Avio iP-750E User Manual

Intelligent projector
Hide thumbs Also See for iP-750E:
Table of Contents

Advertisement

Quick Links

Download this manual
Overseas Department
Industrial Electronic Products Sales Division
NIPPON AVIONICS CO., LTD.
3-20-1 Nishi Shinbashi, Minato-ku, Tokyo, Japan
Zip code: 105-0003
TEL: +81-3-5401-7386 FAX: +81-3-5401-7344
Customer Support Center, Industrial Electronic Products Division
1-1 KOYATO 2-CHOME SAMUKAWA-MACHI
KOZA-GUN KANAGAWA, JAPAN
Zip code: 253-0103
Tel: +81-467-73-4426
E-mail: support_mp@avio.co.jp
URL: http://www.avio.co.jp
To customers : Enter the name and date of the store where you purchased this
product. This information will be useful when you ask your dealer for
repair.
• Date of Purchase
• Store of Purchase
Telephone Number :
(year, month, day)
(
)
A Proposal for New
Presentations
Intelligent Projector
User's Manual
iP-750E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iP-750E and is the answer not in the manual?

Questions and answers

Related Manuals for Avio iP-750E

Summary of Contents for Avio iP-750E

  • Page 1 A Proposal for New Presentations Intelligent Projector User’s Manual iP-750E Overseas Department Industrial Electronic Products Sales Division NIPPON AVIONICS CO., LTD. 3-20-1 Nishi Shinbashi, Minato-ku, Tokyo, Japan Zip code: 105-0003 TEL: +81-3-5401-7386 FAX: +81-3-5401-7344 Customer Support Center, Industrial Electronic Products Division...

  • Page 2: Safety Precautions

    • Enlarged display without changing the screen size When projecting documents having small characters that were not created for presentations, such as catalogs and word- processed documents, the iP-750E can enlarge the document without changing the screen size to provide an easy-to-view display.

  • Page 3: Safety Precautions

    Safety Precautions WARNING ● If a fault occurs: • If you detect smoke, or a strange smell or sound, immediately disconnect the power cable. It is dangerous to continue using the projector after a fault occurs. Return the projector to the dealer where it was purchased for repair.
  • Page 4 Safety Precautions CAUTION • Installation • Avoid installing the projector in places where it may be exposed to: - Strong vibrations - Soot or steam - Direct sunlight or near a heater (35°C/95°F or higher) - High humidity or dust - Extreme cold (0°C/32°F or lower) - Strong magnetic or electric field generated from a nearby appliance - Wobbling on an unstable surface...
  • Page 5 Safety Precautions • Lamp implosion • A DC type Super High pressure lamp is used in this projector and it is rare for the lamp to explode during use. The unit is also designed to forcibly turn off the lamp because there is a high possibility that the lamp will break if it is used beyond the lamp usage of 2000 hours (Refer to pages 43 and 45).

  • Page 6: Table Of Contents

    Table of Contents Safety Precautions ............ 3 Method of OHP Operation ........31 Attaching the Document Cover ......... 31 A Check of the Supplied Items Preparation of the Projection Document ....31 and the Names of the Parts ......... 8 Reading Size of Projection Documents .....

  • Page 7: A Check Of The Supplied Items And The Names Of The Parts

    A Check of the Supplied Items and the Names of the Parts Supplied Parts Check Please check that the supplied parts are included. iP-750E Projector Lens cap Remote control Battery (AA x 2) Power cable (3 m) iP-750E User’s Manual PC connection cable (2 m)

  • Page 8: Names And Functions Of The Parts (Projector)

    A Check of the Supplied Items and the Names of the Parts Names and Functions of the Parts (Projector) Zoom lever Turn this to adjust the screen size. See Page 23. Document cover The document or printed material to be read is placed un- der this cover.
  • Page 9 A Check of the Supplied Items and the Names of the Parts Speaker (2W Stereo) Document reading area The document or printed material that you wish to project in the OHP mode is placed here. See Page 31. Remote control IR sensor Tilt foot Theft prevention lock Air Vent B...

  • Page 10: Names And Functions Of The Parts (Input Connectors)

    7. Test (maintenance) connector 2. Audio Output This special connector is used at the time of maintenance Audio output terminal for iP-750E. and factory tests. It cannot be used for other connections. This terminal outputs audio (either from the PC or video source) that is currently being input.

  • Page 11: Names And Functions Of The Parts (Operation Panel)

    A Check of the Supplied Items and the Names of the Parts Names and Functions of the Parts (Operation Panel) 5. INPUT SELECT Buttons 1. POWER Button Switches the power of the projector on or off (standby mode). These buttons select the input source. OHP →...

  • Page 12: Names And Functions Of The Parts (Remote Control)

    A Check of the Supplied Items and the Names of the Parts Names and Functions of the Parts (Remote Control) 6. SET/POINTER Button During menu display, this button advances the menu to the next level. This button finalizes the setting at the time of item selection.

  • Page 13: Operation Of The Remote Control

    A Check of the Supplied Items and the Names of the Parts Operation of the Remote Control • Please use the remote control within a range of about 7 m from the remote control IR sensor of the projector (located at both the front and rear) and within an angle of 10 degrees to the left and 10 degrees to the right.

  • Page 14: Procedure Up To Projection

    Procedure Up to Projection Consideration of placement location and screen size Determine the screen and projector setup location. Set the projector on a strong and stable, level platform. See Page 16 for information about the projection distance and screen size. Connections with input equipment Connect your personal computer/video equipment.

  • Page 15: Projection Distance And Screen Size

    Projection Distance and Screen Size Please use the following diagrams to determine the screen display size and the type of screen required for any given projector location. Projection distances that will be in focus will be 1.4 m (4.5 feet) to 13 m (41.7 feet) from the front of the lens. Please arrange the setup within this range.

  • Page 16: Connections With The Personal Computer

    • Connection might not be possibly depending on the model and settings of the personal computer. Please contact your dealer of purchase for further information. Basic Connections Terminal panel on the back of the iP-750E main unit Plug in the connection cable and fasten with the screws...

  • Page 17: Connections With Personal Computers

    Connections with the Personal Computer Connecting Macintosh Computers • Attach the supplied (RGB+USB) cable if when the monitor output is a VGA port (mini D-SUB 15-pin). • An optional Apple video adapter cable is required when the monitor output is a video port or DVI port. •...

  • Page 18: When The Image Of The Personal Computer Screen Is Not Projected

    ● The image is not projected When the external output signal from the personal computer is not input to the iP-750E, "No signal being input" is displayed on the display screen of the iP-750E. Should this occur, please check the following matters.

  • Page 19: Table Of Supported Input Signals (Personal Computer Video Input Connector)

    Connections with the Personal Computer Table of Supported Input Signals (Personal Computer Video Input Connector) Signals indicated with a “Yes” are supported. Note that depending on the model of personal computer, please perform the screen adjustment of the "Image adjustment" → "Sync adjustment" menu if flickering or bleeding appear on the projection screen.

  • Page 20: Connections With Video Equipment

    RGB-IN 1 RGB-OUT PC AUDIO PC AUDIO S-VIDEO VIDEO iP-750E Projector side connector panel To the video output connector To the audio output connectors Video deck DVD player NOTE: • When both Video and S-video connections have been made, S-video will be given priority for display.

  • Page 21: Connection Of The Power Cable And On/Off Switching

    Connection of the Power Cable and On/Off Switching Switch On the Power Connect the power cable The projector will enter the standby mode and the ON/STANDBY LED will light in red. To wall outlet. Press the POWER button ( ) The fan will turn, the lamp will light, and the ON/STANDBY LED will light in Operation with the Operation with the...

  • Page 22: Adjustment Of The Projection Image

    Adjustment of the Projection Image Adjusting the Projection Image Adjust the projection image to the screen. Right angle • When the image is shifted to the left or right, move the projector horizontally. (Align the center of the screen with the center of the projector lens.) •...

  • Page 23: Regular Operation

    Regular Operation This section describes the use of direct operation using the projector and remote control buttons. Please see the items on Page 33 "Menu Operation Method" and Page 36 "Menu Description" for information about operation using the menu. Select the Input When the power of the projector is switched on, the input selection (OHP / PC1 / PC2 / VIDEO) icon is displayed.

  • Page 24: Enlarging And Reducing The Projection Image

    Regular Operation To view the portion that has been cut off Operation with the Projector Press the SCROLL ( ) buttons and scroll the projec- tion image up or down. Operation with the Remote Control Press the SCROLL ( ) buttons and scroll the projec- tion image up or down.

  • Page 25: Adjusting The Size Of The Projected Image

    Regular Operation Moving the Screen Movement is possible in 4 directions (up, down, left, and right). Operation with the Projector Press the SCROLL ( ) buttons. Operation with the Remote Control Press the SCROLL ( ) buttons. Adjusting the size of the projected image While the image is displayed vertically, each press of the RESIZE button will toggle the display between a display that matches the horizontal width and a display that matches the vertical width.

  • Page 26: Adjusting The Brightness

    Regular Operation Adjusting the Brightness To change the brightness, perform a manual adjustment using the method described below. Operation with the Projector Adjust using the BRIGHTNESS ( ) buttons. : Projection image becomes brighter : Projection image becomes darker Operation with the Remote Control Brightness adjustment bar Adjust using the BRIGHTNESS (+)/(-) buttons.

  • Page 27: Viewing Ohp History Images

    Regular Operation During PC/VIDEO Input Each time the FREEZE/CAPTURE button is pressed, the currently projected image will be frozen (in a fixed display). NOTE: • The FREEZE LED is lit green during the still image display. • A press of the FREEZE/CAPTURE button while a moving image is projected will result in a still image display at the existing zoom magnification and position.

  • Page 28: Transferring Captured Images

    Regular Operation Full-screen Display of Thumbnail Images Operation with the Projector A full-screen display of captured images is not available from the operation panel of the projector. Operation with the Remote Control Select the images that you would like to display full screen using the SCROLL ( ) buttons and press the POINTER/SET button.

  • Page 29: Displaying The Pointer

    Regular Operation Displaying the Pointer This operation displays the pointer in the currently projected image. Operation with the Projector The ability to turn on and turn off the pointer is not avail- able from the operation panel of the projector. Operation with the Remote Control Press the POINTER/SET button.

  • Page 30: Method Of Ohp Operation

    Method of OHP Operation Attaching the Document Cover The document cover can be removed to suit the circumstances. NOTE: When removing the document cover, lift the cover by both hands and remove it. Preparation of the Projection Document The document (printed material) that is to be projected is placed on the projector as illustrated in the diagram below and the document cover is closed.

  • Page 31: Menu Configuration

    Menu Configuration The adjustment/setting items and content will differ depending on the input selection and the permitted information will be displayed on the menu for that input mode. Settings Pointer • Screen Image adjustment OHP/ PC / VIDEO Common During OHP Input OHP / PC / VIDEO Common During OHP History List Display During PC Input...

  • Page 32: Menu Operation Method

    Menu Operation Method Names and Functions of the Buttons Used in Menu Operation MENU Button Used to display a menu and to close a menu. SCROLL Buttons Used in the selection of menu names and item names, and to set and ad- POINTER/SET Button just item contents.

  • Page 33: Method Of Menu Operation

    Menu Operation Method Method of Menu Operation This section describes the actual operation method. Adjustment of [Keystone] using the remote control is provided as an example. Press the MENU button and display the menu Select [Settings] with the SCROLL buttons button switches the menu one step in the sequence of [Pointer •...
  • Page 34 Menu Operation Method Press the POINTER/SET Button Switches the menu to the sub menu (i.e., the Keystone adjustment menu). Make the adjustment with the SCROLL buttons while checking the projection image Scroll button: Each press increases the value of the verti- cal orientation.

  • Page 35: Menu Description

    Menu Description Pntr setting This selects the shape, color, and size of the pointer. Pointer shape ....Selects the shape of the pointer from 2 types. Pointer color ....Selects the color of the pointer from amongst 3 types (i.e., red, white, and blue).

  • Page 36: Image Adjustment

    Menu Description The following items will be displayed only during the projection of the page that was selected from the OHP history list. Back page in history ..Switches to the history screen that was stored before the currently pro- jected history screen.
  • Page 37 Menu Description Sub menu: Sync adjustment Clock ......Adjusts the horizontal size of the pro- jected image in the range of -50 to Phase ......Adjusts the noise/flickering of the projected image in the range of -50 to 50. Horizontal ....... Adjusts the horizontal position of the projected image in the range of -50 to 50.

  • Page 38: Settings

    Menu Description Settings This performs settings related to the projector unit or while the projector is in use. Lamp usage time ... Displays the usage time of the lamp. "Replacement of the Lamp Unit" → See Page 43 Input signal ..... The name of the currently selected input is displayed.
  • Page 39 Menu Description Language selection ..Selects from among the following languages the language for use in the menus and message indications: Japanese and English. Projection mode ..... Selects the projection system of the projector from between Front (front projection) and Rear (rear projec- tion).

  • Page 40: Maintenance

    Maintenance Fault Protection The projector is equipped with a built-in protection circuit to prevent fire and breakdown due to faults. When the LAMP/COVER LED lights in red Measures to be taken 1. Disconnect the power plug from the outlet. 2. Properly install the air filter. See "Air Filter Cleaning" on Page 46. 3.
  • Page 41 Maintenance When the power has failed (When all the LED go off with the power ON) Measures to be taken 1. Disconnect the power plug from the outlet. 2. Check the following matters and perform the countermeasure properly. Is the ambient temperature in Please use the projector in an operation ambient tempera- excess of 35°C (95°F)? ture of 0°C (32°F) to 35°C (95°F).

  • Page 42: Replacement Of The Lamp Unit

    If a glass part breaks, please exercise due caution in handling so that you are not injured by fragments. Please request repair from the store of purchase or an AVIO customer support center. • There is no compatibility with the lamp units of other MP/iP series. Please specify the dedicated lamp CAUTION unit (Model: MPLK-D1).

  • Page 43: Lamp Unit Replacement Procedure

    Maintenance Lamp Unit Replacement Procedure To prevent burns, wait one hour or longer after the lamp has been switched off before perform- ing the following procedure. Remove the lamp unit cover Using a minus screwdriver, loosen the screws of the lamp unit cover, pull in the direction of the arrow, and remove the cover.
  • Page 44 Maintenance Reset the lamp usage time Please perform the operation indicated below in the standby mode (*). Operation with the Projector Press these buttons in order while pressing the but- ton. Operation with the Remote Control Resetting of the lamp usage time cannot be performed with the remote control.

  • Page 45: Cleaning The Air Filter

    Maintenance Cleaning the Air Filter The air filter is an important part that prevents the intrusion of dust onto the optical parts and other parts inside the projector. When the air filter becomes blocked, the internal temperature will rise and the rotation of the fan will also increase leading to a reduction of the service life or causing breakdown.

  • Page 46: Troubleshooting

    Troubleshooting When you think the projector may be out of order, please first check the following matters before requesting repair. Symptom Please check this Reference page Power does not come on • Is the power cable connected? Projection lamp does not light •...

  • Page 47: Warranty & Repair Service

    Repair Service Repair Service Procedure • Before asking for repair service, check the Troubleshooting section on page 47 once more. If this check confirms a problem, contact the dealer where you bought the product. • When asking for repair service, provide your dealer with the following information: Description of the problem (as many details as possible) Date of purchase Your Name...

  • Page 48: Specifications

    Specifications Model Name iP-750E Type 3 primary Color LCD Shutter Projection Type LCD Panel Size 1.3 inches x 3 Panels, Aspect Ratio 4:3 Drive System Poly Silicon TFT Active Matrix with Micro Lens Array Number of Pixels 786,432 pixels (1,024 x 768 dots) 3...
