enerco à Service Liste Entretien Allumage Tuyauterie capacité 35LP MODÈLE l'admission) d'admission plaque N'excédez PRESSION PRESSION... - Page 16 AVEC COMMUNIQUER COMME APPAREIL, PRÉSENT DEVRAIENT INSTRUCTIONS CARBONE EXPLOSIONS, CORPORELLES BLESSURES AVEC FOURNIES INSTRUCTIONS SANS FONCTIONNER CHAUFFAGE FONCTIONNANT PORTATIF CHAUFFAGE HS35LP fonctionner modèles monter, PERSONNE HEATSTAR sûr d'utilisation. D'UTILISATION INSTRUCTIONS SN#0253700 START • 44135 ÉTATS-UNIS OHIO, CLEVELAND, ST., 160TH DANS UTILISÉ...
