- Page 1 MICROWA VE OVEN KOR-860AM OPERATING INSTRUCTION Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 3: Earthing Instructions
EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed. -
Page 4: Specifications
SPECIFICATIONS POWER SUPPLY 220V AC 60Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION 1350 W MICROWAVE OUTPUT POWER 900 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 495 X 294 X 390 mm CAVITY DIMENSIONS (W X H X D) 320 X 225 X 330 mm NET WEIGHT APPROX. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 1. -
Page 6: Features Diagram
FEATURES DIAGRAM 11 Door latch-When the door is closed 66 Door release button-Pushing this it will automatically shut off. If the button stops oven operation and door is opened while the oven is opens the door. operating, the magnetron will 77 Glass cooking tray-Made of special automatically shut off. - Page 7 FEATURES DIAGRAM (continued) DEF TIMER LOCK 1. BREAD 2. SOUP Auto 3. BAKED POTATO Cook 4. FRESH VEGETABLE 5. FROZEN VEGETABLE One Touch Cook Auto Defrost Meat Dish Warmer Frozen Pizza Poultry Beverage Fish Pasta Kitchen Clock Power Defrost Timer 1hour 10min 1min...
-
Page 8: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 220V 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 9: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever goes off, the display shows “ :0” when the power comes back on. 1. -
Page 10: Weight Defrosting
WEIGHT DEFROSTING Auto Defrost lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. The g indicator light and "500" is displayed. MEAT The display will show what you touched. 2. -
Page 11: Cooking In One Stage
COOKING IN ONE STAGE 1. Touch POWER pad. The M/W indicator lights. (Select the desired power level.) The display will show what you touched. POWER This example shows power level 5. NOTE: If steps 1and 2 are omitted, the oven will cook at full power. 2. -
Page 12: Kitchen Timer Mode
KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking.However delay cooking can not be programmed for defrost. Timer operates without microwave energy. HOW TO USE AS A MINUTE TIMER 1. -
Page 13: Easy Cook
EASY COOK EASY COOK allows you to reheat for 30 seconds at 100% (full power) by simply touching the EASY COOK pad. By repeatedly touching the EASY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. -
Page 14: Auto Cook
ONE TOUCH COOKING (Continued) When you touch DISH WARMER pad once, 1. Touch DISH WARMER pad DISH “350” is displayed. once for 350g or twice for WARMER After 1.5 seconds, the display is changed into 450g. cooking time and the oven starts cooking. * DISH WARMER * •... -
Page 15: Less, More
2. Touch START pad. When you touch START pad, the display is START changed into cooking time and the oven starts cooking. LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE. (except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 second. -
Page 16: Cooking Utensils
COOKING UTENSILS Only use utensils that are suitable for use in microwave ovens. Microwave energy is produced by high frequency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy. Listed below are the suggested cooking utensils for this microwave oven and when to use them. -
Page 17: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3. Check that the cooking time is set. 4.
