KWorld M101 User Manual

Hide thumbs Also See for M101:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Manual
Table of Content
1-1. Features-------------------------------------------------------------------------------2
1-2. Specification-------------------------------------------------------------------------3
1-3. Package Contents-------------------------------------------------------------------------- 3
1-4. Location of Controls(Remote)----------------------------------------------------------- 4
1-5. Connection Chart -------------------------------------------------------------------------- 5
2-1. Setting Up Your KWorld Media Player M101 --------------------------------------- 6
2-2. System Settings---------------------------------------------------------------------------- 7
2-3. Using Your Media Player M101--------------------------------------------------------12
2-4. ArcSoft Media Converter ----------------------------------------------------------------18
2-5. How to update firmware file? ----------------------------------------------------------18
3. Where is there No sound? --------------------------------------------------------------- 21
stick? ----------------------------------------------------------------------------21
encoding? ------------------------------------------------------------------------22

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M101 and is the answer not in the manual?

Questions and answers

Related Manuals for KWorld M101

Summary of Contents for KWorld M101

  • Page 1: Table Of Contents

    6. Why can’t Media Player M101 recognize memory cards or USB memory stick? ----------------------------------------------------------------------------21 7. How do I create subtitle files in SMI, SSA, SRT, ASS format with ANSI encoding? ------------------------------------------------------------------------22 8. Why M101 Media player doesn’t respond when playing some media file? ---22...

  • Page 2: Introduction

    1. Introduction Congratulation! You have purchased a KWorld Media Player M101 and you can enjoy digital entertainment on the big screen in the living room. We will guide you through all of the feature installation and operation. This manual will help you use the many exciting and useful features to make your viewing experience more enjoyable than ever before.

  • Page 3: Specification

    1-2. Specifications TV System PAL/NTSC HDD Partition FAT32,NTFS Max output Resolution VGA:1024*768 ; YPbPr:720P Card reader * 1 IR Receiver * 1 System I/O USB Host * 1 (USB2.0) Power Jack * 1 YPbPr output RCA * 3 VGA output D-sub 15 * 1 AV output S-Video output DIN4 * 1 CVBS output RCA * 1...

  • Page 4: Location Of Controls(Remote)

    1-4. Remote Control Guide Key Function Mute: Enable/Disable Mute function. Power: Stand by/Switch on. Video: Enter Movie page. Music: Enter Music page. Photo: Enter Photo page. Switch between 16:9 and 4:3 Play/Pause Stop Rewind Fast Forward Previous one Next one Increase Volume Decrease Volume VGA: Switch to VGA output mode...

  • Page 5: Connection Chart

    1-5.Connection Chart Note: You do not have to connect all of the output cables such as VGA, YPbPr, AV, S-video. Please connect the cables according to your need. (Please note the package does not supply VGA & S-video cables.)

  • Page 6: Operation

    2. Operation 2-1. Setting Up Your KWorld Media Player M101 1. Please connect your KWorld Media Player M101 with the TV set via AV cables. 2. Please connect the device with its power adaptor and turn it on. Please set...

  • Page 7: System Settings

    4. Please select “Setup” and press “OK” to enter the Setup page. 2-2. System Settings Once you have entered the System Setup page, you will see the options below: Language: Please use the Left/Right key on the Remote to select the preferred language, then press “OK”...
  • Page 8 Slideshow Interval (3sec, 5sec, 15sec, 1min, 15min, 1hr): Please use the Left/Right key on the Remote to select the preferred time interval for your slideshow, then press “OK” to confirm. Slideshow Mode (Bottom to Top, Top to Bottom, Left to Right, Right to Left, Door close, Door open, Horizontal cross, Vertical cross, Random, Fading): Please use the Left/Right key on the Remote to select the preferred mode, then press “OK”...
  • Page 9 Music Play Mode: You may set the Music Play Mode as “Repeat one” or “Repeat All”. Please use the Left/Right key on the Remote to select, then press “OK” to confirm. Video Play Mode: You may set the Video Play Mode as “Repeat one” or “Repeat All”.
  • Page 10 Display Ratio: Set the aspect ratio for your TV according to its screen ratio. Please use the Left/Right key on the Remote to set the right ratio, then press “OK” to confirm. TV Settings (NTSC interlace, NTSC progressive, PAL interlace, PAL progressive, NTSC composite, PAL composite, HD(YPbPr), VGA): Please use the Left/Right key on the Remote to select the right TV setting, then press “OK”...
  • Page 11 Auto Play: You may enable or disable the auto play function. Please use the Left/Right key on the Remote to set your preference, then press “OK” to confirm. Default Settings: To restore the original factory settings simply select, then press “OK” to confirm.

  • Page 12: Using Your Media Player M101

    2-3. Using Your Media Player M101 The Main Menu is the entrance to all media such as Video, Music, Photo, and Text Files. In any page, user can enjoy the corresponding multimedia functions in full display by pressing the Video, Music, or Photo keys on the Remote.
  • Page 13 For Video Playback: Please use the “UP/Down” keys on the Remote to select the video file and press OK to playback. Or, use the “Exit” key to return to the previous page and enter the file listing. In full screen mode, please press the “OSD” key on the Remote to pop-up the Video Control Bar.
  • Page 14 Note on the Subtitle Function: A. Subtitle Format: Only supports ANSI encoding format. Please refer to FAQ-7 on how to make a subtitle file with ANSI encoding format. B. When naming the subtitle file, it should correspond with Video file name. For example, if the Video file name is “A.avi”, then the Subtitle file name must be “A.srt”...
  • Page 15 3. Photo: Please select the Photo icon on the Main Menu and press the OK key to enter Photo listing, and enter the photo play page. Or you can simply press the Photo key on the Remote to enter playback Photo directly. For Photo Playback: Press the “Up/Down/Left/Right”...
  • Page 16 Text: Please select the Text icon on the Main Menu and press the OK key to enter Text file listing. For Viewing Text Files: Please press the “Up/Down” keys to select text file and press OK to confirm to enter full screen mode. Please press the “Up/Down” keys on the Remote to scroll up and down the text file.
  • Page 17 5. Files: On Main Menu, please select the File icon and press the “OK” key to enter File Listing page. Please press the Up/Down keys on the remote to browse the files and press the “Right” arrow key to select one, and then a check mark will appear on the right of the selected file;...

  • Page 18: Arcsoft Media Converter

    1. Please download the firmware file for KWorld wedsite. 2. Please unzip the firmware to USB Thumb Drive or Memory Cards and plug it to Media Player M101. Select the “USB” or “SD” icon and then press “OK“ to enter Main Menu.
  • Page 19 3. Please select “File” and press “OK” to enter file browser. 4. Use Up/Down/Left/Right keys to select the firmware file, and then press “OK” to update firmware. It will pop-up a dialog box. Please use Left/Right keys to select “TICK”, and then press “OK” to upgrade firmware.
  • Page 20 5. Please don’t do anything when it is upgrading firmware. Once it finished, it will reboot automatically.

  • Page 21: Faq

    3. If your answer is no, please press the VGA/YPbPr/AV-S keys on the Remote to switch to the correct AV output mode. Q2: How do I restore factory settings on my Media Player M101? A2: Please press the Menu key on the remote to enter the setup page and select the Default Settings option then press the OK key to return the device to its default settings.

  • Page 22: How Do I Create Subtitle Files In Smi, Ssa, Srt, Ass Format With Ansi

    Q7: How do I create subtitle files in SMI, SSA, SRT, ASS format with ANSI encoding? A7: Since Media Player M101 only supports subtitle files in ANSI encoding format, please follow the steps below: Please open the subtitle file with Notepad (a program that comes with your Windows Operating System), click on the Files Menu and select the “Save As”...
