FEATURES
•
1/3-inch interline black
and white imager, EIA
format
•
380-line B/W imager
•
Sharp picture
•
0.5 lux light sensitivity
•
Sensitive to IR
illumination
4:01 PM Page 1
•
Discreet housings
•
Automatic electronic
shutter
•
Automatic gain control
•
12 VDC input via
included power supply
•
ADC522WP includes IR
illumination and is
weather resistant
ADC520 Series
BLACK AND WHITE SPECIALTY CAMERAS
The ADC520 Series cameras feature a black and
white imager that delivers a sharp picture at a
very economical cost.
The ADC520 Series offers cameras in housings
different than your typical standard camera.
The ADC520D features a 3.5-inch discreet
dome housing that is an attractive alternative
to a standard camera.
The ADC521B features a low silhouette tube
design that will fit in with most decors.
The ADC522WP is a weather resistant tube
design that meets IP57 for weather resistance.
The built in IR illumination LEDs allow this
camera to produce a picture with 0 lux ambient
light. The 12 IR LEDs provide coverage up to
10 meters (30 ft) to deliver a sharp picture while
producing no visible light.
The ADC523PIR is a camera mounted in a
standard motion detector shell. The camera
blends in to the background appearing as a
security system device. People are unaware that
there is video surveillance in the area.
www.americandynamics.net
