- Page 1 KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 3 MICROWA VE OVEN KOR-861G6 OPERATING INSTRUCTIONS Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 1 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 3: Important Safety Instructions
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 2 IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances, basic safety precautions should be followed, including the following: WARNING-To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1. -
Page 4: Federal Communications Commission Radio Frequency Interference Statement(U.s.a. Only)
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 3 FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT(U.S.A. ONLY) WARNING: This equipment generates and uses ISM frequency energy and if not installed and used properly, that is in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception. -
Page 5: Installation
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 4 INSTALLATION 1. Examine the oven after unpacking. Check for damage such as a misaligned door, broken door or dent in the cavity. If any damage is visible, DO NOT INSTALL, and notify your dealer immediately. -
Page 6: Specifications
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 5 SPECIFICATIONS POWER SUPPLY 120V AC 60 Hz SINGLE PHASE WITH GROUNDING POWER CONSUMPTION 1350 W MICROWAVE OUTPUT POWER 900 W FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 495 X 294 X 388 mm (19.5 X 11.6 X 15.3 in.) CAVITY DIMENSIONS (W X H X D) 320 X 228 X 338 mm (12.6 x 9.0 x 13.3 in) -
Page 7: Trim Kit Installation Guide
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 6 TRIM KIT INSTALLATION GUIDE 1. Turn a set upside down. Adhere three urethane foams(1,2) and tighten four screws(4) through the holes of four feet(3) to base plate. FRONT... - Page 8 KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 7 2. Remove three screws(1) on cabinet back. 3. Install the trim kit(2) and mounting brackets(3). 4. Tighten three screws(1) through the holes of mounting brackets(3) 5. Install the oven in the wooden box and fix the trim kit with six screws.
-
Page 9: Features Diagram
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 8 FEATURES DIAGRAM 1. Door latch-When the door is closed it will 6. Door release button-Pushing this button automatically shut off. If the door is opened stops oven operation and opens the door. - Page 10 KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 9 FEATURES DIAGRAM (continued) 8 8 : 8 8 M/W DEF TIMER LOCK lb 1. BREAD POPCORN 2. SOUP 3. BAKED POTATO MORE FROZEN 4. FRESH VEGETABLE PIZZA 5. FROZEN VEGETABLE LESS AUTO...
-
Page 11: Operation Procedure
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 10 OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a standard 3-pronged 15 Amp, 120V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. -
Page 12: Controls
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 11 CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “:0” and a tone will sound. If the AC power ever goes off, the display shows “ : 0” when the power comes back on. -
Page 13: Weight Defrosting
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 12 WEIGHT DEFROSTING AUTO DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting time. Follow the steps below for easy defrosting. 1. Touch MEAT pad. The lb indicator light and “ 1.0 ” is displayed. -
Page 14: Cooking In One Stage
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 13 COOKING IN ONE STAGE 1. Touch POWER pad. The M/W indicator lights. POWER (Select the desired power level.) The display will show what you touched. Note : If steps 1 is omitted, the oven will cook at full power. -
Page 15: Kitchen Timer Mode
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 14 KITCHEN TIMER MODE Timer operates as a minute timer, can be set to delay cooking and used to set a holding time after cooking. However delay cooking can not be programmed for defrost. Timer operates without microwave energy. -
Page 16: Speedy Cook
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 15 SPEEDY COOK SPEEDY COOK allows you to reheat for 30 seconds at full power by simply touching the SPEEDY COOK pad. By repeatedly touching the SPEEDY COOK pad, you can also extend reheating time to 5 minutes by 30 second increments. -
Page 17: Auto Cook
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 16 ONE TOUCH COOKING (continued) 1. Touch DINNER PLATE pad once When you touch DINNER PLATE pad once, “ 12 ” DINNER for 12 oz of dinner plate or twice for is displayed. -
Page 18: Less, More
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 17 LESS, MORE To alter one touch cooking or cooking time whilst oven is in operation, use LESS or MORE.(except for defrosting) Press LESS/MORE to decrease/increase the one touch cooking time in multiples of 10 seconds. -
Page 19: Utensil Test
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 18 Dishes that do not absorb microwave energy are best for microwave cooking. Lock on the label to verify that particular cups, glasses, plates are indeed suitable, especially paper goods. If you are not sure, try this utensil test to check. -
Page 20: Defrosting Frozen Foods Chart
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 19 DEFROSTING FROZEN FOODS CHART Item and Weight Defrosting Time Standing Time Special Techniques BEEF Break apart and remove thawed Mineed beef 10-12 min. 5-7 min. portions with fork. 454g (1 lb.) Stew Meat Separate and rearrange once. -
Page 21: Cooking Chart
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 20 COOKING CHART MEAT ITEM POWER LEVEL COOKING TIME PER 500g Beef Standing/rolled Rib - Rare P-80 9-11 min. - Medium P-80 10-12 min. - well done P-80 12-14 min. Ground Beef(to brown for casserole) P-HI 5-7 min. -
Page 22: Reheating Chart
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 21 VEGETABLE ITEM POWER LEVEL PREPARATION QUANTITY COOKING TIME STANDING TIME asparagus, fresh P-HI 11/2-in.pieces 500g(1 lb.) 7-9 min. 3 min. asparagus, frozen P-HI Whole spears 280g(10 oz. pkg) 7-9 min. 3 min. - Page 23 KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 22 ITEM QUANTITY POWER LEVEL COOKING TIME SPECIAL INSTRUCTION 2 pieces P-HI 3-5 min. Arrange, on paper tower lined Fried chicken 4 pieces P-HI 4-6 min. paper plate, covered with paper 6 pieces P-HI 5-7 min.
-
Page 24: Care Of Your Microwave Oven
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 23 CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. -
Page 25: Use Your Microwave Oven Safely
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 24 USE YOUR MICROWAVE OVEN SAFELY GENERAL USE Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. -
Page 26: Before You Call For Service
KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 25 BEFORE YOU CALL FOR SERVICE Refer to the following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : 1. Check that the power cord is securely plugged in. - Page 27 KOR-861G6(¿ ) 02.5.20 1:23 PM ˘ ` 26 QUESTIONS AND ANSWERS (continued) * Q : Why this standing time recommended after the cooking operation has been completed? A : Standing time is very important. With microwave cooking, the heat is in the food, not in the oven. Many foods build up enough internal heat to allow the cooking process to continue, even after the food is removed from the oven.
