Summary of Contents for KWorld SP800
-
Page 1: Table Of Contents
Contents V1.0 ONE Simple Explanation of Operation ..........02 1.1 Front Panel ..............02 1.2 Rear View ...............02 1.3 Remote Control Guide ...........03 TWO HOME Screen ...............04 2.1 Quick Access Panel (QAP) ..........04 2.2 Status Bar ..............04 2.3 Settings ................05 THREE Application ..............06 3.1 File Browser ..............06 3.2 Books... -
Page 2: One Simple Explanation Of Operation
Simple Explanation of Operation 1.1 Side view SATA HDD input 1.2 Rear panel USB2.0 interface input Power Card YPbPr Coaxial HDMI USB2.0 Optical input Reader Output Output Output input Output © 2012 KWorld... -
Page 3: Remote Control Guide
1.3 Remote Control Guide Function POWER button: Press the power button to turn on or turn off the SP800 Device POWER SETUP MUTE SETUP button:To access the Setup Menu,that you can directly to change system settings Mute button:Mute Number buttons:To input the number... -
Page 4: Two Home Screen
HOME Screen 2.1 Quick Access Panel (QAP) SP800 provides many application, some of them already showed on the Quick Access Panel (QAP) in HOME Screen; from left to right are “File Browser”, “Books”, “Pictures”, “Music”, “Movies”, “Internet Browser”,“All Programs” and “Setup”. -
Page 5: Settings
● SD card and device storage - Manage the SD card or other storage device. ● Language & keyboard - Manage language and IME type. ● Date & time - Set current date and time. ● About device – Show system information. SP800... -
Page 6: Three Application
It is the same with “Music” and “Pictures”. The “File Browser” option displays files in the storage device and network APK program can be installed here. ● Read LAN sharing files: Select “LAN” to find the files in the local area network. © 2012 KWorld... -
Page 7: Books
STOP: Exit play. ● SUBTITLE: Access the subtitles menu. ● 16:9: Access the display ratio menu. ● Repeat: Access the repeat play menu. ● Return: Exit and return to files browser. ● Home: Exit and return to the main interface. SP800... -
Page 8: Music
STOP: Exit play. SUBTITLE: Access the subtitles menu. Repeat: Access the repeat play menu. Return: Exit and return to file browser. Using mouse: ● Left click of the mouse is to confirm and right click is to return. © 2012 KWorld... -
Page 9: Pictures
● Left click of the mouse is to confirm and right click is to return. Pictures Toolbar ● “Previous”, “Play/Pause”, “Stop” and “Next” ● Zoom in or out ● Photo rotating ● Photo ratio: original size and full screen ● Settings: Time Interval, Repeat Mode, Shuffle Mode, Switch Effect SP800... -
Page 10: Internet Browser
Please press the menu button of the remote control or click the upper right m e n u b u t t o n o f t h e s c r e e n t o g e t advanced setting. © 2012 KWorld... -
Page 11: All Programs
● Clock – To function as a normal or alarm clock. ● Email – To send and receive emails through your regular email account. Remark: Some Android Market applications are designed for cell phone only and might not be compatible with screen resolution of this product. SP800... -
Page 12: Four Frequently Asked Questions
Answer:Check the system in following steps: ● Check if the power indicator light of the SP800 is on. If not, please check if the power adapter is properly connected. ● Check if there is signal output of images. If not, please check if the video output cable is properly connected and the correct video channel output (YPbPr or HDMI) is set up on the TV / PC monitor. - Page 13 Please check if the IP address, subnet mask, gateway and DNS of the device are set up correctly. ● Please select “automatically capture of IP address” at Network Settings and make sure that the DNS service of the router is enabled. ● Please check if the network is working normally. SP800...
- Page 14 (3)Please contact our local warranty department to arrange for maintenance if necessary. To replace devices or accessories, please select the original ones designated by the manufacturer. © 2012 KWorld...
- Page 15 KWorld Website: www.kworld-global.com Technical Support Thank you for reading this manual. If there is any further inquiry, please contact us at www.kworld-global.com The information contained in this documentation is for reference only. The text, images and charts of this documentation have been processed with intensive care and we have been dedicated to ensure the accuracy and completeness.
