Page 1: Documentation Updates
53-1002363-03 ® 26 August 2011 Network Advisor Documentation Updates Supporting Network Advisor 11.1.0...
Page 2: Document History
Copyright © 2010 Brocade Communications Systems, Inc. All Rights Reserved. Brocade, the B-wing symbol, BigIron, DCFM, DCX, Fabric OS, FastIron, IronView, NetIron, SAN Health, ServerIron, TurboIron, and Wingspan are registered trademarks, and Brocade Assurance, Brocade NET Health, Brocade One, Extraordinary Networks, MyBrocade, and VCS are trademarks of Brocade Communications Systems, Inc., in the United States and/or in other countries.
Page 3: Table Of Contents
Contents About This Document In this chapter ......... . . vii How this document is organized .
Page 4 Appendix E Database Fields In this appendix ......... . 15 Database tables and fields .
Page 5 N2F_PORT_MAP_INFO....... . 177 DEVICE_NODE_INFO ....... . .178 DEVICE_PORT_INFO.
Page 6 Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 7: About This Document
About This Document In this chapter • How this document is organized ........vii •...
Page 8 viii Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 9: Brocade Network Advisor Installation Guide
Chapter Brocade Network Advisor Installation Guide In this chapter The updates in this chapter are for the Brocade Network Advisor Installation Guide, part number: 53-1002320-01, published May 2010. • Operating system requirements ........1 Operating system requirements In Table 5, “Server operating system requirements,”...
Page 10 Operating system requirements Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 11: In This Chapter
Chapter Brocade Network Advisor Migration Guide In this chapter The updates in this chapter are for the Brocade Network Advisor Migration Guide, part number: 53-1002321-01, published May 2011. • Operating system requirements ........3 •...
Page 12 Network Advisor migration Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 13: In This Chapter
Chapter Brocade Network Advisor SAN User Manual In this chapter The updates in this chapter are for the Brocade Network Advisor SAN User Manual, part number: 53-1002167-01, published May 2011. • Chapter 1, Getting Started ........6 •...
Page 14: Chapter 1, Getting Started
Chapter 1, Getting Started Chapter 1, Getting Started In the section “User interface components,” on page 2, replace Figure 1 with the following: FIGURE 1 Main window Chapter 4, Application Configuration In the section “Configuring an internal FTP server,” on page 124 change step 4 as follows: 4.
Page 15: Chapter 8, Third-Party Tools
Chapter 8, Third-party tools Chapter 8, Third-party tools In the section “Launching Web Tools,” on page 200, change Fabro OS to Fabric OS. In the section “Launching Web Tools,” on page 200, change the second Note as follows: NOTE When you close the Management application client, any Web Tools instance launched from the clients closes as well.
Page 16 Chapter 10, SAN Device Configuration In the section “Restoring a configuration from the repository,” on page 256, replace Figure 94 with the following: FIGURE 94 Switch Configuration Repository In the section “Viewing configuration file content,” on page 257, replace Figure 95 with the following: FIGURE 95 Configuration file content...
Page 17: Chapter 13, Host Management
Chapter 13, Host Management Chapter 13, Host Management In the section “Adapter software,” on page 316, replace Figure 107 with the following: FIGURE 107 Adapter Software dialog box, Driver tab In the section “Deleting a boot image from the repository,” on page 318, change the title as follows: Deleting a driver file from the repository Chapter 18, SAN Encryption configuration In the section “Adding target disk LUNs for encryption,”...
Page 18: Chapter 19, Zoning
Chapter 19, Zoning Chapter 19, Zoning In the section “Zone database size,” on page 573, change the supported maximum zone database size to 2 MB. Chapter 26, Troubleshooting In the section “Configuring IP ping,” on page 748, change the second notes as follows: NOTE IP Perf is not supported on the Fabric OS 8 Gbps Extension Switch or Blade.
Page 19: Chapter 31, Technical Support
Chapter 31, Technical Support In the section “Generating a historical performance graph,” on page 780, add the following note to step 3 b: NOTE Devices with 10GE ports must have the rmon MIB enabled on the switch. For more information about the rmon collection command, refer to the Fabric OS Converged Enhanced Ethernet Command Reference.
Page 20 Appendix E, Database Fields Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 21: Virtual Connect Enterprise Manager Guide
Chapter Virtual Connect Enterprise Manager Guide In this chapter The updates in this chapter are for the Virtual Connect Enterprise Manager Guide, part number: 53-1002308-01, published May 2011. • VCEM integration support ........13 VCEM integration support In the section “VCEM integration support,”...
Page 22 VCEM integration support Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 23: In This Appendix
Appendix Database Fields In this appendix Tables • Advanced Call Home ..........17 •...
Page 24 In this appendix • Threshold ........... . 100 •...
Page 25: Database Tables And Fields
Database tables and fields • ROLE_PRIVILEGE_INFO ......... 195 •...
Page 26: Capability
Database tables and fields TABLE 3 ACH_EVENT_FILTER_MAP Field Definition Format Size FILTER_ID * ID of the event filter. EVENT_ID * Event ID which needs to be associated with the filter. TABLE 4 ACH_EVENT Field Definition Format Size ID * REASON_CODE Reason code of the event.
Page 27 Database tables and fields TABLE 8 CARD_CAPABILITY Field Definition Format Size CARD_ID * DB ID of the card. CAPABILITY_ * Name of the capability detected on the card. varchar ENABLED 1 = the capability is enabled on the card. Default value is 0. TABLE 9 VIRTUAL_SWITCH_CAPABILITY Field...
Page 28: Client_View
Database tables and fields TABLE 10 CARD (Continued) Field Definition Format Size FCIP_CIRCUIT_CAPABLE The blade is capable of creating FCIP Circuits. smallint 1 = true. 0 = false. Default value is 0. FCIP_LICENSED FCIP Advanced Extension Licensing is available. smallint 1 = available.
Page 29: Reports
Database tables and fields TABLE 12 USER_ (Continued) Field Definition Format Size NOTIFICATION_ENABLED Flag for e-mail notification. smallint Default value is 0. FULL_NAME User''s Full Name. varchar PHONE_NUMBER User''s Phone number. varchar INVALID_LOGIN_COUNT This is a counter filed to identify the number of invalid smallint login attempts.
Page 30: Client_View
Database tables and fields TABLE 15 CLIENT_VIEW_COLUMN (Continued) Field Definition Format Size ENTITY_CATEGORY Either "fabric" or "product (switch or device)" or "port"; or varchar combination of these 3 basic categories. Default value is 0. COLUMN_INDEX 0 = Predefined column. small int 1 = First user-defined column.
Page 31: Collector
Database tables and fields TABLE 17 FABRIC (Continued) Field Definition Format Size MANAGEMENT_STATE Bit map to indicate various management indications for smallint the fabric. TRACK_CHANGES 1 = changes (member switches, ISL and devices) in the smallint fabric are tracked. STATS_COLLECTION 1 = statistics collection is enabled on the fabric.
Page 32 Database tables and fields TABLE 20 COLLECTOR Field Definition Format Size NAME * Name of the collector registered with the collection varchar framework. CLASS_NAME Java class name which serves as the collector. varchar DESCRIPTION Collector description, usually not used. varchar TABLE 21 FABRIC Field...
Page 33 Database tables and fields TABLE 22 COLLECTOR_END_TIMESTAMP Field Definition Format Size COLLECTOR_SOURCE * Internal key for switches and fabrics for which varchar collection is undertaken. COLLECTOR_NAME * Collection name, Java class used to collect specific varchar fabric or switch information. TIMESTAMP_ When the last successful collection is done.
Page 34: Config
Database tables and fields TABLE 27 SECURITY_POLICY (Continued) Field Definition Format Size POLICY_TYPE* Type of the Policy. The possible values are IKE or IPSec smallint ENCRYPTION_ALGORITHM Encryption Algorithm for the policy.The following are varchar the possible Encryption: NONE,DES,3DES,AES-128,AES-256,AES-CM-128 or AES-CM-256. AUTHENTICATION_ALGORI Authentication Algorithm for the policy: varchar...
Page 35 Database tables and fields TABLE 29 FIRMWARE_FILE_DETAIL (Continued) Field Definition Format Size FIRMWARE_LOCATION Firmware file location in the Management applciation varchar 1024 repository. RELEASE_NOTES_ Release notes file location in theManagement varchar 1024 LOCATION applciation repository. FIRMWARE_REPOSITORY_ Repository type to identify the FTP server: smallint TYPE 0 = internal FTP.
Page 36: Connected End Devices
Database tables and fields TABLE 33 SWITCH_CONFIG (Continued) Field Definition Format Size BACKUP_DATE_TIME The date/time stamp at which the configuration has timestamp been uploaded. CONFIG_DATA The actual switch configuration data. text CEE_CONFIG_DATA Switch configuration data for CEE text KEEP_COPY The column value (1) helps to preserve the smallint configuration even after the expiration of its age.
Page 37: Device
Database tables and fields Device TABLE 37 DEVICE_PORT Field Definition Format Size NODE_ID DB ID of the device node to which this port belongs. DOMAIN_ID Domain ID of the switch to which this device port is attached. Device port WWN. char SWITCH_PORT_WWN WWN of the switch port to which this device port is...
Page 38 Database tables and fields TABLE 38 FICON_DEVICE_PORT Field Definition Format Size DEVICE_PORT_ID* Value for the device port to which these FICON properties are applied. TYPE_NUMBER varchar MODEL_NUMBER Ficon device model number, such as S18. varchar MANUFACTURER Manufacturer of the device, typically IBM. varchar MANUFACTURER_PLANT Plant number where the device is manufactured.
Page 39 Database tables and fields TABLE 39 DEVICE_NODE (Continued) Field Definition Format Size 1 = the device node is actually an AG connected to a smallint switch in the fabric. Default value is 0. PREVIOUS_MISSING_STAT Default value is 0. smallint TABLE 40 DEVICE_ENCLOSURE_MEMBER Field Definition...
Page 40 Database tables and fields TABLE 41 DEVICE_ENCLOSURE (Continued) (Continued) Field Definition Format Size TRACK_CHANGES Flag to enable/disable tracking. smallint Default value is 0. LAST_UPDATE_TIME Last time at which the host information was updated. timestamp LAST_UPDATE_MODULE Module which updated the host information. smallint TRUSTED Flag to mark the enclosure trusted.
Page 41: Ee- Monitor
Database tables and fields TABLE 42 FABRIC (Continued) Field Definition Format Size AD_ENVIRONMENT 1 = there are user-defined ADs in this fabric. smallint MANAGED 1 = it is an actively "monitored" fabric; otherwise, it is smallint an "unmonitored" fabric. MANAGEMENT_STATE Bit map to indicate various management indications smallint for the fabric.
Page 42 Database tables and fields TABLE 47 EE_MONITOR_STATS (Continued) Field Definition Format Size CREATION_TIME The polling time. timestamp ACTIVE_STATE State of collection smallint 0 = failed 1 = success Transmit (TX) value in bytes. double precision Receive (RX) value in bytes. double precision CRCERRORS...
Page 43: Event/Fm
Database tables and fields TABLE 50 EE_MONITOR (Continued) Field Definition Format Size DEST_PORT_ID References the ID in DEVICE_PORT table and this is a target for EE monitor. NAME Name of the End_End Monitor. varchar ERROR CODE Error code returned from the switch, when enabling End-End monitor is attempted on the switch.
Page 44 Database tables and fields TABLE 55 MESSAGE_RECIPIENT Field Definition Format Size DESCRIPTION Description about recipient. varchar IP_ADDRESS IP Address of the recipient. varchar PORT Port number of the recipient. RECIPIENT_TYPE_ID Recipient Type (Syslog or SNMP). ENABLED If forwarding to destination is enabled. smallint SOURCE_ADDRESS_ADD If source address is added as another varbind in trap.
Page 45 Database tables and fields TABLE 57 SNMP_CREDENTIALS (Continued) Field Definition Format Size WRITE_COMMUNITY_ The SNMP Write-Only Community String is like a varchar STRING password. It is sent along with each SNMP Set-Request and allows (or denies) access to device. The default value is "private".
Page 46 Database tables and fields TABLE 58 SYSLOG_EVENT (Continued) Field Definition Format Size EVENT_NUMBER Sequence number of the event. EVENT_COUNT Number of occurrences of the event. AUDIT Audit file of the syslog message. varchar FIRST_OCCURENCE_ First occurrence switch time. timestamp SWITCH_TIME LAST_OCCURENCE_ Last occurrence switch time.
Page 47 Database tables and fields TABLE 59 EVENT (Continued) Field Definition Format Size EVENT_COUNT Number of occurrences of the event.. Default value is 1. RESOLVED Resolution status of the event. smallint Default value is 0. ACKED_TIME Time at which the event is acknowledged. Timestamp FIRST_OCCURRENCE_HOST First occurrence host time;...
Page 48 Database tables and fields TABLE 61 EVENT_NOTIFICATION (Continued) Field Definition Format Size USER_NAME User name for authentication. varchar PASSWORD Password for authentication. varchar NOTIFICATION_INTERVAL Time interval between successive event notifications. NOTIFICATION_UNIT Time interval Unit: smallint 0 = Seconds 1 = Minutes 2 = Hours Default value is 0.
Page 49: Fabric
Database tables and fields TABLE 62 EVENT_RULE (Continued) Field Definition Format Size SEVERITY_LEVEL Event severity level. Default value is 4. SOURCE_NAME Name of the source. varchar 1024 DESCRIPTION_CONTAINS Description pattern about the rule. varchar LAST_MODIFIED_TIME Rules last edited time. timestamp smallint SELECTED_TIME_UNIT Timestamp unit of the selected rule:...
Page 50 Database tables and fields TABLE 64 SAN (Continued) Field Definition Format Size STATS_COLLECTION 1 = statistics collection is enabled; otherwise, 0. smallint Default value is 0. CREATION_TIME time at which this record was created. timestamp Default value is ’now()’. LAST_UPDATE_TIME time when this was last updated.
Page 51 Database tables and fields TABLE 65 FABRIC (Continued) Field Definition Format Size LAST_UPDATE_TIME Time when fabric was last updated. timestamp Default value is ’now()’. ACTIVE_ZONESET_NAME Name of the zone configuration which is effective / varchar active in that fabric. USER_DEFINED_VALUE_1 User-defined custom value.
Page 52: Fc Port Stats
Database tables and fields FC Port Stats TABLE 68 FC_PORT_STATS Field Definition Format Size SWITCH_ID References the ID in CORE_SWITCH table. PORT_ID References the ID in SWITCH_PORT table. Transmission (TX) value in bytes. double precision. Receive (RX) value in bytes. double precision.
Page 53 Database tables and fields TABLE 69 FC_PORT_STATS_30MIN (Continued) Field Definition Format Size double precision. TX_UTILIZATION double precision. RX_UTILIZATION double precision. CREATION_TIME timestamp ACTIVE_STATE smallint LINKFAILURES double precision. TXLINKRESETS double precision. RXLINKRESETS double precision. SYNCLOSSES double precision. SIGNALLOSSES double precision. SEQUENCEERRORS double precision.
Page 54 Database tables and fields TABLE 70 FC_PORT_STATS_2HOUR (Continued) Field Definition Format Size LINKFAILURES double precision. TXLINKRESETS double precision. RXLINKRESETS double precision. SYNCLOSSES double precision. SIGNALLOSSES double precision. SEQUENCEERRORS double precision. INVALIDTRANSMISSIONS double precision. CRCERRORS double precision. DATA_GAPS_IN5MIN smallint DATA_GAPS_IN30MIN smallint TABLE 71 FC_PORT_STATS_1DAY Field...
Page 55 Database tables and fields TABLE 71 FC_PORT_STATS_1DAY (Continued) Field Definition Format Size SIGNALLOSSES double precision. SEQUENCEERRORS double precision. INVALIDTRANSMISSIONS double precision. CRCERRORS double precision. DATA_GAPS_IN5MIN smallint DATA_GAPS_IN30MIN smallint DATA_GAPS_IN2HOUR smallint Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 56: Fcip
Database tables and fields FCIP TABLE 72 FCIP_TUNNEL Field Definition Format Size ETHERNET_PORT_ID GigE Port ID on which the tunnel is created. TUNNEL_ID Tunnel ID for that GigE Port. smallint VLAN_TAG VLAN Tag on the tunnel (if present). SOURCE_IP Source IP on which the tunnel is created. char DEST_IP Destination IP on the other end of tunnel.
Page 57: Fcip Tunnel Stats
Database tables and fields TABLE 75 FCIP_TUNNEL_DETAILS (Continued) Field Definition Format Size FICON_TIN_TIR_ Whether Ficon_Tin_Tir_Emulation is enabled on that smallint EMULATION_ENABLED tunnel. FICON_DEVICE_LEVEL_ Whether Device_Level_Ack_Emulation is enabled on smallint ACK_EMULATION_ENABLED that tunnel. FICON_TAPE_WRITE_MAX_ The value for this on the tunnel. PIPE FICON_TAPE_READ_MAX_ The value for this on the tunnel.
Page 58 Database tables and fields TABLE 76 FCIP_TUNNEL_STATS (Continued) Field Definition Format Size ACTIVE_STATE State of collection: smallint 0 = failed 1 = success RTT_BY_TO Counter of retransmit packet by timeout. double precision RTT_BY_DUP_ACK Counter of retransmit packet by duplicate Ack. double precision DUP_ACK Counter of duplicate Ack...
Page 59 Database tables and fields TABLE 78 FCIP_TUNNEL_STATS_2HOUR (Continued) Field Definition Format Size CREATION_TIME timestamp double precision double precision TX_UTILIZATION double precision RX_UTILIZATION double precision DROPPED_PACKETS double precision COMPRESSION double precision LATENCY double precision LINK_RETRANSMITS double precision ACTIVE_STATE smallint RTT_BY_TO Counter of retransmit packet by timeout. double precision RTT_BY_DUP_ACK Counter of retransmit packet by duplicate Ack.
Page 60 Database tables and fields TABLE 79 FCIP_TUNNEL_STATS_1DAY (Continued) Field Definition Format Size TCP_OOO Counter of TCP out of order double precision SLOW_START SlowStart status from stage 1 to 8 double precision Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 61: Gige Port Stats
Database tables and fields GigE Port Stats TABLE 80 FCIP_TUNNEL Field Definition Format Size TUNNEL_ID Tunnel ID for that GigE Port. smallint VLAN_TAG VLAN Tag on the tunnel (if present). Default value is -1. SOURCE_IP Source IP on which the tunnel is created. char DEST_IP Destination IP on the other end of tunnel.
Page 62 Database tables and fields TABLE 80 FCIP_TUNNEL (Continued) Field Definition Format Size FICON_TAPE_WRITE_TIMER The Value for FICON_TAPE_WRITE_TIMER on the tunnel. Default value is -1. FICON_TAPE_MAX_WRITE_ The Value for FICON_TAPE_MAX_WRITE_CHAIN on CHAIN the tunnel. Default value is -1. FICON_OXID_BASE The Value for FICON_OXID_BASE on the tunnel. Default value is -1.
Page 63 Database tables and fields TABLE 80 FCIP_TUNNEL (Continued) Field Definition Format Size TPERF_ENABLED Is Tperf enabled. Default: 0, Values: 0|1. smallint Default value is 0. AUTH_KEY This is the preshared-key to be used during IKE varchar authentication. CONNECTED_COUNT Active connections count. smallint Default value is 1.
Page 64 Database tables and fields TABLE 82 GIGE_PORT_STATS_30MIN (Continued) Field Definition Format Size double precision double precision TX_UTILIZATION double precision RX_UTILIZATION double precision DROPPED_PACKETS double precision COMPRESSION double precision LATENCY double precision BANDWIDTH double precision TABLE 83 GIGE_PORT_STATS_2HOUR Field Definition Format Size SWITCH_ID PORT_ID...
Page 65 Database tables and fields TABLE 84 GIGE_PORT_STATS_1DAY (Continued) Field Definition Format Size LATENCY double precision BANDWIDTH double precision TABLE 87 Field Definition Format Size FABRIC_ID Fabric DB ID. SOURCE_DOMAIN_ID Source domain ID. SOURCE_PORT_NUMBER Source port number. smallint DEST_DOMAIN_ID Destination domain ID. DEST_PORT_NUMBER Destination port number.
Page 66: License
Database tables and fields TABLE 88 FABRIC (Continued) Field Definition Format Size MANAGED 1 = it is an actively "monitored" fabric; otherwise, it is smallint an "unmonitored" fabric. MANAGEMENT_STATE Bit map to indicate various management indications smallint for the fabric. TRACK_CHANGES 1 = changes (member switches, ISL and devices) in smallint...
Page 67 Database tables and fields TABLE 92 LICENSED_FEATURE Field Definition Format Size NAME License feature name, a short text description. varchar DESCRIPTION Optional detailed description about the license varchar feature. TABLE 93 SWITCH_LICENSE Field Definition Format Size CORE_SWITCH_ID Refers to the entry in the CORE_SWITCH table. LICENSE_KEY Stores the license key obtained from the switch.
Page 68 Database tables and fields TABLE 94 CORE_SWITCH (Continued) Field Definition Format Size LAST_UPDATE_TIME 1 = the Management application server is registered timestamp with the switch to receive Syslog. Default is ’now()’. SYSLOG_REGISTERED 1 = Syslog is enabled for this switch. smallint Default value is 0.
Page 69: Encryption Device
Database tables and fields Encryption Device TABLE 95 KEY VAULT Field Definition Format Size IP_ADDRESS The IP Address (IPv4, IPv6, or hostname) of the key varchar vault. PORT_NUMBER The TCP port number for the key vault. PUBLIC_CERTIFICATE The key vault’s public key certificate. Switches use varchar 4096 this to establish a secure connection to the key vault.
Page 70 Database tables and fields TABLE 96 CRYPTO_SWITCH (Continued) Field Definition Format Size CP_CERTIFICATE The public key certificate, in PEM format, of the varchar 4096 switch’s Control Processor module. This certificate is exchanged with other switches to establish secure communication between switches in an Encryption Group.
Page 71 Database tables and fields TABLE 97 ENCRYPTION GROUP (Continued) Field Definition Format Size SYSTEM_CARD_REQUIRED Boolean value that indicates whether a System Card smallint (smart card) must be inserted in the Encryption Engine to enable the engine after power-up. This feature is not yet supported. ACTIVE_MASTER_KEY_STAT The operational status of the "master key"...
Page 72 Database tables and fields TABLE 98 ENCRYPTION_TAPE_POOL (Continued) Field Definition Format Size ENCRYPTION_GROUP_ID Foreign key reference to the ENCRYPTION_GROUP record that describes which Encryption Group this tape pool belongs to. TAPE_POOL_NAME User-supplied name or number for the tape pool. This varchar is the same name or number specified in the tape backup application.
Page 73 Database tables and fields TABLE 100 ENCRYPTION_GROUP_MEMBER (Continued) Field Definition Format Size MEMBER_WWN The Node WWN of the member switch. char MEMBER_STATUS The reachability status of the member switch as seen smallint by the group leader switch. For possible values see the enum definition in the DTO class.
Page 74 Database tables and fields TABLE 103 SMART CARD Field Definition Format Size GROUP_NAME The name of the Encryption Group used to initialize varchar the card. For recovery set cards, this identifies which group’s master key is backed up on the card. CREATION_TIME The date and time that the card was initialized.
Page 75: Encryption Container
Database tables and fields Encryption Container TABLE 105 CRYPTO HOST Field Definition Format Size CRYPTO_TARGET_CONTAIN Foreign key reference to the ER_ID CRYPTO_TARGET_CONTAINER that contains this host. VI_NODE_WWN Node WWN of Virtual Initiator that represents this char host. VI_PORT_WWN Port WWN of Virtual Initiator that represents this char host.
Page 76 Database tables and fields TABLE 107 CRYPTO LUN (Continued) Field Definition Format Size SERIAL_NUMBER The LUN serial number, used to identify the physical varchar LUN. ENCRYPTION_STATE Boolean. True (1) if LUN is being encrypted. False (0) smallint if cleartext. STATUS Not currently used but left in for possible future use.
Page 77 Database tables and fields TABLE 107 CRYPTO LUN (Continued) Field Definition Format Size CRYPTO_HOST_ID Foreign key reference to the CRYPTO_HOST that uses this LUN. LUN_NUMBER The Logical Unit Number of the LUN, as seen by the varchar LUNs host. This may be an integer (0 - 65565) or a WWN-format 8-byte hex number.
Page 78 Database tables and fields TABLE 108 ENCRYPTION ENGINE (Continued) Field Definition Format Size SP_CERTIFICATE The public key certificate, in PEM format, for the varchar 4096 Security Processor within the Encryption Engine. Used to create link keys for NetApp LKM key vaults. EE_STATE The operational status of this Encryption Engine.
Page 79: Meta San
Database tables and fields Meta SAN TABLE 111 LSAN_DEVICE Field Definition Format Size BB_FABRIC_ID Backbone fabric DB ID. FCR_FABRIC_ID FID assigned to edge fabric. DEVICE_PORT_WWN Device port WWN of physical device. char PHYSICAL_PID PID of physical device. char TABLE 112 LSAN_PROXY_DEVICE Field Definition...
Page 80 Database tables and fields TABLE 114 FABRIC (Continued) Field Definition Format Size TYPE Type of fabric: smallint 0 = legacy fabric 1 = base fabric 2 = logical fabric SECURE 1 = it is a secured fabric. smallint AD_ENVIRONMENT 1 = there are user-defined ADs in this fabric. smallint MANAGED 1 = it is an actively "monitored"...
Page 81: Network
Database tables and fields Network TABLE 117 IP_INTERFACE Field Definition Format Size ETHERNET_PORT_ID GigE Port ID. IP_ADDRESS IP address on the Ip_interface. varchar NET_MASK Subnet mask for the interface. varchar MTU_SIZE MTU Size for that interface. CHECKSUM Check Sum. varchar TABLE 118 IP_ROUTE Field...
Page 82: Port Fencing
Database tables and fields TABLE 121 OUI_GUESSED_DEVICE_MAP Field Definition Format Size OUI* Vendor OUI. char TYPE Guessed device type for this vendor. varchar TABLE 122 FEATURE Field Definition Format Size FEATURE_ID* ID used to uniquely identify the feature. NAME Name of the feature. varchar DESCRIPTION Description for the feature.
Page 83: Switch
Database tables and fields TABLE 125 PORT_FENCING_POLICY_MAP Field Definition Format Size POLICY_ID Foreign key to ID column of PORT_FENCING_POLICY table. LEVEL 0 = All Fabric smallint 1 = Fabric 2 = Core Switch Group 3 = Switch 4 = Port Type 5 = Port List SUB_LEVEL 1 = E_Port...
Page 84 Database tables and fields TABLE 127 QRTZ_TRIGGERS (Continued) Field Definition Format Size JOB_GROUP Name of the job group. varchar IS_VOLATILE Whether the trigger should be persisted in the boolean JobStore for re-use after program restarts. DESCRIPTION A description for the trigger instance - may be useful varchar for remembering/displaying the purpose of the trigger, though the description has no meaning to...
Page 85 Database tables and fields TABLE 129 QRTZ_FIRED_TRIGGERS (Continued) Field Definition Format size IS_STATEFUL Whether the job implements the interface boolean StatefulJob. REQUESTS_RECOVERY True or false. boolean TABLE 130 QRTZ_JOB_LISTENERS Field Definition Format Size JOB_NAME* Name of the job. varchar JOB_GROUP* Name of the job group.
Page 86: Reports
Database tables and fields TABLE 135 QRTZ_LOCKS Field Definition Format Size LOCK_NAME* Resource identification name assigned by user. varchar TABLE 136 QRTZ_CALENDARS Field Definition Format Size CALENDAR_NAME* Name of the Calendar. varchar CALENDAR Calendar object. bytea TABLE 137 QRTZ_PAUSED_TRIGGER_GRPS Field Definition Format Size...
Page 87 Database tables and fields TABLE 141 ROLE Field Definition Format Size NAME Role name. varchar DESCRIPTION Role description. varchar HIDDEN Field to identify whether the role is Hidden from users smallint or not. Values: 0= Not Hidden 1= Hidden Currently, only ''All Users'' Role is hidden and other roles are visible to user.
Page 88 Database tables and fields TABLE 147 USER_ Field Definition Format Size ID * NAME User name. varchar DESCRIPTION User description. varchar PASSWORD User password. varchar EMAIL User e-mail ID. varchar 1024 NOTIFICATION_ENABLED Flag for e-mail notification. smallint Default value is 0. FULL_NAME User''s Full Name.
Page 89 Database tables and fields TABLE 150 RESOURCE_FABRIC_MAP Field Definition Format Size RESOURCE_GROUP_ID* Resource group ID. FABRIC_ID* Fabric ID, which is in the resource group. Brocade Network Advisor Documentation Updates 53-1002363-02...
Page 90: Snmp
Database tables and fields SNMP TABLE 152 SNMP_CREDENTIALS Field Definition Format Size VIRTUAL SWITCH_ID Virtual switch ID for which this instance of the SNMP credentials apply. RECIPIENT_ID Recipient in the MESSAGE_RECIPIENT table. POR)_NUMBER Port number of the SNMP agent on the switch for get smallint and set requests.
Page 91 Database tables and fields TABLE 152 SNMP_CREDENTIALS (Continued) Field Definition Format Size PRIV_PROTOCOL An indication of whether messages sent or received varchar on behalf of this user can be encrypted and if so, which privacy protocol to use. The current values for this field are: usmNoPrivProtocol and usmDESPrivProtocol.
Page 92 Database tables and fields TABLE 153 SNMP_PROFILE (Continued) Field Definition Format Size AUTH_PROTOCOL An indication of whether or not messages sent or varchar received on behalf of this user can be authenticated and if so, which authentication protocol to use. The supported values for this field are: usmNoAuthProtocol, usmHMACMD5AuthProtocol, and usmHMACSHAAuthProtocol.
Page 93: Stats
Database tables and fields Stats TABLE 155 FAVORITES Field Definition Format Size NAME Name of the favorite. varchar USER_ The application user credentials. varchar TOP_N The top number of ports(5,10,15,20). varchar SELECTION_FILTER Types of ports (FC/FCIP/GE) and -End Monitors. varchar FROM_TIME The time interval in which the graph is shown.
Page 94 Database tables and fields TABLE 156 USER_ (Continued) Field Definition Format Size LOCKED_OUT_DATETIME The date time stamp when a user got locked out timestamp because of exceeding max number of invalid login attempts. STATUS User''s account status: smallint 0=Disabled 1=Enabled Default value is 1.
Page 95 Database tables and fields TABLE 159 DEFAULT_FAVORITES (Continued) Field Definition Format Size TOP_N Types of ports (FC/FCIP/GE) and -End Monitors. varchar SELECTION_FILTER The time interval in which the graph is shown. varchar FROM_TIME Always null. The default favorite is not customized. varchar CUSTOM_LAST_VALUE Always null.
Page 96: Switch
Database tables and fields Switch TABLE 160 VIRTUAL-SWITCH Field Definition Format Size LOGICAL_ID Logical ID of the switch. smallint NAME Switch name. varchar WWN of the switch. char VIRTUAL_FABRIC_ID Virtual fabric ID. If VF enabled then will have the VFID; smallint otherwise it will be -1.
Page 97 Database tables and fields TABLE 161 CORE_SWITCH Field Definition Format Size IP_ADDRESS IP address of the switch. varchar Chassis WWN. char NAME Switch name. varchar TYPE SWBD type number as given by Fabric OS. smallint Default value is 0. MODEL Model type of the switch: smallint 0 = Unknown...
Page 98 Database tables and fields TABLE 161 CORE_SWITCH (Continued) Field Definition Format Size NIC_PROFILE_ID NIC profile of the Management application server host used by this switch to communicate in interactive configuration and other operations. It determines which Management application host IP used by this switch.
Page 99: Switch Details
Database tables and fields TABLE 164 SWITCH_MODEL (Continued) Field Definition Format Size DESCRIPTION Model description, such as FC link speed, port count varchar and whether multi-card (director) class switch or other type of switch. Default is ‘Not Available’. MODEL Switch model string. varchar REMARK Remarks, such as an internal project name.
Page 100 Database tables and fields TABLE 166 CORE_SWITCH_DETAILS (Continued) Field Definition Format Size FC_MASK Subnet mask for FC IP. char FC_IP Fibre Channel IP address. char FC_CERTIFICATE smallint SW_LICENSE_ID char SUPPLIER_SERIAL_ Serial number of the chassis. varchar NUMBER PART_NUMBER The part number assigned by the organization varchar responsible for producing or manufacturing the PhysicalElement.
Page 101 Database tables and fields TABLE 166 CORE_SWITCH_DETAILS (Continued) Field Definition Format Size MAX_NUM_OF_BLADES Required by SMIA to populate smallint Brocade_Chassis.MaxNumOfBlades property. It indicates the max no of blades that can be present in a chassis. VENDOR_VERSION Required by integrated SMI agent to populate varchar Brocade_Product.Version property.
Page 102 Database tables and fields TABLE 167 CORE_SWITCH (Continued) Field Definition Format Size CREATION_TIME Time when this record was created by the timestamp Management application. Default is ’now()’. LAST_SCAN_TIME Time when this record was last updated. timestamp LAST_UPDATE_TIME 1 = the Management application server is registered timestamp with the switch to receive Syslog.
Page 103: Switch Port
Database tables and fields Switch port TABLE 169 GIGE_PORT Field Definition Format Size SWITCH_PORT_ID ID for the GigE Port in SWITCH_PORT. PORT_NUMBER GigE Port Number(0 for ge0 and 1 for ge1). SLOT_NUMBER Slot number on which the GigE Port is present. ENABLED Enabled or disabled.
Page 104 Database tables and fields TABLE 170 SWITCH_PORT (Continued) Field Definition Format Size PORT_NUMBER The logical port number of the user port. There is no smallint assumption of any relation to the physical location of a port within a chassis. USER_PORT_NUMBER User port number.
Page 105 Database tables and fields TABLE 170 SWITCH_PORT (Continued) Field Definition Format Size PERSISTENT_DISABLE 1 = port is persistently disabled. smallint FICON_SUPPORTED 1 = FICON is supported; otherwise, 0. smallint BLOCKED 1 = port is blocked; otherwise, 0. smallint PROHIBIT_PORT_NUMBERS varchar 1024 PROHIBIT_PORT_COUNT smallint...
Page 106 Database tables and fields TABLE 170 SWITCH_PORT (Continued) Field Definition Format Size LOGICAL_PORT_NUMBER F-Port trunk logical port number. smallint Default value is -1. DEFAULT_AREA_ID Default Area id of F-Port trunk port. smallint Default value is -1. LOGICAL_PORT_WWN Logical port WWN of F-Port trunk group. char PREVIOUS_TYPE This fields copies the old state of the port type.
Page 107 Database tables and fields TABLE 174 FPORT_TRUNK_GROUP (Continued) Field Definition Format Size MASTER_USER_PORT User port number for the master port of this trunk. smallint WWN of the trunk group. char TRUNK_AREA User-assigned area number used to group together smallint F_ports of the trunk. TABLE 175 FPORT_TRUNK_MEMBER Field...
Page 108: Switch Snmp Info
Database tables and fields TABLE 176 VIRTUAL_SWITCH (Continued) Field Definition Format Size USER_DEFINED_VALUE_2 varchar USER_DEFINED_VALUE_3 varchar CORE_SWITCH_ID Core switch DB ID. INTEROP_MODE Mode in which this switch is operating. smallint CRYPTO_CAPABLE 0 = the switch is not crypto-enabled; if capable it will smallint have non-zero value FCR_CAPABLE...
Page 109 Database tables and fields TABLE 181 VIRTUAL_SWITCH Field Definition Format Size LOGICAL_ID smallint NAME varchar char VIRTUAL_FABRIC_ID Default value is 0. smallint DOMAIN_ID smallint BASE_SWITCH Default value is 0. smallint SWITCH_MODE Default value is 0. smallint ROLE varchar FCS_ROLE varchar AD_CAPABLE Default value is 0.
Page 110 Database tables and fields TABLE 181 VIRTUAL_SWITCH (Continued) Field Definition Format Size DEFAULT_LOGICAL_SWITCH Check to see whether virtual switch is a default smallint logical switch or not. 1 is true and 0 is false. Default value is 0. FEATURES_SUPPORTED Contains the features supported as a bit mask. Default value is 0.
Page 111: User Interface
Database tables and fields TABLE 181 VIRTUAL_SWITCH (Continued) Field Definition Format Size PREVIOUS_STATE This fields copies the old state of the switch . The varchar field could be used to track the state change information for the switch.These values to be populated by FCS during Fabric Refresh task.SMIA requested this information but could be used by any module which needs to track the state change...
Page 112 Database tables and fields TABLE 184 AVAILABLE_FLYOVER_PROPERTY (Continued) Field Definition Format Size TYPE The flyover property type: smallint 0 = Product property 1 = Connection property DEFAULT_SELECTION AVAILABLE_FLYOVER_PROPERTY smallint DEFAULT_SELECTION 1 = default selected product/connection property 0 = not included in the default list. TABLE 185 SELECTED_FLYOVER_PROPERTY Field...
Page 113 Database tables and fields TABLE 188 PRODUCT_APP (Continued) Field Definition Format Size PROP2_KEY Second condition name to be satisfied by a selected varchar product to launch a particular tool. PROP2_VALUE Second condition value to be satisfied by a selected varchar product to launch a particular tool.
Page 114: Zoning 2
Database tables and fields TABLE 191 LSAN_ZONE (Continued) Field Definition Format Size EDGE_FABRIC_ID FID assigned to edge fabric. NAME LSAN zone name. varchar BACKBONE 0= is not a backbone lsan zone, smallint 1= is a backbone lsan zone. Default value is 0. TABLE 192 LSAN_ZONE_MEMBER Field...
Page 115 Database tables and fields TABLE 196 ZONE_ALIAS_MEMBER Field Definition Format Size TYPE Zone alias member type: smallint 2 = WWN 4 = D,P VALUE Member value (D,P or WWN). varchar ZONE_ALIAS_ID PK of the owning zone alias. TABLE 197 ZONE_IN-ZONE_SET Field Definition Format...
Page 116 Database tables and fields TABLE 199 ZONE_DB (Continued) Field Definition Format Size DEFAULT_ZONE_STATUS All access or no access when no active zone smallint configuration. ZONE_TXN_SUPPORTED Zoning commands support transaction. smallint MCDATA_DEFAULT_ZONE McData switch default zoning mode. smallint MCDATA_SAFE_ZONE McData switch safe zoning mode. smallint ZONE_CONFIG_SIZE Zone configuration string length.
Page 117 Database tables and fields TABLE 204 AD_GROUP_ROLE_MAP Field Definition Format Size AD_GROUP_ID Active directory group ID ROLE_ID TABLE 205 Field Definition Format Size NAME varchar DESCRIPTION varchar TABLE 206 AOR_DEVICE_GROUP_MAP Field Definition Format Size AOR_ID ID of the AOR. DEVICE_GROUP_ID The Product Group which is in the AOR.
Page 118 Database tables and fields TABLE 211 AUTO_TRACE_DUMP Field Definition Format Size CORE_SWITCH_ID ENABLED The enabled/disabled state of automatic trace dump smallint transfer on the switch PROTOCOL The protocol Unknown(0)/FTP(1)/SCP(2) to be used for smallint transfer IP_ADDRESS The Host IP Address varchar USER_NAM The user name...
Page 119 Database tables and fields TABLE 214 BOOT_LUN_SEQUENCE Field Definition Format Size NAME Name of the Boot LUN Sequence varchar FABRIC_ID PK of the owning fabric TABLE 215 BOOT_LUN_SEQUENCE_DETAIL Field Definition Format Size ID * BOOT_LUN_SEQ_ID PK of the owning Boot LUN Sequence char PORT_WWN WWN of the port in the Boot LUN Sequenc...
Page 120 Database tables and fields TABLE 216 CEE_PORT (Continued) Field Definition Format Size QOS_NAME Name of the QoS Map set on the port varchar DOT1X_ENABLED Indicate if 802.1x authentication is enabled on this smallint port. The default value is 0. TABLE 217 CLIENT_VIEW_MEMBER_HOST Field Definition...
Page 121 Database tables and fields TABLE 221 CNA_PORT Field Definition Format Size Primary key autogenerated ID PORT_NUMBER Port number of the CNA port PORT_WWN Port WWN of the port char NODE_WWN Node WWN of the port char PHYSICAL_PORT_TYPE Port type CNA/FC varchar NAME Name of the port...
Page 122 Database tables and fields TABLE 223 COLLECTOR_END_TIMESTAMP (Continued) Field Definition Format Size TIMESTAMP_ When the last successful collection is done. timestamp LAST_COLLECTED_STATUS Status of the last collection, successful or not. 200 is smallint for successful. Values are standard HTTP protocol values.
Page 123 Database tables and fields TABLE 225 CRYPTO_LUN (Continued) Field Definition Format Size LAST_REKEY_PROGRESS Indicates whether a re-key operation is in progress. 0 smallint = no re-keying in progress. > 0 = percentage done of re-keying operation in progress. Only valid for disk LUNs. The default value is If a tape session is in progress, this is the volume label varchar 2048...
Page 124 Database tables and fields TABLE 225 CRYPTO_LUN (Continued) Field Definition Format Size LUN_FLAGS Bitmap of LUN options. The only option currently used bigint is bit 0 (least significant) which indicates that the LUN must be manually enabled because it has been disabled due to inconsistent metadata detected.
Page 125 Database tables and fields TABLE 226 CRYPTO_TARGET_CONTAINER (Continued) Field Definition Format Size FAILOVER_STATUS Indicates whether this container''s target is being smallint encrypted by the encryption engine on which the container is configured (value 0) or by another encryption engine in the HA Cluster (value 1). Default value is 0..
Page 126 Database tables and fields TABLE 229 ENCRYPTION_ENGINE Field Definition Format Size SWITCH_ID Foreign key reference to both the VIRTUAL_SWITCH table and the CRYPTO_SWITCH table (both switch tables use the same primary key values). Identifies the switch that contains this encryption engine. SLOT_NUMBER For chassis switches, the slot or blade that contains smallint...
Page 127 Database tables and fields TABLE 229 ENCRYPTION_ENGINE (Continued) Field Definition Format Size LINK_MTU Local EE Link MTU. The default value is -1. LINK_STATE Local EE State says whether link is down or up varchar REBALANCE_REQUIRED This field indicates whether a rebalance operation is smallint required on the Encryption Engine.
Page 128 Database tables and fields TABLE 230 ENCRYPTION_GROUP (Continued) Field Definition Format Size Boolean value that indicates whether a System Card smallint SYSTEM_CARD_REQUIRED (smart card) must be inserted in the Encryption Engine to enable the engine after power-up. This feature is not yet supported. The default value is 0.
Page 129 Database tables and fields TABLE 231 ETHERNET_CLOUD Field Definition Format Size SWITCH_ID The unique id of the switch this cloud is associated TABLE 232 ETHERNET_ISL Field Definition Format Size SOURCE_PORT_ID The unique id of the source port. DEST_PORT_ID The unique id of the destination port. MISSING smallint, MISSING_TIME...
Page 130 Database tables and fields TABLE 234 EVENT_CATEGORY Field Definition Format Size 0 - Unknown 1 - Product Event 2 - Link Incident Event 3 - Product Audit Event 4 - Product Status Event 5 - Security Event 6 - User Action Event 7 - Management Server Event DESCRIPTION varchar...
Page 131 Database tables and fields TABLE 237 EVENT_FWD_FILTER Field Definition Format Size NAME Filter Name varchar DESCRIPTION varchar TYPE Filter Type (SNMP/ SYSLOG) smallint APPLICATION_ENABLED If Application Events enabled smallint SNORT_ENABLED If Snort Messages enabled smallint PSUDO_ENABLED If Pseudo Events enabled smallint REGULAR_EXP Common filtering message for Syslog Forwarding...
Page 132 Database tables and fields TABLE 242 EVENT_INSTANCE Field Definition Format Size EVENT_POLICY_ID Foreign Key to Event_Policy Table EVENT_KEY A String Key string which identifies a specific instance varchar of an Event. STRING_PATTERN A Regular expression pattern string which can be used varchar 1024 to match an Event instance.
Page 133 Database tables and fields TABLE 245 EVENT_POLICY Field Definition Format Size TYPE Even Policy Type smallint 0 - Pseudo Event 1 - Event Action NAME The Name of the Event Policy varchar DESCRIPTION The Description of the Event Policy varchar 1024 STATUS Administrative status of the Event Policy...
Page 134 Database tables and fields TABLE 246 EVENT_POLICY_SOURCE_ENTRY (Continued) Field Definition Format Size SOURCE_SELECTION_TYPE Option selected to give Source Information smallint IPAddress/Node wwn/Name provided Source selected from available list of sources. The default value is 0. IP_ADDRESS IP address of source varchar 1024 Node WWN of source...
Page 135 Database tables and fields TABLE 250 FCIP_TUNNEL_CIRCUIT (Continued) Field Definition Format Size TAPE_ACCELERATION_ENABLED Whether TapeAccelaration is smallint enabled on that circuit IKE_POLICY_NUM The IKE Policy on the circuit.The default value is -1. IPSEC_POLICY_NUM The IPSEC Policy on the circuit'. The default value is PRESHARED_KEY The preshared Key on the char(...
Page 136 Database tables and fields TABLE 250 FCIP_TUNNEL_CIRCUIT (Continued) Field Definition Format Size MAX_RETRANSMISSIONS Max number of Retransmission attempts on the circuit. The default value is 0. SLOT_NUMBER Slot number of the circuit. smallint The default value is 0. VE_PORT_NUMBER VE port number of the tunnel to which the circuit belongs.
Page 137 Database tables and fields TABLE 251 FCIP_TUNNEL_PERFORMANCE Field Definition Format Size TUNNEL_ID Primary key of the Switch Port SWITCH_ID The number of octets or bytes that have been transmitted by this port. One second periodic polling of the port. This value is saved and compared with the next polled value to compute...
Page 138: Collector
Database tables and fields TABLE 251 FCIP_TUNNEL_PERFORMANCE (Continued) Field Definition Format Size RTT_BY_TIME_OUT Counter of retransmit double precision packets due to timeout RTT_BY_DUP_ACK Counter of retransmit double precision packets due to duplicate acknowledgement' DUPLICATE_ACK Counter of duplicate double precision acknowledgement packets ROUND_TRIP_TIME Round trip time in...
Page 139 Database tables and fields TABLE 253 FRU (Continued) Field Definition Format Size VENDOR_PART_ provides the Vendor-assigned part number of this varchar package, requested by SMIA and values filled in by NUMBER Switch Asset Collector VENDOR_SERIAL_ provides the Vendor-assigned serial number of this varchar package, requested by SMIA and values filled in by NUMBER...
Page 140 Database tables and fields TABLE 253 FRU (Continued) Field Definition Format Size PREVIOUS_OP_STATUS provides the previous operational status of FRU element, requested by SMIA and values filled in by Switch Asset Collector. Helps identify the operational status transitions. The default value is -1. VENDOR This holds the vendor name information for FRU varchar...
Page 141 Database tables and fields TABLE 255 HBA (Continued) Field Definition Format Size MANAGEMENT_INTERFACE Management interface bit mask, JSON/WMI/SMI etc . The default value is -1. DRIVER_VERSION The version level of the host adapter varchar driver DRIVER_NAME The name of the HBA driver varchar FIRMWARE_VERSION The version level of the firmware...
Page 142 Database tables and fields TABLE 255 HBA (Continued) Field Definition Format Size VPD_PW PW details of the device varchar VPD_EDC EDC details of the device varchar VPD_MDC MDC details of the device varchar VPD_FABRIC_GEOGRAPHY FABRIC_GEOGRAPHY of the device varchar VPD_LOCATION LOCATION of the device varchar VPD_MANUFACTURER_ID...
Page 143 Database tables and fields TABLE 257 (Continued) HOST_DISCOVERY_REQUEST Field Definition Format Size The status of HBA Discovery using CIM_MANAGEMENT_STA CIM, indicating success or failure. The default value is 0. MANAGEMENT_STATE Reflects the status of the request E.g. 0-> Completed, 1->Add Pending 2->Delete Pending 3->Edit Pending 4->Delete Failed.
Page 144 Database tables and fields TABLE 260 (Continued) Field Definition Format Size LAG_MODE Static or dynamic (1=dynamic, 2=static) smallint ACTIVE LACP active or passive (1=active, 2=passive) valid if smallint mode=dynamic TYPE Trunking type (1=standard, 2=brocade, 3=hybrid) smallint IF_MODE L2 or L3 mode varchar L2_MODE Type of L2 mode (default=access...
Page 145 Database tables and fields TABLE 263 LICENSE_RULE (Continued) Field Definition Format Size DESCRIPTION Description of the rule varchar SCOPE Scope of the rule - is it applicable to Fabric, switch or varchar ports CATEGORY Category of the rule - is it used by unknown - 0, asset smallint collection - 1, or 2 - the license manager service ENABLE...
Page 146 Database tables and fields TABLE 267 PASSWORD_HISTORY Field Definition Format Size USER_NAME varchar PASSWORD_UPDATED_ The date and time the user updated password recently. timestamp DATETIME PREVIOUS_PASSWORD User''s Previous password varchar TABLE 268 PHANTOM_PORT Field Definition Format Size The Wwn of the phantom port. char VIRTUAL_SWITCH_ID The id of the phantom switch.
Page 147 Database tables and fields TABLE 269 PORT_BOTTLENECK_CONFIG (Continued) Field Definition Format Size WINDOW_ Value of bottleneck detection latency window in millisecond. The default value is 0. QUIET_TIME Value of bottleneck detection quiet time in millisecond. The default value is 0. CREATION_TIME Creation time of the record.
Page 148 Database tables and fields TABLE 274 RESOURCE_HOST_MAP Field Definition Format Size RESOURCE_GROUP_ID Resource Group ID HOST_ID HOST_ID,which is in the resource group TABLE 275 SSL_KEY_PASSWORD Field Definition Format Size KEY_PASSWORD_ALIAS Key Password Alias is the alias name used for the varchar encrypted key password.
Page 149 Database tables and fields TABLE 277 IP_DEVICE_LICENSE (Continued) Field Definition Format Size PRECEDENCE Defines the priority of a particular trial license among those having the same package and License ID. This is primarily used for determining which license to use, when there are many trial and normal licenses with same package name and LID.
Page 150 Database tables and fields TABLE 280 ZONE_TRANSACTION Field Definition Format Size FABRIC_ID The id of the fabric on which the zoning transaction is open. This is the primary key for this table and is a foreign key from the FABRIC table where ZONE_TR.FABRIC_ID == FABRIC.ID USER_NAME The Management applciation username of the...
Page 151 Database tables and fields TABLE 285 V_CENTER_HOST Field Definition Format Size HOST The FQDN or the ip address of the host varchar PORT The port of the VCENTER server on the host. The default value is 443 . USER_NAME The username to login into the VCENTER varchar PASSWORD The password to login into the VCENTER...
Page 152 Database tables and fields TABLE 288 VIRTUAL_FCOE_PORT_STAT Field Definition Format Size SWITCH_ID PORT_ID The number of valid frames sent from the port double precision The number of valid frames received at this port double precision TX_UTILIZATION The computed value of TX based on speed of port (for double MarchingAnts) precision...
Page 153 Database tables and fields TABLE 289 VIRTUAL_FCOE_PORT_STAT_1DAY (Continued) Field Definition Format Size RX_UTILIZATION double precision CREATION_TIME timestamp ACTIVE_STATE smallint LINK_FAILURES double precision TX_LINK_RESETS double precision RX_LINK_RESETS double precision SYNC_LOSSES double precision SIGNAL_LOSSES double precision SEQUENCE_ERRORS double precision INVALID_TX double precision CRC_ERRORS double precision...
Page 154 Database tables and fields TABLE 290 VIRTUAL_FCOE_PORT_STAT_2HR (Continued) Field Definition Format Size CREATION_TIME double precision ACTIVE_STATE timestamp LINK_FAILURES double precision TX_LINK_RESETS double precision RX_LINK_RESETS double precision SYNC_LOSSES double precision SIGNAL_LOSSES double precision SEQUENCE_ERRORS double precision INVALID_TX double precision CRC_ERRORS double precision DATA_GAPS_5MIN smallint...
Page 155 Database tables and fields TABLE 291 VIRTUAL_FCOE_PORT_STAT_30M (Continued) Field Definition Format Size TX_LINK_RESETS double precision RX_LINK_RESETS double precision SYNC_LOSSES double precision SIGNAL_LOSSES double precision SEQUENCE_ERRORS double precision INVALID_TX double precision CRC_ERRORS double precision DATA_GAPS_5MIN Data gap in 5 minutes table smallint TABLE 292 VIRTUAL_MACHINE...
Page 156 Database tables and fields TABLE 292 VIRTUAL_MACHINE (Continued) Field Definition Format Size DATASTORE_NAME varchar The user-assigned name for the VMs datastore. The datastore holds the VMs virtual disks, swap file, and configuration data DATASTORE_LOCATION varchar The location of the VMs datastore May be a SAN tar- get disk or a locally-attached host disk folder.
Page 157 Database tables and fields TABLE 295 USER_DEFINED_DEVICE_DETAIL (Continued) Field Definition Format Size USER_DEFINED_VALUE1 varchar USER_DEFINED_VALUE2 varchar USER_DEFINED_VALUE3 varchar TABLE 296 SWITCH_BOTTLENECK_CONFIG Field Definition Format Size VIRTUAL_SWITCH_ID The database ID of the switch that the configuration belongs to 'Flag indicates if bottleneck detection is enabled or smallint BOTTLENECK_DETECT_ENA not.
Page 158 Database tables and fields TABLE 297 SWITCH_PORT_PERFORMANCE (Continued) Field Definition Format Size RX_UTILIZATION 'The computed value of RX based on speed of port double precision LINK_FAILURE Count of link failures. This count is part of the Link double Error Status Block (LESB). (FC-PH 29.8). Note, this is precision a Fibre Channel only stat TX_LINK_RESETS...
Page 159 Database tables and fields TABLE 298 SWITCH_TE_PORT_PERFORMANCE (Continued) Field Definition Format Size The number of octets or bytes that have been double received by this port. One second periodic polling of precision the port. This value is saved and compared with the next polled value to compute net throughput.
Page 160 Database tables and fields TABLE 299 SWITCH_TE_PORT_STATS Field Definition Format Size SWITCH_ID The primary key of the switch PORT_ID The primary key of the port TRANSMIT_OK 'The number of valid frames sent from the port double precision RECEIVE_OK The number of valid frames received at this port. double precision The computed value of transmit_ok based on speed...
Page 161 Database tables and fields TABLE 300 SWITCH_TE_PORT_STATS_1DAY Field Definition Format Size SWITCH_ID PORT_ID TRANSMIT_OK double precision RECEIVE_OK double precision double TRANSMIT_OK_PERCENT_U precision double RECEIVE_OK_PERCENT_UTI precision CREATION_TIME timestamp ACTIVE_STATE smallint RECEIVE_EOF double precision UNDERFLOW_ERRORS double precision OVERFLOW_ERRORS double precision CRC_ERRORS double precision ALIGNMENT_ERRORS double...
Page 162 Database tables and fields TABLE 301 SWITCH_TE_PORT_STATS_2HR Field Definition Format Size SWITCH_ID PORT_ID TRANSMIT_OK double precision RECEIVE_OK double precision double TRANSMIT_OK_PERCENT_U precision double RECEIVE_OK_PERCENT_UTI precision CREATION_TIME timestamp ACTIVE_STATE smallint RECEIVE_EOF double precision UNDERFLOW_ERRORS double precision OVERFLOW_ERRORS double precision CRC_ERRORS double precision ALIGNMENT_ERRORS double...
Page 163 Database tables and fields TABLE 302 SWITCH_TE_PORT_STATS_30MIN (Continued) Field Definition Format Size PORT_ID TRANSMIT_OK double precision RECEIVE_OK double precision TRANSMIT_OK_PERCENT_ double precision UTIL RECEIVE_OK_PERCENT_ double precision UTIL CREATION_TIME timestamp ACTIVE_STATE smallint RECEIVE_EOF double precision UNDERFLOW_ERRORS double precision OVERFLOW_ERRORS double precision CRC_ERRORS double precision...
Page 164 Database tables and fields TABLE 304 TOPO_MAP_IMAGE Field Definition Format Size NAME Image name in the foo.png format varchar IMAGE_OBJECT 'Image Object BLOB bytea TABLE 305 SMART_CARD Field Definition Format Size CARD_TYPE Indicates how this smart card is configured: 0 = smallint authorization card.
Page 165 Database tables and fields TABLE 306 SNMP_DATA_1DAY (Continued) Field Definition Format Size VALUE double precision TIME_IN_SECONDS COLLECTOR_ID MIB_INDEX char TABLE 307 SNMP_DATA_2HOUR Field Definition Format Size MIB_OBJECT_ID TARGET_TYPE numeric (2,0) TARGET_ID VALUE double precision TIME_IN_SECONDS COLLECTOR_ID MIB_INDEX char TABLE 308 SNMP_DATA_30MIN Field Definition...
Page 166 Database tables and fields TABLE 309 SNMP_EXPR_DATA_1DAY (Continued) Field Definition Format Size TIME_IN_SECONDS COLLECTOR_ID TABLE 310 SNMP_EXPR_DATA_2HOUR Field Definition Format Size EXPRESSION_ID TARGET_TYPE smallint TARGET_ID VALUE double precision TIME_IN_SECONDS COLLECTOR_ID TABLE 311 SNMP_EXPR_DATA_30MIN Field Definition Format Size Primary key autogenerated ID EXPRESSION_ID DB ID of the expression object used for collection TARGET_TYPE...
Page 167 Database tables and fields TABLE 313 SENSOR Field Definition Format Size CORE_SWITCH_ID SENSOR_ID Identifies the sensor device , requested by SMIA and values filled in by Switch Asset Collector. Maps to Device Id in the html page. The default value is -1. CURRENT_READING Identifies the current temperature reading sensor, bigint...
Page 168 Database tables and fields TABLE 313 SENSOR (Continued) Field Definition Format Size UNIT_NUMBER provides the unit number of the sensor, requested by SMIA and values filled in by Switch Asset Collector will be available only from FOS 6.4 switches and above .
Page 169 Database tables and fields TABLE 315 HOST_DISCOVERY_OPTION (Continued) Field Definition Format Size CIM_NAMESPACE CIM Namespace. varchar The default value is 'root/brocade CIM_PORT Port number used for the CIM agent. The default value is 5988. DISCOVER_VM Flag to indicate VM discovery for a host. On/Off'. smallint The default value is 0.
Page 170 Database tables and fields TABLE 317 HBA_REMOTE_PORT_LUN (Continued) Field Definition Format size BLOCK_SIZE The block size of the logical unit, in bytes (for example, 512 Bytes). The default value is 0. VENDOR The vendor of the device to which the logical unit is varchar assigned PRODUCT_ID...
Page 171 Database tables and fields TABLE 318 HBA_REMOTE_PORT (Continued) Field Definition Format Size QOS_PRIORITY QOS Priority on the target. The default value is varchar 'Unknown'. QOS_FLOW_ID QOS Flow ID on the target. The default value is 0. varchar CURRENT_SPEED Current speed of the remote port, as enforced by varchar TRL.
Page 172 Database tables and fields TABLE 319 HBA_PORT (Continued) Field Definition Format Size CONFIGURED_TOPOLOGY The topology setting. The default value is 1. MAX_SPEED_SUPPORTED The maximum port speed that is supported on the port, in Gb/s. The default value is 0. OPERATING_STATE Indicates whether the link is online or offline.
Page 173 Database tables and fields TABLE 320 HBA_PORT_DETAIL (Continued) Field Definition Format Size BOOT_SPEED The default value is 0. BOOT_TOPOLOGY The default value is 1. BB_CREDIT The maximum number of receive buffer. The default value is 8. FRAME_DATA_FIELD_SIZE The default value is 512. HARDWARE_PATH Indicates whether MPIO is enabled or disabled V_PORT_COUNT...
Page 174 Database tables and fields TABLE 320 HBA_PORT_DETAIL (Continued) Field Definition Format Size FCSP_AUTH_STATE Indicates whether FC-SP authentication is on or off. smallint The default value is 0. FCSP_STATUS The status of FC-SP authentication. varchar The default value is 'Disabled'. FCSP_ALGORITHM The configured authentication algorithm.
Page 175 Database tables and fields TABLE 321 HBA_PORT_FCOE_DETAILS (Continued) Field Definition Format Size PORT_LOG_ENABLED The default value is 0. smallint MAX_FRAME_SIZE The default value is 512. The default value is 0. PATH_TOV The default value is 0. SCSI_QUEUE_DEPTH The default value is 0. STATE varchar SUPPORTED_CLASS...
Page 176 Database tables and fields TABLE 323 VM_HOST Field Definition Format Size Identifies a server running a supported hypervisor. The ID value is the same as the ID of the correspond- ing DEVICE_ENCLOSURE record. NODE_WWN The Node WWN for this host. char HYPERVISOR_NAME Hypervisor name and version, such as VMware ESX...
Page 177 Database tables and fields TABLE 324 VM_LUN (Continued) Field Definition Format Size PATH_POLICY Determines how multiple paths to this LUN are used. smallint 0 = fixed, 1 = Most Recently Used, 2 = Round Robin. The default value is 0. UUID Universal unique ID varchar...
Page 178: Views
Views TABLE 325 VM_PATH (Continued) Field Definition Format Size VM_NODE_WWN char The initiator node WWN used by the VM. If NPIV is used, this is a virtual node WWN assigned to the VM. If NPIV is not used, this WWN is the same as the node WWN of one of the HBAs in the host.
Page 179: Cna_Port_Details_Info
Views CEE_PORT.OCCUPIED, CEE_PORT.LAST_UPDATE, CEE_PORT.NET_MASK, CEE_PORT.PROTOCOL_DOWN_REASON, CEE_PORT.MAC_ACL_POLICY, CEE_PORT.QOS_TYPE, CEE_PORT.QOS_NAME, CEE_PORT.DOT1X_ENABLED, CORE_SWITCH.IP_ADDRESS as PHYSICAL_SWITCH_IP, CORE_SWITCH.WWN as PHYSICAL_SWITCH_WWN, GIGE_PORT.OPERATIONAL_STATUS, GIGE_PORT.MAX_SPEED, GIGE_PORT.PORT_TYPE, GIGE_PORT.REMOTE_MAC_ADDRESS, GIGE_PORT.SLOT_NUMBER, VIRTUAL_SWITCH.WWN, SWITCH_PORT.USER_PORT_NUMBER, SWITCH_PORT.STATE from CEE_PORT, GIGE_PORT, SWITCH_PORT, VIRTUAL_SWITCH, CORE_SWITCH where CEE_PORT.GIGE_PORT_ID = GIGE_PORT.ID and GIGE_PORT.SWITCH_PORT_ID = SWITCH_PORT.ID and SWITCH_PORT.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID and VIRTUAL_SWITCH.CORE_SWITCH_ID = CORE_SWITCH.ID;...
Page 180: Core_Switch_Details_Info
Views select CNA_PORT.ID, CNA_PORT.PORT_NUMBER, CNA_PORT.PORT_WWN, CNA_PORT.NODE_WWN, CNA_PORT.PHYSICAL_PORT_TYPE, CNA_PORT.NAME, CNA_PORT.MAC_ADDRESS, CNA_PORT.MEDIA, CNA_PORT.CEE_STATE, CNA_PORT.HBA_ID, CNA_PORT.CREATION_TIME as CNA_PORT_CREATION_TIME, CNA_ETH_PORT.ID as ETH_PORT_ID, CNA_ETH_PORT.ETH_DEV, CNA_ETH_PORT.ETH_LOG_LEVEL, CNA_ETH_PORT.NAME as ETH_PORT_NAME, CNA_ETH_PORT.MAC_ADDRESS as ETH_MAC_ADDRESS, CNA_ETH_PORT.IOC_ID, CNA_ETH_PORT.HARDWARE_PATH, CNA_ETH_PORT.STATUS, CNA_ETH_PORT.CREATION_TIME as ETH_PORT_CREATION_TIME, HBA_PORT.DEVICE_PORT_ID from CNA_PORT left outer join HBA_PORT on CNA_PORT.ID = HBA_PORT.CNA_PORT_ID left outer join CNA_ETH_PORT on CNA_PORT.ID = CNA_ETH_PORT.CNA_PORT_ID;...
Page 181: Crypto_Host_Lun_Info
Views CORE_SWITCH_DETAILS.FC_CERTIFICATE, CORE_SWITCH_DETAILS.SW_LICENSE_ID, CORE_SWITCH_DETAILS.SUPPLIER_SERIAL_NUMBER, CORE_SWITCH_DETAILS.PART_NUMBER, CORE_SWITCH_DETAILS.CHECK_BEACON, CORE_SWITCH_DETAILS.TIMEZONE, CORE_SWITCH_DETAILS.MAX_PORT, CORE_SWITCH_DETAILS.CHASSIS_SERVICE_TAG, CORE_SWITCH_DETAILS.BAY_ID, CORE_SWITCH_DETAILS.TYPE_NUMBER, CORE_SWITCH_DETAILS.MODEL_NUMBER, CORE_SWITCH_DETAILS.MANUFACTURER, CORE_SWITCH_DETAILS.PLANT_OF_MANUFACTURER, CORE_SWITCH_DETAILS.SEQUENCE_NUMBER, CORE_SWITCH_DETAILS.TAG, CORE_SWITCH_DETAILS.ACT_CP_PRI_FW_VERSION, CORE_SWITCH_DETAILS.ACT_CP_SEC_FW_VERSION, CORE_SWITCH_DETAILS.STBY_CP_PRI_FW_VERSION, CORE_SWITCH_DETAILS.STBY_CP_SEC_FW_VERSION, CORE_SWITCH_DETAILS.EGM_CAPABLE, CORE_SWITCH_DETAILS.SUB_TYPE, CORE_SWITCH_DETAILS.PARTITION, CORE_SWITCH_DETAILS.MAX_NUM_OF_BLADES, CORE_SWITCH_DETAILS.VENDOR_VERSION, CORE_SWITCH_DETAILS.VENDOR_PART_NUMBER, CORE_SWITCH_DETAILS.RNID_SEQUENCE_NUMBER, CORE_SWITCH_DETAILS.CONTACT, CORE_SWITCH_DETAILS.LOCATION, CORE_SWITCH_DETAILS.DESCRIPTION from CORE_SWITCH LEFT OUTER JOIN CORE_SWITCH_DETAILS on CORE_SWITCH_DETAILS.CORE_SWITCH_ID = CORE_SWITCH.ID; CRYPTO_HOST_LUN_INFO create or replace view CRYPTO_HOST_LUN_INFO as select...
Page 182: Crypto_Target_Engine_Info
Views LUN.ENCRYPTION_ALGORITHM, LUN.KEY_ID_STATE, LUN.REKEY_SESSION_NUMBER, LUN.PERCENTAGE_COMPLETE, LUN.REKEY_ROLE, LUN.CURRENT_LBA, LUN.LUN_STATE_STRING, LUN.NEW_LUN, LUN.NEW_LUN_TYPE, CRYPTO_HOST.HOST_PORT_WWN, CRYPTO_HOST.HOST_NODE_WWN from CRYPTO_LUN LUN, CRYPTO_HOST where LUN.CRYPTO_HOST_ID = CRYPTO_HOST.ID; CRYPTO_TARGET_ENGINE_INFO create or replace view CRYPTO_TARGET_ENGINE_INFO as select CRYPTO_TARGET_CONTAINER.ID TARGET_CONTAINER_ID, CRYPTO_TARGET_CONTAINER.NAME, CRYPTO_TARGET_CONTAINER.VT_NODE_WWN, CRYPTO_TARGET_CONTAINER.VT_PORT_WWN, CRYPTO_TARGET_CONTAINER.FAILOVER_STATUS, CRYPTO_TARGET_CONTAINER.FAILOVER_STATUS_2, CRYPTO_TARGET_CONTAINER.DEVICE_STATUS, CRYPTO_TARGET_CONTAINER.DEVICE_TYPE, CRYPTO_TARGET_CONTAINER.TARGET_PORT_WWN, CRYPTO_TARGET_CONTAINER.TARGET_NODE_WWN, CRYPTO_TARGET_CONTAINER.CONTAINER_FIELD_DATA, CRYPTO_TARGET_CONTAINER.CONFIGURATION_STATUS, CRYPTO_TARGET_CONTAINER.FRONT_END_N_PORT_NUMBER, ENCRYPTION_ENGINE.STATUS ENCRYPTION_ENGINE_STATUS,...
Page 183 Views CORE_SWITCH.OPERATIONAL_STATUS as PHYSICAL_OPERATIONAL_STATUS, CORE_SWITCH.TYPE, CORE_SWITCH.MAX_VIRTUAL_SWITCHES, CORE_SWITCH.NUM_VIRTUAL_SWITCHES, CORE_SWITCH.FIRMWARE_VERSION, CORE_SWITCH.VENDOR, CORE_SWITCH.REACHABLE, CORE_SWITCH.UNREACHABLE_TIME, CORE_SWITCH.MODEL, CORE_SWITCH.SYSLOG_REGISTERED, CORE_SWITCH.SNMP_REGISTERED, CORE_SWITCH.CALL_HOME_ENABLED, CORE_SWITCH.USER_IP_ADDRESS, CORE_SWITCH.NIC_PROFILE_ID, CORE_SWITCH.MANAGING_SERVER_IP_ADDRESS, CORE_SWITCH.VF_ENABLED, CORE_SWITCH.VF_SUPPORTED, CORE_SWITCH.MANAGED_ELEMENT_ID as CORE_MANAGED_ELEMENT_ID, CORE_SWITCH.NAT_PRIVATE_IP_ADDRESS, CORE_SWITCH.ALTERNATE_IP_ADDRESS, VIRTUAL_SWITCH.ID, VIRTUAL_SWITCH.NAME, VIRTUAL_SWITCH.OPERATIONAL_STATUS, VIRTUAL_SWITCH.SWITCH_MODE, VIRTUAL_SWITCH.AD_CAPABLE, VIRTUAL_SWITCH.WWN, VIRTUAL_SWITCH.ROLE, VIRTUAL_SWITCH.FCS_ROLE, VIRTUAL_SWITCH.DOMAIN_ID, VIRTUAL_SWITCH.VIRTUAL_FABRIC_ID, VIRTUAL_SWITCH.BASE_SWITCH, VIRTUAL_SWITCH.MAX_ZONE_CONFIG_SIZE, VIRTUAL_SWITCH.CREATION_TIME, VIRTUAL_SWITCH.LAST_UPDATE_TIME, VIRTUAL_SWITCH.USER_NAME, VIRTUAL_SWITCH.PASSWORD, VIRTUAL_SWITCH.MANAGEMENT_STATE, VIRTUAL_SWITCH.STATE,...
Page 184: Device_Info
Views VIRTUAL_SWITCH.PREVIOUS_OPERATIONAL_STATUS, VIRTUAL_SWITCH.LAST_SCAN_TIME, VIRTUAL_SWITCH.DOMAIN_MODE_239, VIRTUAL_SWITCH.DOMAIN_ID_OFFSET, VIRTUAL_SWITCH.DISCOVERED_PORT_COUNT, VIRTUAL_SWITCH.FCOE_LOGIN_ENABLED, VIRTUAL_SWITCH.LAST_PORT_MEMBERSHIP_CHANGE, VIRTUAL_SWITCH.FCIP_CIRCUIT_CAPABLE, VIRTUAL_SWITCH.MAX_FCIP_TUNNELS, VIRTUAL_SWITCH.MAX_FCIP_CIRCUITS, VIRTUAL_SWITCH.FCIP_LICENSED, VIRTUAL_SWITCH.ADDRESSING_MODE, VIRTUAL_SWITCH.PREVIOUS_STATE, VIRTUAL_SWITCH.MANAGED_ELEMENT_ID, VIRTUAL_SWITCH.HIF_ENABLED, FABRIC_MEMBER.FABRIC_ID, FABRIC_MEMBER.TRUSTED, FABRIC_MEMBER.MISSING, FABRIC_MEMBER.MISSING_TIME, FABRIC.MANAGED as FABRIC_MANAGED, FABRIC.PRINCIPAL_SWITCH_WWN, FABRIC.SEED_SWITCH_WWN from CORE_SWITCH, VIRTUAL_SWITCH, FABRIC_MEMBER, FABRIC where VIRTUAL_SWITCH.CORE_SWITCH_ID = CORE_SWITCH.ID and FABRIC_MEMBER.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID and FABRIC_MEMBER.FABRIC_ID = FABRIC.ID; DEVICE_INFO create or replace view DEVICE_INFO as select distinct...
Page 185: N2F_Port_Map_Info
Views SWITCH_PORT.ID as SWITCH_PORT_ID, SWITCH_PORT.WWN as SWITCH_PORT_WWN, SWITCH_PORT.NAME as SWITCH_PORT_NAME, SWITCH_PORT.SLOT_NUMBER, SWITCH_PORT.PORT_NUMBER, SWITCH_PORT.PORT_INDEX, SWITCH_PORT.TYPE as SWITCH_PORT_TYPE, SWITCH_PORT.FULL_TYPE as SWITCH_PORT_FULL_TYPE, SWITCH_PORT.STATUS as SWITCH_PORT_STATUS, SWITCH_PORT.HEALTH as SWITCH_PORT_HEALTH, SWITCH_PORT.SPEED, SWITCH_PORT.MAX_PORT_SPEED, SWITCH_PORT.NPIV, SWITCH_PORT.NPIV_CAPABLE, SWITCH_PORT.CALCULATED_STATUS, SWITCH_PORT.AREA_ID, SWITCH_PORT.PHYSICAL_PORT, SWITCH_PORT.CATEGORY, SWITCH_PORT.PERSISTENT_DISABLE, SWITCH_PORT.BLOCKED, SWITCH_PORT.FCR_INTEROP_MODE, SWITCH_INFO.IP_ADDRESS, SWITCH_INFO.PHYSICAL_SWITCH_WWN, SWITCH_INFO.FIRMWARE_VERSION, SWITCH_INFO.REACHABLE, SWITCH_INFO.SYSLOG_REGISTERED, SWITCH_INFO.SNMP_REGISTERED, SWITCH_INFO.ID as VIRTUAL_SWITCH_ID,...
Page 186: Device_Node_Info
Views N2F_PORT_MAP, SWITCH_PORT AG_N_PORT, SWITCH_PORT AG_F_PORT where N2F_PORT_MAP.VIRTUAL_SWITCH_ID = AG_N_PORT.VIRTUAL_SWITCH_ID and N2F_PORT_MAP.N_PORT = AG_N_PORT.USER_PORT_NUMBER and N2F_PORT_MAP.VIRTUAL_SWITCH_ID = AG_F_PORT.VIRTUAL_SWITCH_ID and N2F_PORT_MAP.F_PORT = AG_F_PORT.USER_PORT_NUMBER; DEVICE_NODE_INFO create or replace view DEVICE_NODE_INFO as select DEVICE_NODE.ID, DEVICE_NODE.FABRIC_ID, DEVICE_NODE.WWN, DEVICE_NODE.TYPE, DEVICE_NODE.DEVICE_TYPE, DEVICE_NODE.SYMBOLIC_NAME, DEVICE_NODE.FDMI_HOST_NAME, DEVICE_NODE.VENDOR, DEVICE_NODE.CAPABILITY_, DEVICE_NODE.TRUSTED, DEVICE_NODE.CREATION_TIME, DEVICE_NODE.MISSING, DEVICE_NODE.MISSING_TIME,...
Page 187 Views DEVICE_PORT.SYMBOLIC_NAME, DEVICE_PORT.FC4_TYPE, DEVICE_PORT.COS, DEVICE_PORT.IP_PORT, DEVICE_PORT.HARDWARE_ADDRESS, DEVICE_PORT.TRUSTED, DEVICE_PORT.CREATION_TIME, DEVICE_PORT.MISSING, DEVICE_PORT.MISSING_TIME, DEVICE_PORT.NPV_PHYSICAL, DEVICE_PORT.EDGE_SWITCH_PORT_WWN, FICON_DEVICE_PORT.TYPE_NUMBER, FICON_DEVICE_PORT.MODEL_NUMBER, FICON_DEVICE_PORT.MANUFACTURER, FICON_DEVICE_PORT.MANUFACTURER_PLANT, FICON_DEVICE_PORT.SEQUENCE_NUMBER, FICON_DEVICE_PORT.TAG, FICON_DEVICE_PORT.FLAG, FICON_DEVICE_PORT.PARAMS, USER_DEFINED_DEVICE_DETAIL.NAME, USER_DEFINED_DEVICE_DETAIL.TYPE as USER_DEFINED_TYPE, USER_DEFINED_DEVICE_DETAIL.IP_ADDRESS, USER_DEFINED_DEVICE_DETAIL.CONTACT, USER_DEFINED_DEVICE_DETAIL.LOCATION, USER_DEFINED_DEVICE_DETAIL.DESCRIPTION, USER_DEFINED_DEVICE_DETAIL.USER_DEFINED_VALUE1, USER_DEFINED_DEVICE_DETAIL.USER_DEFINED_VALUE2, USER_DEFINED_DEVICE_DETAIL.USER_DEFINED_VALUE3, DEVICE_NODE.WWN as DEVICE_NODE_WWN, DEVICE_NODE.FDMI_HOST_NAME, DEVICE_NODE.SYMBOLIC_NAME as DEVICE_SYMBOLIC_NAME, DEVICE_NODE.AG as AG_PORT, coalesce(SWITCH_PORT.NAME, VIRTUAL_FCOE_PORT.NAME) as SWITCH_PORT_NAME, coalesce (SWITCH_PORT.TYPE, VIRTUAL_FCOE_PORT.PORT_TYPE) as SWITCH_PORT_TYPE, SWITCH_PORT.LOGICAL_PORT_WWN,...
Page 188: Dev_Port_Gige_Port_Link_Info
Views DEV_PORT_GIGE_PORT_LINK_INFO create or replace view DEV_PORT_GIGE_PORT_LINK_INFO as select DEVICE_PORT_GIGE_PORT_LINK.DEVICE_PORT_ID, DEVICE_PORT_GIGE_PORT_LINK.GIGE_PORT_ID, DEVICE_PORT_GIGE_PORT_LINK.DIRECT_ATTACH, DEVICE_PORT.TRUSTED, DEVICE_PORT.CREATION_TIME, DEVICE_PORT.MISSING, DEVICE_PORT.MISSING_TIME from DEVICE_PORT_GIGE_PORT_LINK, DEVICE_PORT where DEVICE_PORT_GIGE_PORT_LINK.DEVICE_PORT_ID = DEVICE_PORT.ID; DEV_PORT_MAC_ADDR_MAP_INFO create or replace view DEV_PORT_MAC_ADDR_MAP_INFO as select DEVICE_PORT_MAC_ADDRESS_MAP.DEVICE_PORT_ID, DEVICE_PORT_MAC_ADDRESS_MAP.MAC_ADDRESS, DEVICE_NODE.ID as DEVICE_NODE_ID, DEVICE_NODE.FABRIC_ID, DEVICE_PORT.TRUSTED, DEVICE_PORT.CREATION_TIME, DEVICE_PORT.MISSING, DEVICE_PORT.MISSING_TIME from DEVICE_PORT_MAC_ADDRESS_MAP,...
Page 189: Event_Details_Info
Views ETHERNET_ISL, GIGE_PORT SOURCE_GIGE_PORT, VIRTUAL_SWITCH SOURCE_VIRTUAL_SWITCH, SWITCH_PORT SOURCE_SWITCH_PORT, GIGE_PORT DEST_GIGE_PORT, VIRTUAL_SWITCH DEST_VIRTUAL_SWITCH, SWITCH_PORT DEST_SWITCH_PORT where SOURCE_GIGE_PORT.ID = ETHERNET_ISL.SOURCE_PORT_ID and SOURCE_GIGE_PORT.SWITCH_PORT_ID = SOURCE_SWITCH_PORT.ID and SOURCE_SWITCH_PORT.VIRTUAL_SWITCH_ID = SOURCE_VIRTUAL_SWITCH.ID and DEST_GIGE_PORT.ID = ETHERNET_ISL.DEST_PORT_ID and DEST_GIGE_PORT.SWITCH_PORT_ID = DEST_SWITCH_PORT.ID and DEST_SWITCH_PORT.VIRTUAL_SWITCH_ID = DEST_VIRTUAL_SWITCH.ID; EVENT_DETAILS_INFO create or replace view EVENT_DETAILS_INFO as select EVENT.ID as ID, EVENT.ME_ID as ME_ID,...
Page 190: Event_Info
Views left outer join EVENT_ORIGIN on EVENT.EVENT_ORIGIN_ID = EVENT_ORIGIN.ID left outer join EVENT_CATEGORY on EVENT.EVENT_CATEGORY_ID = EVENT_CATEGORY.ID left outer join EVENT_MODULE on EVENT.EVENT_MODULE_ID = EVENT_MODULE.ID left outer join EVENT_DESCRIPTION on EVENT.EVENT_DESCRIPTION_ID = EVENT_DESCRIPTION.ID left outer join EVENT_DETAILS on EVENT.ID = EVENT_DETAILS.EVENT_ID left outer join EVENT_CALL_HOME on EVENT.ID = EVENT_CALL_HOME.EVENT_ID;...
Page 191: Fcip_Tunnel_Circuit_Info
Views FABRIC.CONTACT, FABRIC.LOCATION, FABRIC.DESCRIPTION, FABRIC.CREATION_TIME, FABRIC.LAST_SCAN_TIME, FABRIC.LAST_UPDATE_TIME, FABRIC.TRACK_CHANGES, FABRIC.TYPE, FABRIC.USER_DEFINED_VALUE_1, FABRIC.USER_DEFINED_VALUE_2, FABRIC.USER_DEFINED_VALUE_3, FABRIC.PRINCIPAL_SWITCH_WWN, FABRIC.ZONE_TRANSACTION_TIMEOUT, FABRIC.FABRIC_MODEL, FABRIC.ENHANCED_TI_ZONE_SUPPORT, VIRTUAL_SWITCH.ID as SEED_SWITCH_ID, VIRTUAL_SWITCH.VIRTUAL_FABRIC_ID, VIRTUAL_SWITCH.INTEROP_MODE, CORE_SWITCH.IP_ADDRESS as SEED_SWITCH_IP_ADDRESS, (select count(*) from FABRIC_MEMBER where FABRIC_MEMBER.FABRIC_ID = FABRIC.ID) as SWITCH_COUNT from FABRIC, CORE_SWITCH, VIRTUAL_SWITCH, FABRIC_MEMBER where FABRIC.SEED_SWITCH_WWN = VIRTUAL_SWITCH.WWN and VIRTUAL_SWITCH.CORE_SWITCH_ID = CORE_SWITCH.ID and FABRIC_MEMBER.FABRIC_ID = FABRIC.ID;...
Page 192: Fcip_Tunnel_Info
Views FCIP_TUNNEL_CIRCUIT.SECURITY_FLAG, FCIP_TUNNEL_CIRCUIT.DSCP_CONTROL, FCIP_TUNNEL_CIRCUIT.CIRCUIT_STATUS, FCIP_TUNNEL_CIRCUIT.ENABLED, FCIP_TUNNEL_CIRCUIT.MISMATCHED_CONFIGURATIONS, FCIP_TUNNEL_CIRCUIT.CIRCUIT_STATUS_STRING, FCIP_TUNNEL_CIRCUIT.L2COS_F_CLASS, FCIP_TUNNEL_CIRCUIT.L2_COS_HIGH, FCIP_TUNNEL_CIRCUIT.L2_COS_MEDIUM, FCIP_TUNNEL_CIRCUIT.L2_COS_LOW, FCIP_TUNNEL_CIRCUIT.DSCP_F_CLASS, FCIP_TUNNEL_CIRCUIT.DSCP_HIGH, FCIP_TUNNEL_CIRCUIT.DSCP_MEDIUM, FCIP_TUNNEL_CIRCUIT.DSCP_LOW, GIGE_PORT.PORT_NUMBER GIGE_PORT_NUMBER, GIGE_PORT.SLOT_NUMBER GIGE_PORT_SLOT_NUMBER, FCIP_CIRCUIT_PORT_MAP.SWITCH_PORT_ID GIGE_PORT_ID, SWITCH_PORT.VIRTUAL_SWITCH_ID, SWITCH_PORT.USER_PORT_NUMBER from FCIP_TUNNEL_CIRCUIT left outer join FCIP_CIRCUIT_PORT_MAP on FCIP_CIRCUIT_PORT_MAP.CIRCUIT_ID = FCIP_TUNNEL_CIRCUIT.ID left outer join GIGE_PORT on FCIP_CIRCUIT_PORT_MAP.SWITCH_PORT_ID = GIGE_PORT.ID left outer join SWITCH_PORT on GIGE_PORT.SWITCH_PORT_ID = SWITCH_PORT.ID;...
Page 193: Fcoe_Device_Info
Views FCIP_TUNNEL.FICON_TR_EMUL_ENABLED, FCIP_TUNNEL.FICON_DEBUG_FLAGS, FCIP_TUNNEL.REMOTE_WWN, FCIP_TUNNEL.CDC, FCIP_TUNNEL.ADMIN_STATUS, FCIP_TUNNEL.CONTROL_L2_COS, FCIP_TUNNEL.DSCP_CONTROL, FCIP_TUNNEL.TRUNKING_ALGORITHM, FCIP_TUNNEL.EXTENDED_TUNNEL, FCIP_TUNNEL.VIRTUAL_SWITCH_ID, FCIP_TUNNEL.CIRCUIT_COUNT, FCIP_TUNNEL.MISMATCHED_CONFIG_DETAILS, FCIP_TUNNEL.SLOT_NUMBER, FCIP_TUNNEL.FICON_ENABLED, FCIP_TUNNEL.TPERF_ENABLED, FCIP_TUNNEL.AUTH_KEY, FCIP_TUNNEL.CONNECTED_COUNT, FCIP_TUNNEL.TUNNEL_STATUS_STRING, FCIP_TUNNEL.COMPRESSION_MODE, FCIP_TUNNEL.TURBO_WRITE_ENABLED, FCIP_TUNNEL.TAPE_ACCELERATION_ENABLED, FCIP_TUNNEL.IPSEC_ENABLED, FCIP_TUNNEL.PRESHARED_KEY, PORT.WWN as VIRTUAL_PORT_WWN, PORT.REMOTE_PORT_WWN as REMOTE_PORT_WWN, PORT.REMOTE_NODE_WWN as REMOTE_NODE_WWN, PORT.ID as SWITCH_PORT_ID, PORT.PORT_NUMBER as SWITCH_PORT_NUMBER, PORT.USER_PORT_NUMBER as USER_PORT_NUMBER, PORT.PORT_INDEX, PORT.STATUS_MESSAGE from...
Page 194: Fru_Info
Views FRU_INFO create or replace view FRU_INFO as select FRU.ID, FRU.CORE_SWITCH_ID, FRU.TAG, FRU.PART_NUMBER, FRU.SERIAL_NUMBER, FRU.VENDOR_PART_NUMBER, FRU.VENDOR_SERIAL_NUMBER, FRU.CAN_BE_FRUED, FRU.SLOT_NUMBER, FRU.MANUFACTURER_DATE, FRU.UPDATE_DATE, FRU.VERSION, FRU.MANUFACTURER, FRU.VENDOR_EQUIPMENT_TYPE, FRU.OPERATIONAL_STATUS, FRU.TOTAL_OUTPUT_POWER, FRU.SPEED, FRU.CREATION_TIME, FRU.LAST_UPDATE_TIME, FRU.PREVIOUS_OP_STATUS, FRU.VENDOR, CORE_SWITCH.WWN as PHYSICAL_SWITCH_WWN, VIRTUAL_SWITCH.SWITCH_MODE as VIRTUAL_SWITCH_MODE from FRU, CORE_SWITCH, VIRTUAL_SWITCH where FRU.CORE_SWITCH_ID = CORE_SWITCH.ID and FRU.CORE_SWITCH_ID = VIRTUAL_SWITCH.CORE_SWITCH_ID;...
Page 195: Gige_Port_Info
Views GIGE_PORT.SWITCH_PORT_ID = SWITCH_PORT.ID and SWITCH_PORT.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID; GIGE_PORT_INFO create or replace view GIGE_PORT_INFO as select GIGE_PORT.ID, GIGE_PORT.SWITCH_PORT_ID, GIGE_PORT.PORT_NUMBER, GIGE_PORT.SLOT_NUMBER, GIGE_PORT.ENABLED, GIGE_PORT.SPEED, GIGE_PORT.MAX_SPEED, GIGE_PORT.MAC_ADDRESS, GIGE_PORT.PORT_NAME, GIGE_PORT.OPERATIONAL_STATUS, GIGE_PORT.LED_STATE, GIGE_PORT.SPEED_LED_STATE, GIGE_PORT.PORT_TYPE, GIGE_PORT.PERSISTENTLY_DISABLED, GIGE_PORT.INTERFACE_TYPE, GIGE_PORT.CHECKSUM, GIGE_PORT.FCIP_CAPABLE, GIGE_PORT.ISCSI_CAPABLE, GIGE_PORT.REMOTE_MAC_ADDRESS, GIGE_PORT.INBAND_MANAGEMENT_STATUS, GIGE_PORT.LAST_UPDATE, SWITCH_PORT.VIRTUAL_SWITCH_ID, SWITCH_PORT.USER_PORT_NUMBER, SWITCH_PORT.PORT_INDEX, VIRTUAL_SWITCH.WWN as VIRTUAL_SWITCH_WWN, CORE_SWITCH.WWN as PHYSICAL_SWITCH_WWN from...
Page 196 Views HBA_PORT.CNA_PORT_ID, HBA_PORT.PORT_NWWN, HBA_PORT.PHYSICAL_PORT_WWN, HBA_PORT.SWITCH_IP, HBA_PORT.PRINCIPAL_SWITCH_WWN, HBA_PORT.HBA_ID, HBA_PORT.PORT_NUMBER, HBA_PORT.NAME, HBA_PORT.FACTORY_PORT_WWN, HBA_PORT.FACTORY_NODE_WWN, HBA_PORT.PREBOOT_CREATED, HBA_PORT_DETAIL.PERSISTENT_BINDING, HBA_PORT_DETAIL.FABRIC_NAME, HBA_PORT_DETAIL.BOOT_OVER_SAN, HBA_PORT_DETAIL.BOOT_OPTION, HBA_PORT_DETAIL.BOOT_SPEED, HBA_PORT_DETAIL.BOOT_TOPOLOGY, HBA_PORT_DETAIL.BB_CREDIT, HBA_PORT_DETAIL.FRAME_DATA_FIELD_SIZE, HBA_PORT_DETAIL.HARDWARE_PATH, HBA_PORT_DETAIL.V_PORT_COUNT, HBA_PORT_DETAIL.QUEUE_DEPTH, HBA_PORT_DETAIL.INTERRUPT_CONTROL_COALESCE, HBA_PORT_DETAIL.INTERRUPT_CONTROL_LATENCY, HBA_PORT_DETAIL.INTERRUPT_CONTROL_DELAY, HBA_PORT_DETAIL.BEACON_STATE, HBA_PORT_DETAIL.LINK_BEACON_STATE, HBA_PORT_DETAIL.MPIO_MODE_STATE, HBA_PORT_DETAIL.PATH_TIME_OUT, HBA_PORT_DETAIL.LOGGING_LEVEL, HBA_PORT_DETAIL.TARGET_RATE_LIMIT, HBA_PORT_DETAIL.DEFAULT_RATE_LIMIT, HBA_PORT_DETAIL.VF_MODE, HBA_PORT_DETAIL.RECIEVE_BUFFER_CREDIT, HBA_PORT_DETAIL.TRANSMIT_BUFFER_CREDIT, HBA_PORT_DETAIL.FCSP_AUTH_STATE, HBA_PORT_DETAIL.FCSP_STATUS, HBA_PORT_DETAIL.FCSP_ALGORITHM, HBA_PORT_DETAIL.FCSP_GROUP, HBA_PORT_DETAIL.FCSP_ERROR_STATUS, HBA_PORT_DETAIL.QOS_CONFIGURED_STATE, HBA_PORT_DETAIL.QOS_OPERATING_STATE,...
Page 197: Hba_Target_Info
Views HBA_PORT_FCOE_DETAILS.MAX_FRAME_SIZE as FCOE_MAX_FRAME_SIZE, HBA_PORT_FCOE_DETAILS.MTU as FCOE_MTU, HBA_PORT_FCOE_DETAILS.PATH_TOV as FCOE_PATH_TOV, HBA_PORT_FCOE_DETAILS.SCSI_QUEUE_DEPTH as FCOE_SCSI_QUEUE_DEPTH, HBA_PORT_FCOE_DETAILS.STATE as FCOE_STATE, HBA_PORT_FCOE_DETAILS.SUPPORTED_CLASS as FCOE_SUPPORTED_CLASS, HBA_PORT_FCOE_DETAILS.TRL_SPEED as FCOE_TRL_SPEED, HBA_PORT_FCOE_DETAILS.TRL_STATE as FCOE_TRL_STATE, HBA_PORT_FCOE_DETAILS.PG_ID as FCOE_PG_ID, HBA_PORT_FCOE_DETAILS.PRIORITIES as FCOE_PRIORITIES, HBA_PORT_FCOE_DETAILS.FCOE_MAC from HBA_PORT left outer join HBA_PORT_DETAIL on HBA_PORT.DEVICE_PORT_ID = HBA_PORT_DETAIL.DEVICE_PORT_ID left outer join HBA_PORT_FCOE_DETAILS on HBA_PORT.DEVICE_PORT_ID = HBA_PORT_FCOE_DETAILS.DEVICE_PORT_ID;...
Page 198: Host_Discovery_Request_Info
Views HBA_REMOTE_PORT_LUN.TARGET_WWN, HBA_REMOTE_PORT_LUN.PHYSICAL_LUN, HBA_REMOTE_PORT_LUN.LUN_ID, HBA_REMOTE_PORT.FCP_IM_STATE, HBA_REMOTE_PORT.IO_LATENCY_MIN, HBA_REMOTE_PORT.IO_LATENCY_MAX, HBA_REMOTE_PORT.IO_LATENCY_AVERAGE, HBA_REMOTE_PORT.DATA_RETRANSMISSION_SUPPORT, HBA_REMOTE_PORT.REC_SUPPORT, HBA_REMOTE_PORT.TASK_RENTRY_IDENT_SUPPORT, HBA_REMOTE_PORT.CONFIRMED_COMPLETIONS_SUPPORT from HBA_TARGET, HBA_REMOTE_PORT, HBA_REMOTE_PORT_LUN where HBA_TARGET.HBA_REMOTE_PORT_LUN_ID = HBA_REMOTE_PORT_LUN.ID and HBA_REMOTE_PORT.ID = HBA_REMOTE_PORT_LUN.HBA_REMOTE_PORT_ID; HOST_DISCOVERY_REQUEST_INFO create or replace view HOST_DISCOVERY_REQUEST_INFO as select HOST_DISCOVERY_REQUEST.ID, HOST_DISCOVERY_REQUEST.HOST_NAME AS REQUEST_HOST_NAME, HOST_DISCOVERY_REQUEST.DEVICE_ENCLOSURE_ID, HOST_DISCOVERY_REQUEST.REQUEST_GROUP_ID, HOST_DISCOVERY_REQUEST.HOST_DISCOVERY_OPTION_ID, HOST_DISCOVERY_REQUEST.VM_MANAGEMENT_STATE, HOST_DISCOVERY_REQUEST.JSON_MANAGEMENT_STATE, HOST_DISCOVERY_REQUEST.CIM_MANAGEMENT_STATE, HOST_DISCOVERY_REQUEST.MANAGEMENT_STATE,...
Page 199: Ifl_Info
Views DEVICE_ENCLOSURE.SERIAL_NUMBER, DEVICE_ENCLOSURE.FIRMWARE, DEVICE_ENCLOSURE.USER_DEFINED_VALUE1, DEVICE_ENCLOSURE.USER_DEFINED_VALUE2, DEVICE_ENCLOSURE.USER_DEFINED_VALUE3, DEVICE_ENCLOSURE.HCM_AGENT_VERSION, DEVICE_ENCLOSURE.OS_VERSION, DEVICE_ENCLOSURE.CREATED_BY, DEVICE_ENCLOSURE.TRACK_CHANGES, DEVICE_ENCLOSURE.LAST_UPDATE_TIME, DEVICE_ENCLOSURE.LAST_UPDATE_MODULE, DEVICE_ENCLOSURE.TRUSTED, DEVICE_ENCLOSURE.CREATION_TIME, DEVICE_ENCLOSURE.MISSING, DEVICE_ENCLOSURE.MISSING_TIME, DEVICE_ENCLOSURE.HOST_NAME, DEVICE_ENCLOSURE.SYSLOG_REGISTERED, DEVICE_ENCLOSURE.VIRTUALIZATION, DEVICE_ENCLOSURE.MANAGED_ELEMENT_ID from HOST_DISCOVERY_REQUEST join HOST_DISCOVERY_OPTION on HOST_DISCOVERY_REQUEST.HOST_DISCOVERY_OPTION_ID = HOST_DISCOVERY_OPTION.ID left outer join DEVICE_ENCLOSURE on HOST_DISCOVERY_REQUEST.DEVICE_ENCLOSURE_ID = DEVICE_ENCLOSURE.ID; IFL_INFO create or replace view IFL_INFO as select IFL.ID as IFL_ID, IFL.EDGE_FABRIC_ID,...
Page 200: Isl_Trunk_Info
Views ISL.SOURCE_DOMAIN_ID, ISL.SOURCE_PORT_NUMBER, ISL.MISSING, SOURCE_VIRTUAL_SWITCH.ID as SOURCE_SWITCH_ID, SOURCE_VIRTUAL_SWITCH.NAME as SOURCE_SWITCH_NAME, SOURCE_VIRTUAL_SWITCH.WWN as SOURCE_SWITCH_WWN, SOURCE_VIRTUAL_SWITCH.CORE_SWITCH_ID as SOURCE_CORE_SWITCH_ID, SOURCE_VIRTUAL_SWITCH.BASE_SWITCH as SOURCE_BASE_SWITCH, SOURCE_SWITCH_PORT.ID as SOURCE_SWITCH_PORT_ID, SOURCE_SWITCH_PORT.WWN as SOURCE_SWITCH_PORT_WWN, SOURCE_SWITCH_PORT.NAME as SOURCE_SWITCH_PORT_NAME, SOURCE_SWITCH_PORT.TYPE as PORT_TYPE, SOURCE_SWITCH_PORT.KIND as SOURCE_SWITCH_PORT_KIND, SOURCE_SWITCH_PORT.PHYSICAL_PORT as SOURCE_PHYSICAL_PORT, SOURCE_SWITCH_PORT.TRUNKED as SOURCE_SWITCH_PORT_TRUNKED, ISL.DEST_DOMAIN_ID, ISL.DEST_PORT_NUMBER, DEST_VIRTUAL_SWITCH.ID as DEST_SWITCH_ID,...
Page 201: Nport_Wwn_Map_Info
Views ISL_INFO.TYPE, ISL_INFO.SOURCE_PORT_NUMBER, ISL_INFO.SOURCE_SWITCH_ID, SOURCE_CORE_SWITCH.IP_ADDRESS as SOURCE_SWITCH_IP_ADDRESS, SOURCE_VIRTUAL_SWITCH.WWN as SOURCE_SWITCH_WWN, ISL_INFO.SOURCE_DOMAIN_ID as MASTER_PORT, ISL_INFO.SOURCE_SWITCH_NAME, ISL_INFO.SOURCE_SWITCH_PORT_ID, ISL_INFO.DEST_PORT_NUMBER, ISL_INFO.DEST_SWITCH_ID, DEST_CORE_SWITCH.IP_ADDRESS as DEST_SWITCH_IP_ADDRESS, DEST_VIRTUAL_SWITCH.WWN as DEST_SWITCH_WWN, ISL_INFO.SOURCE_SWITCH_PORT_WWN, ISL_INFO.DEST_DOMAIN_ID as REMOTE_MASTER_PORT, ISL_INFO.DEST_SWITCH_NAME, ISL_INFO.DEST_SWITCH_PORT_ID from ISL_TRUNK_GROUP, ISL_INFO, CORE_SWITCH SOURCE_CORE_SWITCH, CORE_SWITCH DEST_CORE_SWITCH, VIRTUAL_SWITCH SOURCE_VIRTUAL_SWITCH, VIRTUAL_SWITCH DEST_VIRTUAL_SWITCH where ISL_INFO.SOURCE_SWITCH_ID = ISL_TRUNK_GROUP.VIRTUAL_SWITCH_ID and ISL_INFO.SOURCE_PORT_NUMBER = ISL_TRUNK_GROUP.MASTER_USER_PORT...
Page 202: Phantom_Port_Info
Views PHANTOM_PORT_INFO create or replace view PHANTOM_PORT_INFO as select PHANTOM_PORT.ID, PHANTOM_PORT.WWN, PHANTOM_PORT.VIRTUAL_SWITCH_ID, PHANTOM_PORT.PORT_NUMBER, PHANTOM_PORT.PORT_ID, PHANTOM_PORT.SPEED, PHANTOM_PORT.MAX_SPEED, PHANTOM_PORT.TYPE, PHANTOM_PORT.REMOTE_NODE_WWN, PHANTOM_PORT.REMOTE_PORT_WWN, PHANTOM_PORT.PHANTOM_TYPE, PHANTOM_PORT.BB_FABRIC_ID, VIRTUAL_SWITCH.WWN as VIRTUAL_SWITCH_WWN from PHANTOM_PORT, VIRTUAL_SWITCH where PHANTOM_PORT.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID; PORT_BOTTLENECK_CONF_INFO This view provides combine port bottleneck configuration and enough information from switch port for the client to identify the port.
Page 203: Port_Group_Info
Views SWITCH_PORT.VIRTUAL_SWITCH_ID, SWITCH_PORT.USER_PORT_NUMBER, SWITCH_PORT.TYPE from PORT_BOTTLENECK_STATUS left outer join SWITCH_PORT on PORT_BOTTLENECK_STATUS.SWITCH_PORT_ID = SWITCH_PORT.ID; PORT_GROUP_INFO create or replace view PORT_GROUP_INFO as select SWITCH_PORT.ID as PORT_ID, SWITCH_PORT.NAME as SWITCH_PORT_NAME, SWITCH_PORT.WWN, SWITCH_PORT.HEALTH, SWITCH_PORT.STATUS, SWITCH_PORT.PORT_NUMBER, SWITCH_PORT.SLOT_NUMBER, SWITCH_PORT.FICON_SUPPORTED, SWITCH_PORT.STATE, SWITCH_PORT.USER_PORT_NUMBER, VIRTUAL_SWITCH.NAME as VIRTUAL_SWITCH_NAME, VIRTUAL_SWITCH.ID as SWITCH_ID, FABRIC.NAME as FABRIC_NAME, FABRIC.MANAGED as FABRIC_MANAGED, PORT_GROUP.ID as PORT_GROUP_ID,...
Page 204: Scom_Ee_Monitor_Info
Views SCOM_EE_MONITOR_INFO This view provides combined ee_monitor, ee_monitor_stats, device_port and device_node tables to get the EE Monitor information for SCOM plug-in. create or replace view SCOM_EE_MONITOR_INFO as select distinct EE_MONITOR.NAME, EE_MONITOR.SWITCH_PORT_ID, EE_MONITOR.SOURCE_PORT_ID, EE_MONITOR.DEST_PORT_ID, EE_MONITOR_STATS.TX, EE_MONITOR_STATS.RX, EE_MONITOR_STATS.CRCERRORS, EE_MONITOR_STATS.CREATION_TIME, SOURCE_PORT.PORT_ID as SID, DEST_PORT.PORT_ID as DID, SOURCE_NODE.WWN as SOURCE_DEVICE_WWN, SOURCE_PORT.WWN as SOURCE_PORT_WWN,...
Page 205: Smart_Card_Usage_Info
Views SENSOR.VERSION, SENSOR.CREATION_TIME, SENSOR.LAST_UPDATE_TIME, SENSOR.FRU_TYPE, SENSOR.UNIT_NUMBER, SENSOR.STATE, CORE_SWITCH.WWN as PHYSICAL_SWITCH_WWN, VIRTUAL_SWITCH.SWITCH_MODE as VIRTUAL_SWITCH_MODE from SENSOR, CORE_SWITCH, VIRTUAL_SWITCH where SENSOR.CORE_SWITCH_ID = CORE_SWITCH.ID and SENSOR.CORE_SWITCH_ID = VIRTUAL_SWITCH.CORE_SWITCH_ID; SMART_CARD_USAGE_INFO create or replace view SMART_CARD_USAGE_INFO as select SC.ID SMART_CARD_ID, SC.CARD_TYPE, SC.CARD_INFO, SC.CARDCN_ID, SC.FIRST_NAME, SC.LAST_NAME, SC.NOTES, SC.CREATION_TIME, -1 ENGINE_ID,...
Page 206: Switch_Details_Info
Views SMART_CARD SC, ENCRYPTION_GROUP EG, RECOVERY_CARD_GROUP_MAPPING RCGM where SC.ID = RCGM.SMART_CARD_ID and EG.ID = RCGM.ENCRYPTION_GROUP_ID and SC.CARD_TYPE = 1 union select SC.ID SMART_CARD_ID, SC.CARD_TYPE, SC.CARD_INFO, SC.CARDCN_ID, SC.FIRST_NAME, SC.LAST_NAME, SC.NOTES, SC.CREATION_TIME, EE.ID ENGINE_ID, -1 ENCRYPTION_GROUP_ID, '' GROUP_NAME, -1 CARD_POSITION, EE.SWITCH_ID CRYPTO_SWITCH_ID, EE.SLOT_NUMBER SLOT_NUMBER from SMART_CARD SC,...
Page 207 Views CORE_SWITCH.NAT_PRIVATE_IP_ADDRESS, CORE_SWITCH.ALTERNATE_IP_ADDRESS, VIRTUAL_SWITCH.ID, VIRTUAL_SWITCH.NAME, VIRTUAL_SWITCH.OPERATIONAL_STATUS, VIRTUAL_SWITCH.SWITCH_MODE, VIRTUAL_SWITCH.AD_CAPABLE, VIRTUAL_SWITCH.WWN, VIRTUAL_SWITCH.ROLE, VIRTUAL_SWITCH.FCS_ROLE, VIRTUAL_SWITCH.DOMAIN_ID, VIRTUAL_SWITCH.VIRTUAL_FABRIC_ID, VIRTUAL_SWITCH.BASE_SWITCH, VIRTUAL_SWITCH.MAX_ZONE_CONFIG_SIZE, VIRTUAL_SWITCH.CREATION_TIME, VIRTUAL_SWITCH.LAST_UPDATE_TIME, VIRTUAL_SWITCH.USER_NAME, VIRTUAL_SWITCH.PASSWORD, VIRTUAL_SWITCH.MANAGEMENT_STATE, VIRTUAL_SWITCH.STATE, VIRTUAL_SWITCH.STATUS, VIRTUAL_SWITCH.STATUS_REASON, VIRTUAL_SWITCH.FABRIC_IDID_MODE, VIRTUAL_SWITCH.LOGICAL_ID, VIRTUAL_SWITCH.USER_DEFINED_VALUE_1, VIRTUAL_SWITCH.USER_DEFINED_VALUE_2, VIRTUAL_SWITCH.USER_DEFINED_VALUE_3, VIRTUAL_SWITCH.FMS_MODE, VIRTUAL_SWITCH.DYNAMIC_LOAD_SHARING, VIRTUAL_SWITCH.PORT_BASED_ROUTING, VIRTUAL_SWITCH.IN_ORDER_DELIVERY, VIRTUAL_SWITCH.INSISTENT_DID_MODE, VIRTUAL_SWITCH.FCR_CAPABLE, VIRTUAL_SWITCH.LAST_PORT_MEMBERSHIP_CHANGE, VIRTUAL_SWITCH.FCIP_CIRCUIT_CAPABLE, VIRTUAL_SWITCH.MAX_FCIP_TUNNELS, VIRTUAL_SWITCH.MAX_FCIP_CIRCUITS, VIRTUAL_SWITCH.FCIP_LICENSED, VIRTUAL_SWITCH.MANAGED_ELEMENT_ID, FABRIC_MEMBER.FABRIC_ID, FABRIC_MEMBER.TRUSTED, FABRIC_MEMBER.MISSING,...
Page 208: Switch_Port_Info
Views CORE_SWITCH_DETAILS.TAG, CORE_SWITCH_DETAILS.ACT_CP_PRI_FW_VERSION, CORE_SWITCH_DETAILS.ACT_CP_SEC_FW_VERSION, CORE_SWITCH_DETAILS.STBY_CP_PRI_FW_VERSION, CORE_SWITCH_DETAILS.STBY_CP_SEC_FW_VERSION, CORE_SWITCH_DETAILS.TYPE as DETAILS_TYPE, CORE_SWITCH_DETAILS.EGM_CAPABLE, CORE_SWITCH_DETAILS.SUB_TYPE, CORE_SWITCH_DETAILS.PARTITION, CORE_SWITCH_DETAILS.MAX_NUM_OF_BLADES, CORE_SWITCH_DETAILS.SNMP_INFORMS_ENABLED, CORE_SWITCH_DETAILS.VENDOR_VERSION, CORE_SWITCH_DETAILS.VENDOR_PART_NUMBER, CORE_SWITCH_DETAILS.CONTACT, CORE_SWITCH_DETAILS.LOCATION, CORE_SWITCH_DETAILS.DESCRIPTION, CORE_SWITCH_DETAILS.RNID_SEQUENCE_NUMBER, CORE_SWITCH_DETAILS.FIRMWARE_VERSION as CSD_FIRMWARE_VERSION from CORE_SWITCH, VIRTUAL_SWITCH, FABRIC_MEMBER, CORE_SWITCH_DETAILS where VIRTUAL_SWITCH.CORE_SWITCH_ID = CORE_SWITCH.ID and FABRIC_MEMBER.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID and CORE_SWITCH_DETAILS.CORE_SWITCH_ID = CORE_SWITCH.ID; SWITCH_PORT_INFO create or replace view SWITCH_PORT_INFO as select...
Page 209 Views SWITCH_PORT.ACTUAL_DISTANCE, SWITCH_PORT.LONG_DISTANCE_SETTING, SWITCH_PORT.DEGRADED_PORT, SWITCH_PORT.REMOTE_NODE_WWN, SWITCH_PORT.REMOTE_PORT_WWN, SWITCH_PORT.LICENSED, SWITCH_PORT.SWAPPED, SWITCH_PORT.TRUNKED, SWITCH_PORT.TRUNK_MASTER, SWITCH_PORT.PERSISTENT_DISABLE, SWITCH_PORT.FICON_SUPPORTED, SWITCH_PORT.BLOCKED, SWITCH_PORT.PROHIBIT_PORT_NUMBERS, SWITCH_PORT.PROHIBIT_PORT_COUNT, SWITCH_PORT.NPIV, SWITCH_PORT.NPIV_CAPABLE, SWITCH_PORT.NPIV_ENABLED, SWITCH_PORT.FC_FAST_WRITE_ENABLED, SWITCH_PORT.ISL_RRDY_ENABLED, SWITCH_PORT.RATE_LIMIT_CAPABLE, SWITCH_PORT.RATE_LIMITED, SWITCH_PORT.QOS_CAPABLE, SWITCH_PORT.QOS_ENABLED, SWITCH_PORT.TUNNEL_CONFIGURED, SWITCH_PORT.FCIP_TUNNEL_UP, SWITCH_PORT.FCR_FABRIC_ID, SWITCH_PORT.FCR_INTEROP_MODE, SWITCH_PORT.CALCULATED_STATUS, SWITCH_PORT.USER_DEFINED_VALUE1, SWITCH_PORT.USER_DEFINED_VALUE2, SWITCH_PORT.USER_DEFINED_VALUE3, SWITCH_PORT.KIND, SWITCH_PORT.STATE, SWITCH_PORT.PREVIOUS_STATUS, SWITCH_PORT.LAST_UPDATE, SWITCH_PORT.OCCUPIED, SWITCH_PORT.PORT_BIT_MASK, SWITCH_PORT.LOGICAL_PORT_NUMBER, SWITCH_PORT.DEFAULT_AREA_ID, SWITCH_PORT.LOGICAL_PORT_WWN, SWITCH_PORT.LATENCY_DETECT_SUPPORTED, SWITCH_PORT.EPORT_DISABLED,...
Page 210: Switch_Snmp_Info
Views SWITCH_SNMP_INFO create or replace view SWITCH_SNMP_INFO as select CORE_SWITCH.ID as PHYSICAL_SWITCH_ID, CORE_SWITCH.NAME as PHYSICAL_SWITCH_NAME, CORE_SWITCH.IP_ADDRESS, CORE_SWITCH.WWN as PHYSICAL_SWITCH_WWN, CORE_SWITCH.OPERATIONAL_STATUS as PHYSICAL_OPERATIONAL_STATUS, CORE_SWITCH.TYPE, CORE_SWITCH.MAX_VIRTUAL_SWITCHES, CORE_SWITCH.FIRMWARE_VERSION, CORE_SWITCH.VENDOR, CORE_SWITCH.REACHABLE, CORE_SWITCH.UNREACHABLE_TIME, CORE_SWITCH.MODEL, CORE_SWITCH_DETAILS.CONTACT, CORE_SWITCH_DETAILS.LOCATION, CORE_SWITCH_DETAILS.DESCRIPTION, VIRTUAL_SWITCH.ID, VIRTUAL_SWITCH.NAME, VIRTUAL_SWITCH.OPERATIONAL_STATUS, VIRTUAL_SWITCH.SWITCH_MODE, VIRTUAL_SWITCH.AD_CAPABLE, VIRTUAL_SWITCH.FCIP_CAPABLE, VIRTUAL_SWITCH.WWN, VIRTUAL_SWITCH.ROLE, VIRTUAL_SWITCH.FCS_ROLE, VIRTUAL_SWITCH.DOMAIN_ID, VIRTUAL_SWITCH.VIRTUAL_FABRIC_ID,...
Page 211: User_Role_Resource_Info
Views coalesce(SNMP_CREDENTIALS.WRITE_COMMUNITY_STRING, (select SNMP_PROFILE.WRITE_COMMUNITY_STRING from SNMP_PROFILE where SNMP_PROFILE.NAME='default')) as SNMP_WRITE_COMMUNITY_STRING, coalesce(SNMP_CREDENTIALS.USER_NAME, (select SNMP_PROFILE.USER_NAME from SNMP_PROFILE where SNMP_PROFILE.NAME='default')) as SNMP_USER_NAME, coalesce(SNMP_CREDENTIALS.CONTEXT_NAME, (select SNMP_PROFILE.CONTEXT_NAME from SNMP_PROFILE where SNMP_PROFILE.NAME='default')) as SNMP_CONTEXT_NAME, coalesce(SNMP_CREDENTIALS.AUTH_PROTOCOL, (select SNMP_PROFILE.AUTH_PROTOCOL from SNMP_PROFILE where SNMP_PROFILE.NAME='default')) as SNMP_AUTH_PROTOCOL, coalesce(SNMP_CREDENTIALS.AUTH_PASSWORD, (select SNMP_PROFILE.AUTH_PASSWORD from SNMP_PROFILE where SNMP_PROFILE.NAME='default')) as SNMP_AUTH_PASSWORD, coalesce(SNMP_CREDENTIALS.PRIV_PROTOCOL, (select SNMP_PROFILE.PRIV_PROTOCOL from SNMP_PROFILE where SNMP_PROFILE.NAME='default')) as SNMP_PRIV_PROTOCOL,...
Page 212: Vm_Connectivity_Info
Views VIRTUAL_FCOE_PORT.PORT_TYPE, VIRTUAL_FCOE_PORT.ENABLED, VIRTUAL_FCOE_PORT.STATUS, VIRTUAL_FCOE_PORT.TRUNK_INDEX, VIRTUAL_FCOE_PORT.PORT_NUMBER, VIRTUAL_FCOE_PORT.NAME, VIRTUAL_FCOE_PORT.SLOT_NUMBER, VIRTUAL_FCOE_PORT.VLAN_ID, VIRTUAL_FCOE_PORT.DEVICE_COUNT, VIRTUAL_FCOE_PORT.PEER_MAC, VIRTUAL_SWITCH.WWN as VIRTUAL_SWITCH_WWN, VIRTUAL_SWITCH.ROLE as SWITCH_ROLE, VIRTUAL_SWITCH.VIRTUAL_FABRIC_ID as VIRTUAL_FABRIC_ID, VIRTUAL_SWITCH.DOMAIN_ID as DOMAIN_ID, VIRTUAL_SWITCH.INTEROP_MODE as INTEROP_MODE, CORE_SWITCH.TYPE as SWITCH_TYPE, CORE_SWITCH.FIRMWARE_VERSION as FIRMWARE_VERSION, CORE_SWITCH.IP_ADDRESS as IP_ADDRESS, CORE_SWITCH.WWN as PHYSICAL_SWITCH_WWN, CORE_SWITCH.MODEL as SWITCH_MODEL, CORE_SWITCH_DETAILS.MODEL_NUMBER as SWITCH_MODEL_NUMBER from VIRTUAL_FCOE_PORT, CORE_SWITCH, VIRTUAL_SWITCH, CORE_SWITCH_DETAILS...
Page 213 Views from DEVICE_PORT left outer join USER_DEFINED_DEVICE_DETAIL on DEVICE_PORT.WWN = USER_DEFINED_DEVICE_DETAIL.WWN, CORE_SWITCH, SWITCH_PORT, VIRTUAL_SWITCH, VM_CONNECTIVITY, DEVICE_NODE, FABRIC where VM_CONNECTIVITY.ADAPTER_PORT_WWN = DEVICE_PORT.WWN and DEVICE_PORT.SWITCH_PORT_WWN = SWITCH_PORT.WWN and SWITCH_PORT.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID and VIRTUAL_SWITCH.CORE_SWITCH_ID = CORE_SWITCH.ID and DEVICE_PORT.NODE_ID = DEVICE_NODE.ID and DEVICE_NODE.FABRIC_ID = FABRIC.ID union all select DEVICE_PORT.SWITCH_PORT_WWN,...
Page 214: Vm_Ee_Monitor_Info
Views and SWITCH_PORT.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID and VIRTUAL_SWITCH.CORE_SWITCH_ID = CORE_SWITCH.ID and DEVICE_PORT.NODE_ID = DEVICE_NODE.ID and DEVICE_NODE.FABRIC_ID = FABRIC.ID; VM_EE_MONITOR_INFO This view provides combined ee_monitor, ee_monitor_stats, device_port and device_node tables to get the EE Monitor information for vmplug-in. create or replace view VM_EE_MONITOR_INFO as select distinct EE_MONITOR.NAME, EE_MONITOR.SWITCH_PORT_ID,...
Page 215: Vm_Lun_Info
Views VM_HOST.CPU_COUNT, VM_HOST.CPU_TYPE, VM_HOST.CPU_RESOURCES as HOST_CPU_RESOURCES, VM_HOST.MEM_RESOURCES as HOST_MEM_RESOURCES, VM_HOST.LICENSE_SERVER, VM_HOST.BOOT_TIME as HOST_BOOT_TIME, CLUSTER.NAME as CLUSTER_NAME, CLUSTER.IP_ADDRESS as CLUSTER_ADDRESS, VIRTUAL_MACHINE.ID as VM_ID, VIRTUAL_MACHINE.HYPERVISOR_VM_ID, VIRTUAL_MACHINE.NAME as VM_NAME, VIRTUAL_MACHINE.DESCRIPTION as VM_DESCRIPTION, VIRTUAL_MACHINE.OS as VM_OS, VIRTUAL_MACHINE.STATUS as VM_STATUS, VIRTUAL_MACHINE.VCPU_COUNT, VIRTUAL_MACHINE.CPU_RESOURCES as VM_CPU_RESOURCES, VIRTUAL_MACHINE.MEM_RESOURCES as VM_MEM_RESOURCES, VIRTUAL_MACHINE.IP_ADDRESS as VM_IP_ADDRESS,...
Page 216: Vm_Statistics_Info
Views VM_PATH.ACTIVE as PATH_ACTIVE, VM_PATH.PREFERRED as PATH_PREFERRED from VM_LUN join VM_PATH on VM_LUN.ID = VM_PATH.LUN_ID; VM_STATISTICS_INFO This view gets the FC port statistics for the VM Connectivity data. create or replace view VM_STATISTICS_INFO as select distinct DEVICE_PORT.SWITCH_PORT_WWN, DEVICE_PORT.DOMAIN_ID, VM_CONNECTIVITY.HYPERVISOR_HOST, VM_CONNECTIVITY.ADAPTER_PORT_WWN, VM_CONNECTIVITY.ADAPTER_PORT_STATUS, VM_CONNECTIVITY.HYPERVISOR_VM_ID, VM_CONNECTIVITY.VM_NAME,...
Page 217: Zone_Db_Info
Views CORE_SWITCH.NAME as CORE_NAME, SWITCH_TE_PORT_STATS.TRANSMIT_OK, SWITCH_TE_PORT_STATS.RECEIVE_OK, SWITCH_TE_PORT_STATS.TRANSMIT_OK_PERCENT_UTIL, SWITCH_TE_PORT_STATS.RECEIVE_OK_PERCENT_UTIL, -1,-1,-1,-1,-1, SWITCH_TE_PORT_STATS.CREATION_TIME, VIRTUAL_SWITCH.NAME as VIRTUAL_NAME, SWITCH_PORT.STATUS as SWITCH_PORT_STATUS, SWITCH_PORT.PORT_ID, SWITCH_PORT.PORT_NUMBER from DEVICE_PORT, VM_CONNECTIVITY, SWITCH_PORT, CORE_SWITCH, SWITCH_TE_PORT_STATS, VIRTUAL_SWITCH, DEVICE_PORT_MAC_ADDRESS_MAP, DEVICE_PORT_GIGE_PORT_LINK, GIGE_PORT where VM_CONNECTIVITY.ADAPTER_PORT_WWN = DEVICE_PORT.WWN and DEVICE_PORT.ID = DEVICE_PORT_MAC_ADDRESS_MAP.DEVICE_PORT_ID and DEVICE_PORT_MAC_ADDRESS_MAP.MAC_ADDRESS = GIGE_PORT.REMOTE_MAC_ADDRESS and GIGE_PORT.SWITCH_PORT_ID = SWITCH_TE_PORT_STATS.PORT_ID and GIGE_PORT.SWITCH_PORT_ID = SWITCH_PORT.ID and SWITCH_PORT.VIRTUAL_SWITCH_ID = VIRTUAL_SWITCH.ID...
Page 218 Views ZONE_DB.ID = ZONE_DB_CONFIG.ZONE_DB_ID; -- Name: access_control_entry; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE access_control_entry ( access_control_entry_id integer NOT NULL, access_control_list_id integer NOT NULL, sequence_num numeric(8,0) NOT NULL, is_permit numeric(1,0), is_log numeric(1,0), comments character varying(256), table_subtype character varying(32) NOT NULL -- Name: access_control_group;...
Page 219 Views -- Name: accessible_port_group; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE accessible_port_group ( accessible_entity_id integer NOT NULL, port_group_id integer -- Name: accessible_vip_server; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE accessible_vip_server ( accessible_entity_id integer NOT NULL, server_ip character varying(39) NOT NULL, server_mode character varying(39) NOT NULL, server_iron_ip character varying(39) -- Name: acl_spec;...
Page 220 Views -- Name: address_spec; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE address_spec ( address_spec_id integer NOT NULL, table_subtype character varying(32) NOT NULL -- Name: alert; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE alert ( alert_id integer NOT NULL, name character varying(32) NOT NULL, user_id integer NOT NULL, description character varying(255),...
Page 221 Views macaddr character varying(17), authenticated smallint, associated smallint, forwarding smallint, lastkeytype smallint, manualblock smallint, dynamicblock smallint, attemptsconsumed integer, attemptsremained integer, remainedcycletime integer, remainedblocktime integer -- Name: ap_ids_last_saved; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE ap_ids_last_saved ( device_id integer NOT NULL, time_stamp bigint NOT NULL -- Name: ap_ids_sqnum_seq;...
Page 222 Views authenticated smallint, associated smallint, isforwarding smallint, keytype smallint, lastauthenticatedtime bigint, associatedtime bigint, lastassociatedtime bigint, lastdisassociatedtime bigint, txpacketcount bigint, rxpacketcount bigint, txbytecount bigint, rxbytecount bigint, time_interval bigint, radio smallint, channel smallint -- Name: ap_station_last_saved; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE ap_station_last_saved ( device_id integer NOT NULL,...
Page 223 Views -- Name: block_mac_list; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE block_mac_list ( block_mac_list_id integer NOT NULL, mac character varying(32) NOT NULL, radio_vap numeric(2,0), lockout_time character varying(64), last_seen_ap_id integer, last_time_seen character varying(64), device_group_id integer, is_full_device_group numeric(1,0), deployment_setting_id integer -- Name: cfg_backup_archive;...
Page 224 Views -- Name: cfg_restore_backup_detail; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE cfg_restore_backup_detail ( cfg_backup_detail_id integer NOT NULL, user_id integer, cfg_file_revision_id integer -- Name: chassis_component; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE chassis_component ( chassis_component_id integer NOT NULL, device_id integer NOT NULL, name character varying(128), description character varying(128),...
Page 225 Views exec_option numeric(2,0), is_public numeric(1,0), content character varying, report_file_name character varying(256), template_report_type numeric(2,0) -- Name: cli_template_report_execution; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE cli_template_report_execution ( cli_template_report_execution_id integer NOT NULL, device_deployment_job_id integer, cli_template_id integer, content character varying, compare_status numeric(2,0) -- Name: cli_template_target_device;...
Page 226 Views -- Name: collector_target_entry; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE collector_target_entry ( collector_target_entry_id integer NOT NULL, collector_id integer, target_id integer NOT NULL, prop_str character varying(8192), collector_target_entry_type integer -- Name: collector_threshold_rearm_trigger; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE collector_threshold_rearm_trigger ( collector_threshold_rearm_trigger_id integer NOT NULL, collector_id integer,...
Page 227 Views device_deployment_job_id integer NOT NULL, interface_id integer NOT NULL -- Name: deployment_setting; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE deployment_setting ( deployment_setting_id integer NOT NULL, scenario_id integer NOT NULL, user_id integer NOT NULL, is_write_to_ram numeric(1,0), is_reload numeric(1,0), deployment_mode character(1), do_pre_post_snapshot numeric(2,0) NOT NULL, cli_template_id integer NOT NULL, pre_post_deploy_setting_id integer NOT NULL,...
Page 228 Views local_username_port_cfg character varying(512), local_password_port_cfg character varying(512), local_username_read_only character varying(512), local_password_read_only character varying(512), radius_username_port_cfg character varying(512), radius_password_port_cfg character varying(512), radius_username_read_only character varying(512), radius_password_read_only character varying(512), tac_username_port_cfg character varying(512), tac_password_port_cfg character varying(512), tac_username_read_only character varying(512), tac_password_read_only character varying(512), tacplus_username_port_cfg character varying(512), tacplus_password_port_cfg character varying(512), tacplus_username_read_only character varying(512), tacplus_password_read_only character varying(512),...
Page 229 Views name_key character varying(64) NOT NULL, device_config_id integer NOT NULL, value_str bytea NOT NULL, line_num smallint NOT NULL, key1 smallint, key2 smallint, ref_table_name character varying(64), table_id integer, table_subtype character varying(32) NOT NULL, type_key character varying(32) -- Name: device_deployment_job; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE device_deployment_job ( device_config_id integer NOT NULL,...
Page 230 Views start_time numeric(20,0) NOT NULL, duration integer -- Name: discovery_log; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE discovery_log ( discovery_log_id integer NOT NULL, discovery_cycle_id integer NOT NULL, "timestamp" numeric(20,0), category smallint, device_ip character varying(40), messages character varying(4096) -- Name: discovery_profile; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE discovery_profile ( discovery_profile_id integer NOT NULL, discovery_profile_name character varying(255) NOT NULL...
Page 231 Views -- Name: events; Type: VIEW; Schema: dcm; Owner: dcmadmin CREATE VIEW events AS SELECT emain.trap_log_id, emain.trap_sender, emain."timestamp", emain.severity, emsgs.messages, emain.is_ack, emain.log_type, emain.slot, emain.port, emain.device_id, emain.event_action_id, emain.device_group_id, emain.port_group_id, emain.trap_device_ip, emain.log_sub_type, emain.unit FROM (events_main emain LEFT JOIN events_messages emsgs ON ((emain.messages_id = emsgs.messages_id)));...
Page 232 Views is_port_vlan_enabled numeric(1,0), architecture_type numeric(2,0), build_label character varying(64), ssl_slot numeric(4,0) -- Name: foundry_module; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE foundry_module ( module_id integer NOT NULL, serial_num character varying(32), dram_size numeric(4,0), boot_flash_size numeric(4,0), module_type numeric(4,0), code_flash_size numeric(4,0), expansion_module_type numeric(4,0), expansion_module_description character varying(128) -- Name: foundry_physical_device;...
Page 233 Views -- Name: image_archive; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE image_archive ( image_archive_id integer NOT NULL, product_type character varying(32) NOT NULL, feature_mask character varying(32), supported_type character varying(32) NOT NULL, flash_size integer, location character varying(255) NOT NULL, file_name character varying(64) NOT NULL, version_label character varying(32) NOT NULL, release_datetime character varying(64), special_key character varying(32),...
Page 234 Views CREATE TABLE ip_address_spec ( address_spec_id integer NOT NULL, ip_address character varying(40) NOT NULL, wildcard_mask character varying(40) -- Name: inm_ip_interface; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE inm_ip_interface ( ip_interface_id integer NOT NULL, ip_routing_service_id integer, interface_id integer, device_id integer NOT NULL, ip_subnet_id integer NOT NULL, ip_address character varying(40) NOT NULL, subnet_mask character varying(40)
Page 235 Views network_number character varying(32) NOT NULL, frame_type numeric(4,0) NOT NULL -- Name: ironclad_adaptive_entry; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE ironclad_adaptive_entry ( policy_entry_id integer NOT NULL, normal_burst numeric(20,3), normal_burst_type character(1), max_burst numeric(20,3), max_burst_type character(1), conform_action numeric(2,0), exceed_action numeric(2,0), vlan_id numeric(4,0) -- Name: jetcore_adaptive_entry;...
Page 236 Views config_state character varying(1), time_stamp character varying(64) -- Name: license_files; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE license_files ( license_file_id integer NOT NULL, identifier character varying(255) NOT NULL, license_details character varying(255) NOT NULL, is_eval numeric(1,0) NOT NULL -- Name: license_parameters; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE license_parameters ( license_param_id integer NOT NULL,...
Page 237 Views type numeric(2,0) -- Name: loopback_interface; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE loopback_interface ( interface_id integer NOT NULL -- Name: mac_filter_entry; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE mac_filter_entry ( mac_filter_entry_id integer NOT NULL, mac_filter_group_id integer, mac_filter_num numeric(8,0) NOT NULL, is_permit numeric(1,0), src_mac_address character varying(24) NOT NULL,...
Page 238 Views is_independent numeric(1,0) NOT NULL, xml_instance bytea NOT NULL, key1 character varying(128), key2 character varying(128), last_updated_time numeric(20,0), is_internal numeric(1,0) -- Name: mib_object; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE mib_object ( mib_object_id integer NOT NULL, oid character varying(128) NOT NULL, name character varying(64), value_type numeric(2,0), target_type numeric(2,0)
Page 239 Views mpls_admin_group_db_id integer NOT NULL, interface_id integer NOT NULL -- Name: mpls_lsp; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE mpls_lsp ( mpls_lsp_db_id integer NOT NULL, table_subtype character varying(32) NOT NULL, name character varying(255) NOT NULL, destination_ip_address character varying(255) NOT NULL, oper_status smallint NOT NULL, device_id integer NOT NULL -- Name: mpls_path;...
Page 240 Views -- Name: mpls_rsvp_lsp_admin_group_container; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE mpls_rsvp_lsp_admin_group_container ( mpls_rsvp_lsp_admin_group_container_db_id integer NOT NULL, mpls_rsvp_lsp_parameters_db_id integer, mpls_rsvp_lsp_frr_parameters_db_id integer -- Name: mpls_rsvp_lsp_frr_parameters; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE mpls_rsvp_lsp_frr_parameters ( mpls_rsvp_lsp_frr_parameters_db_id integer NOT NULL, bandwidth integer NOT NULL, hop_limit numeric(3,0) NOT NULL, is_facility_backup numeric(1,0) NOT NULL,...
Page 241 Views -- Name: mpls_service; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE mpls_service ( mpls_service_db_id integer NOT NULL, name character varying(255) NOT NULL, vcid bigint NOT NULL, mpls_service_type smallint NOT NULL, vll_mode smallint, status smallint NOT NULL, conflicts integer NOT NULL, last_updated_time numeric(20,0) -- Name: mpls_service_device_relation;...
Page 242 Views mrp_ring_device_db_id integer NOT NULL, mrp_ring_id integer NOT NULL, device_id integer NOT NULL, port_vlan_db_id integer DEFAULT 0 NOT NULL, mrp_ring_name character varying(255), topo_grp_id integer DEFAULT 0 NOT NULL, state smallint NOT NULL, role smallint NOT NULL, hello_time integer NOT NULL, pre_fwd_time integer NOT NULL, pri_port_interface_id integer DEFAULT 0 NOT NULL, pri_port_state smallint NOT NULL,...
Page 243 Views port_num smallint NOT NULL, module_id integer NOT NULL, is_port_present smallint, table_subtype character varying(32) NOT NULL -- Name: policy; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE policy ( policy_id integer NOT NULL, name character varying(64) NOT NULL, user_id integer, is_public numeric(1,0), description character varying(256) -- Name: policy_entry;...
Page 244 Views -- Name: port_vlan; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE port_vlan ( vlan_db_id integer NOT NULL, stp numeric(1,0), vlan_id smallint NOT NULL, qos smallint, global_vlan_db_id integer, stp_instance_id integer -- Name: pos_interface; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE pos_interface ( interface_id integer NOT NULL -- Name: inm_privilege;...
Page 245 Views last_updated bigint, name character varying(64) NOT NULL, messages character varying(255), policy_desc character varying(255) -- Name: query_based_device_group; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE query_based_device_group ( device_group_id integer NOT NULL, query_text character varying(512) -- Name: radio_interface; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE radio_interface ( interface_id integer NOT NULL, radio_type numeric(2,0) NOT NULL,...
Page 246 Views -- Name: report_definition; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE report_definition ( report_definition_id integer NOT NULL, name character varying(64) NOT NULL, category character varying(20) NOT NULL, user_id integer NOT NULL, type numeric(2,0) NOT NULL, last_modified character varying(64) NOT NULL, description character varying(128), definition character varying NOT NULL, is_with_data_source numeric(1,0),...
Page 247 Views sensor_total integer, sensor_up integer, sensor_down integer, sensor_relief integer, last_viewed_timestamp bigint NOT NULL -- Name: rf_overview_logs; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE rf_overview_logs ( log_timestamp bigint NOT NULL, log_message character varying(512) NOT NULL -- Name: rfmon_ap; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE rfmon_ap ( sqnum integer NOT NULL, time_stamp bigint,...
Page 248 Views totalcrcerrframes integer, totalfragerrframes integer, totalretryframes integer, totalassocreq integer, totalassocresp integer, totalreassocreq integer, totalreassocresp integer, totalprobereq integer, totalproberesp integer, totalbeacon integer, totaldisassoc integer, totalauth integer, totaldeauth integer, totalcriticalalerts integer, totalmoderatealerts integer, totalminor integer -- Name: rfmon_ap_last_saved; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE rfmon_ap_last_saved ( device_id integer NOT NULL,...
Page 249 Views authtype smallint, networkmode smallint, wepenabled smallint, cfpollable smallint, shortpreamblemode smallint, rsnsupported smallint, onexenabled smallint, shortslottime integer, failedreassocattempts integer, failedassocattempts integer, associateid integer, rssi integer, listeninterval integer, ssidlen smallint, ssid character varying(256), ipaddress character varying(40), deauthreasoncode integer, deassocreasoncode integer, ratesupported character varying(256), extratesupported character varying(256), firstseen integer, lastupdated integer,...
Page 250 Views -- Name: rl_access_control_group; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE rl_access_control_group ( rl_access_control_group_id integer NOT NULL, name character varying(64) NOT NULL, user_id integer, is_public numeric(1,0), description character varying(256) -- Name: rl_access_control_list; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE rl_access_control_list ( rl_access_control_list_id integer NOT NULL,...
Page 251 Views privilege_id integer NOT NULL, role_id integer NOT NULL -- Name: routing_service; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE routing_service ( service_id integer NOT NULL -- Name: scenario; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE scenario ( scenario_id integer NOT NULL, name character varying(256) NOT NULL, user_id integer NOT NULL,...
Page 252 Views -- Name: scenario_port_binding; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE scenario_port_binding ( scenario_binding_id integer NOT NULL, interface_id integer NOT NULL -- Name: scenario_port_group_binding; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE scenario_port_group_binding ( port_group_id integer NOT NULL, scenario_binding_id integer NOT NULL -- Name: schedule_email_user;...
Page 253 Views -- Name: service_group_spec; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE service_group_spec ( port_spec_id integer NOT NULL, service_group_id integer -- Name: service_name_entry; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE service_name_entry ( service_name_entry_id integer NOT NULL, service_group_id integer NOT NULL, service_port_definition_id integer NOT NULL, name character varying(32) -- Name: service_port_definition;...
Page 254 Views L4_DEST_PORT integer, SRC_SUBNET_BITS smallint, DEST_SUBNET_BITS smallint, LOCAL_AS bigint, SRC_AS bigint, SRC_PEER_AS bigint, SFLOW_IP_ROUTE_INFO_ID integer, IP_FLOW_LABEL integer, SRC_USER integer, DEST_USER integer, FRAMES bigint not null, BYTES bigint not null, TCP_FLAGS smallint create table SFLOW_STAGING_SLNUM MIN_SLNUM bigint ) with (autovacuum_vacuum_threshold=4); -- Name: sflow_hour_summary; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: create table SFLOW_HOUR_SUMMARY SLNUM bigserial not null,...
Page 255 Views create table SFLOW_HOUR_SUMMARY_SLNUM ( MAX_SLNUM bigint ) with (autovacuum_vacuum_threshold=4); -- Name: sflow; Type: VIEW; Schema: dcm; Owner: dcmadmin create or replace view SFLOW as select DEVICE_ID, IN_SLOT, IN_PORT, OUT_SLOT, OUT_PORT, L4_PROTOCOL, IP_TOS, SRC_SUBNET_BITS, DEST_SUBNET_BITS, IN_PRIORITY, OUT_PRIORITY, IN_VLAN, OUT_VLAN, L3_PROTOCOL, L4_SRC_PORT, L4_DEST_PORT, TIME_IN_SECONDS, SRC_MAC, DEST_MAC, L3_SRC_ADDR, L3_DEST_ADDR, TCP_FLAGS, LOCAL_AS, SRC_AS, SRC_PEER_AS, SFLOW_IP_ROUTE_INFO_ID, IP_FLOW_LABEL, SRC_USER, DEST_USER, FRAMES, BYTES, IN_UNIT, OUT_UNIT...
Page 256 Views -- Name: sflow_minute_bgp_view; Type: VIEW; Schema: dcm; Owner: dcmadmin create or replace view SFLOW_MINUTE_BGP_VIEW as select DEVICE_ID, TIME_IN_SECONDS, SRC_AS, SFLOW_IP_ROUTE_INFO_ID, IN_VLAN, OUT_VLAN, FRAMES, BYTES from SFLOW_MINUTE_BGP where SLNUM <= (select MAX_SLNUM from SFLOW_MINUTE_BGP_SLNUM fetch first 1 rows only) union all select DEVICE_ID, TIME_IN_SECONDS, SRC_AS, SFLOW_IP_ROUTE_INFO_ID, IN_VLAN, OUT_VLAN, FRAMES, BYTES from SFLOW_STAGING...
Page 257 Views IN_VLAN smallint, OUT_VLAN smallint, SRC_MAC bytea, DEST_MAC bytea create table SFLOW_MINUTE_MAC_SLNUM ( MAX_SLNUM bigint ) with (autovacuum_vacuum_threshold=4); -- Name: sflow_minute_mac_view; Type: VIEW; Schema: dcm; Owner: dcmadmin create or replace view SFLOW_MINUTE_MAC_VIEW as select DEVICE_ID, TIME_IN_SECONDS, SRC_MAC, DEST_MAC, IN_VLAN, OUT_VLAN, FRAMES, BYTES from SFLOW_MINUTE_MAC where SLNUM <= (select MAX_SLNUM from SFLOW_MINUTE_MAC_SLNUM fetch first 1 rows...
Page 258 Views where SLNUM >= (select MIN_SLNUM from SFLOW_STAGING_SLNUM fetch first 1 rows only); -- Name: sflow_report_l3_source; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE sflow_report_l3_source ( sflow_report_l3_source_id integer NOT NULL, report_definition_id integer NOT NULL, address_group_id integer, ip_subnet_definition_id integer -- Name: sflow_report_l4_source; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE sflow_report_l4_source ( sflow_report_l4_source_id integer NOT NULL,...
Page 259 Views constraint PK_SNMP_EXPR_DATA primary key (ID) -- Name: snmp_expression; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: create table SNMP_EXPRESSION ( EXPRESSION_ID serial not null, NAME character varying(64) not null, DESCRIPTION character varying(512), EQUATION character varying(1024) -- Name: snmp_fwd_aa; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE snmp_fwd_aa ( snmp_fwd_aa_id integer NOT NULL, trap_community character varying(64),...
Page 260 Views CREATE TABLE snmp_fwd_targets ( snmp_fwd_targets_id integer NOT NULL, is_enable character varying(8) DEFAULT 'Yes'::character varying NOT NULL, ip_address character varying(40) NOT NULL, snmp_trap_port integer DEFAULT 162 NOT NULL, snmp_version character varying(8) DEFAULT 'v2/v3'::character varying NOT NULL, snmp_notify_type character varying(1) DEFAULT '1'::character varying NOT NULL, snmp_to_nnm character varying(8) DEFAULT 'No'::character varying NOT NULL -- Name: snmp_fwd_trap_oid;...
Page 261 Views -- Name: ssl_certificate; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE ssl_certificate ( ssl_certificate_id integer NOT NULL, name character varying(255), location character varying(255), file_name character varying(255), key_id integer NOT NULL, cert_type numeric(2,0) NOT NULL, start_time numeric(20,0), expiration_time numeric(20,0), format numeric(2,0) NOT NULL, description character varying(1024), notification_time numeric(20,0) NOT NULL DEFAULT 0,...
Page 262 Views CREATE TABLE stp_entry ( stp_entry_id integer NOT NULL, device_id integer NOT NULL, vlan_id integer NOT NULL, port_id character varying(32) NOT NULL, port_priority smallint NOT NULL, path_cost integer NOT NULL, port_state smallint NOT NULL, designated_cost integer NOT NULL, designated_root character varying(32) NOT NULL, designated_bridge character varying(32) NOT NULL, edge_port smallint NOT NULL, p2p smallint NOT NULL,...
Page 263 Views row_id integer NOT NULL, file_pointer bigint NOT NULL, file_name character varying(512) -- Name: system_profile; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE system_profile ( system_profile_id integer NOT NULL, new_installation_update_status character varying(64) NOT NULL, db_schema_string character varying(20), is_demo_version numeric(1,0), demo_expiration_datetime character varying(32), is_full_install numeric(1,0) DEFAULT 0, serial_number character varying(64),...
Page 264 Views -- Name: trap_backup_detail; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE trap_backup_detail ( cfg_backup_detail_id integer NOT NULL, cfg_change_user_name character varying(64), trap_log_id integer -- Name: trunk_group_interface; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE trunk_group_interface ( interface_id integer NOT NULL -- Name: trunk_group_member;...
Page 265 Views phone_number character varying(32), status character(1) NOT NULL, user_type numeric(2,0) DEFAULT 0 NOT NULL, email_address1 character varying(255), email_address2 character varying(255), email_address3 character varying(255), email_address4 character varying(255), email_alertflag1 character(1), email_alertflag2 character(1), email_alertflag3 character(1), email_alertflag4 character(1), last_updated character varying(32), previous_passwords_used character varying(2500), nbi_identity_key character varying(255) DEFAULT ''::character varying NOT NULL, nbi_access_key character varying(512)
Page 266 Views -- Name: vlan_dynamic_interface_member; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE vlan_dynamic_interface_member ( vlan_interface_relation_id integer NOT NULL -- Name: vlan_excluded_interface; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE vlan_excluded_interface ( vlan_interface_relation_id integer NOT NULL -- Name: vlan_interface_member; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE vlan_interface_member ( vlan_interface_relation_id integer NOT NULL...
Page 267 Views -- Name: vpls_endpoint_relation; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE vpls_endpoint_relation ( mpls_service_endpoint_relation_db_id integer NOT NULL -- Name: vpnpt_authentication; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE vpnpt_authentication ( vpnpt_authentication_id integer NOT NULL, vpnpt_policy_id integer, realm_policy_id integer -- Name: vpnpt_policy;...
Page 268 Views xinfo character varying(64) -- Name: wired_interface; Type: VIEW; Schema: dcm; Owner: dcmadmin CREATE VIEW wired_interface AS SELECT l2.device_id, l2.device_ip_address, l2.physical_device_id, l2.unit_number, l2.slot_id, l2.slot_num, l2.module_id, l2.physical_port_id, l2.port_num, l2.interface_id, l2.name, l2.if_name, l2.identifier, l2.table_subtype, l2.tag_mode, l2.speed_in_mb, l2.physical_address, l2.duplex_mode, l3.ip_id, l3.ip_interface_id, l3.ip_address, l3.subnet_mask FROM ((SELECT DISTINCT d.device_id, d.ip_address AS device_ip_address, pd.physical_device_id, pd.unit_number, s.slot_id, s.slot_num, msp.module_id, pp.physical_port_id, pp.port_num, i.interface_id, i.name, i.if_name,...
Page 269: Managed_Element_Info
Views radio_interface.beacon_rate, radio_interface.dtim, radio_interface.rts_threshold, radio_interface.is_turbo_mode, radio_interface.radio_g_mode, radio_interface.max_associated_clients FROM radio_interface) wireless ON ((l2.interface_id = wireless.radioif_id))); -- Name: wpa; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE wpa ( authentication_encryption_id integer NOT NULL, cipher_mode numeric(2,0), wpa_mode numeric(2,0) -- Name: wpa_psk; Type: TABLE; Schema: dcm; Owner: dcmadmin; Tablespace: CREATE TABLE wpa_psk ( authentication_encryption_id integer NOT NULL, key_type numeric(2,0),...
Page 270: Snmp_Expr_Data_Info
Views select * from SNMP_DATA_2HOUR union all select * from SNMP_DATA_1DAY; SNMP_EXPR_DATA_INFO create or replace view SNMP_EXPR_DATA_INFO as select * from SNMP_EXPR_DATA union all select * from SNMP_EXPR_DATA_30MIN union all select * from SNMP_EXPR_DATA_2HOUR union all select * from SNMP_EXPR_DATA_1DAY; SNMP_DATA_VIEW create view SNMP_DATA_VIEW AS SELECT de.device_id, de.ip_address AS device_ip,...
Page 271 Views SELECT de.device_id, de.ip_address AS device_ip, sd.target_type, ifs.interface_id AS target_id, ifs.if_name AS target_name, 0 AS collectible_type, sd.mib_object_id AS collectible_id, sd.collector_id, ( SELECT perf_collector.name AS collector_name FROM perf_collector WHERE perf_collector.collector_id = sd.collector_id) AS collector_name, ( SELECT (mib_object.name::text || '.'::text) || sd.mib_index::text AS collectible_name FROM mib_object WHERE mib_object.mib_object_id = sd.mib_object_id) AS collectible_name, ( SELECT mib_object.oid AS collectible_detail...
