Summary of Contents for KWorld M210

Page 1 Home Media Center Media Player User Manual...
Page 2: Table Of Contents
Contents V1.1 ONE Simple Explanation of Operation ........02 1.1 Front Pane ............02 1.2 Rear panel .............02 1.3 Remote Control .............03 TWO Menu Introduction ..............04 2.1 Start-up Screen ............04 2.2 Media Center Menu ..........04 THREE Setup Menu ..............05 3.1 Audio Settings ..............05 3.2 Video Settings ...............06...
Page 3: One Simple Explanation Of Operation
Simple Explanation of Operation 1.1 Front Panel 1.2 Rear panel © 2011 KWorld...
Page 4: Remote Control
1.3 Remote Control Function POWER button: Press the power button to turn on or turn off the M210 Device SETUP button:To access the S etup Menu, that you can directly to change system settings. EJECT button:To eject a DVD from the DVD Loader.
Page 5: Two Menu Introduction
Menu introduction 2.1 Start-up Screen Turn the power of the media player ON, and immediately will display the booting screen. 2.2 Media Center Menu Press to enter the Media Center Menu. © 2011 KWorld...
Page 6: Three Setup Menu
The HDMI(High Definition Multimedia Interface) is a compact audio/video connector interface for transmitting uncompressed digital streams. RAW data is the original digital stream of the audio and it will provide a better quality. LPCM is the default setting, and provides 2 channels audio output. M210...
Page 7: Video Settings
3.2.6 TV System:Setting TV system, change video output configure, HDMI AUTO/ NTSC/PAL/480P/576P/720P 60HZ/1080I 50HZ/1080I 60HZ/1080P 50HZ/1080P 60HZ 3.2.7 1080P 24HZ:1080P 24HZ on,if the movie is 25f/s,the unit will switch to this mode, after playback,system will come back to original settings. © 2011 KWorld...
Page 8: Changing Network Settings
3.3.1 Wired Lan Setup Select to set the Network Setting. Before using the Network functions, please check following items: 1. Connect the M210 to Network first 2. Enable NetBIOS of TCP/IP protocol on computer. 3. Shut down your PC’s firewall.
Page 9 Make sure your player is in the effective range of the W LAN Select a Profile Name Press to select. Press the ENTER button to the next step. Press Play button to direct connect. Press the RETURN button to go back. © 2011 KWorld...
Page 10 Get SSID Name System will search for an existing SSID (Service Set Identifier) auto. And select the access point you wish to access from the SSID list. M210...
Page 11 Peer to Peer (Ad Hoc) Peer to Peer mode, which is also called Ad Hoc mode or computer-to-computer mode, is used to connect wireless clients directly together, without the need for a wireless router or access point. © 2011 KWorld...
Page 12 It only supports the model as Realtek RTL8187B and Realtek RTL8191SU. Please consult with your sale agent when you wish to make the best use of this product. M210...
Page 13: Changing System Settings
8. R/RW Auto play: setting DVD ROM turn on or turn off automatically. 9. Angle mark: on/off; 10. HDD format: HDD format. Pls notice never power off during formatting. Otherwise hdd can’t be format. 11. Restore default: Recovery factory settings. © 2011 KWorld...
Page 14: Misc
5.5 Music background: Store music files and picture files into the same folder, therefore while the pictures are being shown the music background will be played. 5.6 Screen Saver: setting on/off for selection. 5.7 Movie preview: Before playback, user can preview movie in advance. On/off for selection. M210...
Page 15: Four File Browser Menu
Under this mode, all files that belong to this player will be listed. For selecting the file you wish to play, please press “OK”. 4.2 Music Select audio files with arrow keys of remote control, there is a bottom bar for display file info, press “ok” for playback. © 2011 KWorld...
Page 16 2. During slide show, user can switch to last or next picture by press previous and next keys. 3. Rotate picture by left/right key. 4. Zoom out or zoom in picture by press after zoom in, user can move picture freely M210...
Page 17 (Ethernet or WLAN). Before viewing the following, please make sure that you have read “Changing Network Settings” and made the right settings. When selecting NET in the local network there are two ways. One way is to browse through workgroup; the other way is to browse through ‘My Shortcuts’. © 2011 KWorld...
Page 18 2. Due to different network conditions, sometimes the workgroup might not be accessed or shown in the list. And then you need to use ‘My Shortcuts’ to browse shared files 3. Use the network stream the media file, some of 1080P files may not play smoothly. M210...
Page 19 4. After rename, select “ok” for confirm; if you want to cancel, press “return”. 5. Delete file, select files which need delete, press “ok” key from remote control for confirm; if not, press“return”. © 2011 KWorld...
Page 20: Five Ims
If you would like to add the weather forecast to favorite, press the “green” button of your control remote. If you would like to edit the area, please go to the main menu of the weather forecast, then select the region which you want to edit by pressing the “green” button of your control. M210...
Page 21: Six File Cope
Access file copy menu, select source device by up/down keys, press “right” key for next step. 2. Select destination device. Access destination list, press RED color key select target storage device by up/down key, press “right” key to next step. © 2011 KWorld...
Page 22 Then, press the “right” key to go to next step. 5. From the pop-up menu, select “copy” to start copy. 6. Process of copy. 7. After successful copy, there will appear the notice of “File Copy Completed!” on the screen. If failure, it will appear “File Copy failed!” M210...
Page 23: Seven System Upgrade
SEVEN System Upgrade How to get the new firmware To get the latest firmware, pls. visit kworld website: http://www.kworld-global.com 7.1 How to upgrade: 1. Download new FW named “install.img” into the root of the USB flash disk; 2. Plug in the USB flash disk into one of USB host ports.
Page 24 7.2 Press “OK” for upgrading, then it will appear on the screen same as the picture below 7.3 Updating procedure will take about 5 minutes, please keep the power “ON” during the process M210...
Page 25: Eight Bt And Samba
The default user name is' admin ', default password is '123'. If the login control is off, you will not need to enter a password and directly log in to your main page showed as below: © 2011 KWorld...
Page 26 At Home page, select “Account Management” into Account Management page. If click “Account Management” is not into this page, please press “ok” to Log in. Login password can be modified here. Please set your own password. Please input password twice and click “Enter” to confirm. M210...
Page 27 The BitTorrent client btpd is running in daemon (a process running in the background) Mode and you can manipulate the process via the Web server. Click BitTorrent Download on the home page of Neighbor Web, then you will enter the BitTorrent Download page. © 2011 KWorld...
Page 28 Click Stop to stop download. Click Delete to delete the selected torrent. Click Refresh to refresh the current status. Click the Down arrow to decrease the priority for the selected torrent. Click the Up arrow to increase the priority for the selected torrent. M210...
Page 29 With this method, you can access into any partitions on the hard disk of the player, you can manage, copy or store the data in the player on LAN. You can also access the player's Internal HD (samba) by the chapter1.3 Visit Neighbor. © 2011 KWorld...
Page 30: Nine Browse The Files Via Network
IP. click Simple Detail to switch between simple and advanced menu. And you can also input the IP address in Specific File Server IP first, then input Net User ID, Net Password, and press confirm or confirm and save to myshortcuts to access. M210...
Page 31 The system will automatically search the computer that has been installed with Transcode. If the computer is found, the player will display the computer name in the list for users’ choice. Then you can access to the files which you shared on the computer by My_Neighbors. © 2011 KWorld...
Page 32 DVD item in the browser and find the file to be played. If you set the R/RW auto-play as in Setup-System setting menu, then when the system detects the DVD-ROM, it will be playing back the disk automatically. M210...
Page 33: Ten About Upnp Network
UPnP Server through the network. This Media Player (Model M210) supports UPnP Client function, but it requires WIFI or Ethernet to connect to UPnP Server to make it work. Users will be able to play files on the UPnP Server through Network Streaming.
Page 34 To enable the server, go to Setting > Network > UPnP and add the content that you want to share. For viewing the content, please add your UPnP share as the source when choosing a media file for playback. M210...
Page 36 (2)Do not dismantle components of the product on your own .The warranty mark will be invalid automatically if you dismantle and repair the product on your own. (3)Please contact our local warranty department to arrange for maintenance if necessary. To replace devices or accessories, please select the original ones designated by the manufacturer. M210...
Page 37 KWorld Website: www.kworld-global.com Technical Support Thank you for reading this manual. If there is any further inquiry, please contact us at www.kworld-global.com The information contained in this documentation is for reference only. The text, images and charts of this documentation have been processed with intensive care and we have been dedicated to ensure the accuracy and completeness.
Page 38 FAX: +886-2-8221-6856 http://www.kworld-global.com © 2011 KWorld Computer Co., Ltd. All rights reserved. All KWorld trademarks and logos are registered trademark of KWorld Computer Co., Ltd. All other trademarks and logos presented in this material are the property of their respective owner.
