American Dynamics ADC521B Operating Instructions

B/w cctv camera

Download this manual

1. Please use a regulated 12VDC power adaptor to operate this unit. The power

tolerance of this unit is 12VDC

than 13.2VDC will damage this unit.

2. The video output (BNC connector) of this unit should only be connected to a

non-powered device. Please check the wiring of the video output before applying

power to this unit. If the power is applied through the video output cable, the unit

will be damaged.

Note:

All ADC520/ADC720 Series cameras ship with a 120VAC to 12VDC UL listed power supply with a

6-foot (1.8m) cord. 12VDC cameras will not line-lock and are not recommended for use in a matrix

switcher environment.

8200-0206-05 Rev. A

ADC521B

B/W CCTV CAMERA

OPERATING INSTRUCTIONS

CAUTION

10% (10.8VDC~13.2VDC); a power input of more

Page 1: Operating Instructions
All ADC520/ADC720 Series cameras ship with a 120VAC to 12VDC UL listed power supply with a 6-foot (1.8m) cord. 12VDC cameras will not line-lock and are not recommended for use in a matrix switcher environment. 8200-0206-05 Rev. A ADC521B B/W CCTV CAMERA OPERATING INSTRUCTIONS CAUTION...
Page 2 Thank you for choosing this high quality camera. Before connecting or operating this product, please read all of these instructions. Specifications Pick-up Element Number of Pixels Resolution Minimum Illumination S/N Ratio Electronic Shutter Load Impedance Standard Board Lens Lens Angle (Diagonal) Power Source Current Consumption Operating Temperature...
Page 3 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. 8200-0206-05 Rev. A American Dynamics Tyco Safety Products 6600 Congress Ave.
