Tripp Lite SMART750RMXL2U Specification

Model #: SMART750RMXL2U
SmartPro .75kVA 600W Line Interactive Sine Wave UPS, Extended-run & SNMPWEBCARD options, 2U
Rack/Tower, LCD, USB, RS232, EPO, 120V
Description
Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and
telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects
brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Interactive LCD interface reports
UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover from
line to battery power occurs within milliseconds to maintain operation of connected equipment without interruption or reboot. 95% line-mode
efficiency offers reduced heat emissions and operating costs. Network management interfaces support communications via USB, RS-232 and
optional SNMPWEBCARD network interface. HID-compliant USB interface enables integration with built-in power management and auto shutdown
features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment load levels, self-test data and utility
power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable scheduled and real-time
remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for viewing in rackmount
or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable self-test.
Field-replaceable, hot-swappable battery modules.
Package Includes
SMART750RMXL2U UPS System
PowerAlert software with USB, Serial & EPO cabling
4 post installation kit
Owner's manual
Features
Tripp Lite SMART750RMXL2U line interactive 2U rack/tower UPS with 750VA / .75kVA / 600W capacity and extended runtime options
Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 147V
NEMA 5-15P input plug; 6 NEMA 5-15R output receptacles, Two independently switched output load banks
Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages
High 95% efficiency rating in line-power mode offers reduced power consumption and BTU emisssions
Internal batteries offer 20.7minutes at 50% load (300W) and 8.5 minutes at 100% load (600W)
Extended runtime is available with optional BP24V15RT2U (limit 1), BP24V28-2U (limit 1), BP24V70-3U (multi-pack compatible) and
BP24V36-2US (multi-pack compatible); Output is reduced to 450 watts maximum with external battery packs
External battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)
Hot-swappable, user-replaceable internal batteries and external battery packs can be replaced with no disruption to connected equipment
Front panel LCD monitoring screen with MODE and ENTER buttons reports operating mode with 5-bar battery charge graphic, plus 7
selectable screens of detailed UPS and site power information
LCD interface also supports a number of advanced user setup and operating preferences
Ships with 4 post rackmount installation hardware; Optional 2POSTRMKITWM enables 2 post rackmount/wallmount installation; Optional
Highlights
.75kVA / 750VA / 600W line interactive 2U rack/tower UPS, Sine wave output
120V output, Corrects brownouts and overvoltages from 83V to 147V
0.8 Power Factor, Interactive LCD interface
Extended runtime options up to 450W
4 post compatible mounting accessories
95% line-mode efficiency, 2 switched load banks
USB, RS232, EPO and slot for SNMPWEBCARD option
120V NEMA 5-15P input, 6 NEMA 5-15R outlets
