- Page 1 A Proposal for New Presentations Intelligent Projector User’s Manual iP-55E English Deutsch Français Español Italiano...
-
Page 2: Warnings And Safety Precautions
The creation of OHP film is not required. This allows a reduction of wasteful time and costs. • Super-thin, stylish body The iP-55E features a super-thin body for a projector having a built-in OHP function which reflects the advanced technology inherent in the design. Offers an easy fit when in use or when stored. -
Page 3: Safety Precautions
• If you detect smoke, or a strange smell or sound, immediately disconnect the power cable. It is dangerous to continue using the projector after a fault occurs. Return the projector to the dealer where it was purchased for repair. - Page 4 • Have the internal components cleaned by a retailer about once a year. There is a risk of fire or faulty operation if the inside of the projector gets dusty and is not cleaned for a long time. For best results, the projector should be serviced before the wet season brings damp conditions.
- Page 5 • Lamp implosion • A DC type Super High pressure lamp is used in this projector and it is rare for the lamp to explode during use. The unit is also designed to forcibly turn off the lamp because there is a high possibility that the lamp will break if it is used beyond the lamp usage of 1500 hours (Refer to pages E-42 and E-44).
-
Page 6: Table Of Contents
Names of the Parts ... E-7 Supplied Parts Check ... E-7 Names and Functions of the Parts (Projector) ... E-8 Names and Functions of the Parts (Input Connectors) ... E-10 Names and Functions of the Parts (Operation Panel) ... E-11 Names and Functions of the Parts (Remote Control) ... -
Page 7: A Check Of The Supplied Items And The Names Of The Parts
A Check of the Supplied Items and the Names of the Parts Supplied Parts Check Please check that the supplied parts are included. iP-55E Projector Lens cap Remote control Battery (AA x 2) Power cable (3 m) PC connection cable (2 m) iP-55E User’s Manual... -
Page 8: Names And Functions Of The Parts (Projector
A Check of the Supplied Items and the Names of the Parts Names and Functions of the Parts (Projector) Handle • Extended Press lightly on the left side of the handle and it rotates 180˚ and comes out. Remote control IR sensor... - Page 9 Air Vent B Air is discharged from the inside to the outside through this vent. Lamp unit cover (Underneath projector) The projection lamp unit is located inside. See Page E-42. A Check of the Supplied Items and the Names of the Parts...
-
Page 10: Names And Functions Of The Parts (Input Connectors
This special connector is used at the time of maintenance and factory tests. It cannot be used for other connections. 6. Audio Output Audio output terminal for iP-55E. This terminal outputs audio (either from the PC or video source) that is currently being input. In the standby mode, PC audio is output. -
Page 11: Names And Functions Of The Parts (Operation Panel
Names and Functions of the Parts (Operation Panel) 1. POWER Button Switches the power of the projector on or off (standby mode). • Only this button is effective when the projection lamp is off. See Page E-21. 2. ON/STANDBY LED Lit red during standby and lit green when the projection lamp is on. -
Page 12: Names And Functions Of The Parts (Remote Control
A Check of the Supplied Items and the Names of the Parts Names and Functions of the Parts (Remote Control) 1. POWER Button Switches the power of the projector on or off (standby mode). • Only this button is effective when the projection lamp is off. -
Page 13: Operation Of The Remote Control
Operation of the Remote Control • Please use the remote control within a range of about 7 m from the remote control IR sensor of the projector (located at both the front and rear) and within an angle of 10 degrees to the left and 10 degrees to the right. Note that this distance may be shorter depending on battery consumption. -
Page 14: Procedure Up To Projection
Properly adjust the projection image to the screen → See Page E-15 Perform the tilt adjustment of the projector to provide the desired projection height. The tilt adjustment allows the position of the projection image to be raised and lowered. The adjustment angle is from 0 degrees to 7 degrees. -
Page 15: Projection Distance And Screen Size
• Do not place the projector in a location where the ventilation vents will be blocked or in closed areas having poor ventilation. Doing so will cause the temperature to rise and could cause a fire or acci- dent. -
Page 16: Connections With The Personal Computer
Connections with the Personal Computer Connection Precautions • To protect this projector and the equipment to be connected, switch off the power of each unit before making connections. • Please read the various equipment instruction manuals for information about the connection of the equipment and the method of use. -
Page 17: Personal Computer Input Connector
The pins and their corresponding signal inputs are described below. 13 12 NOTE: • This projector uses a 15-pin RGB input and an analog type output terminals. For this reason, it cannot be connected to a digital output type personal computer. • Plug and play is not supported. -
Page 18: When The Image Of The Personal Computer Screen Is Not Projected
● The image is not projected When the external output signal from the personal computer is not input to the iP-55E, "No signal being input" is displayed on the display screen of the iP-55E. Should this occur, please check the following matters. -
Page 19: Table Of Supported Input Signals (Personal Computer Video Input Connector
Table of Supported Input Signals (Personal Computer Video Input Connector) Signals indicated with a “Yes” are supported. Note that depending on the model of personal computer, please perform the screen adjustment of the "Image adjustment" → "Sync adjustment" menu if flickering or bleeding appear on the projection screen. -
Page 20: Connections With Video Equipment
Connections with Video Equipment The video of a video tape deck or DVD player is projected onto a large screen. iP-55E Projector side connector panel To the video output connector Video deck NOTE: • When both Video and S-video connections have been made, S-video will be given priority for display. -
Page 21: Connection Of The Power Cable And On/Off Switching
• Do not disconnect the power cable while the lamp is on or while the ventilation fan is turning. • Unplug the power plug of the projector from the wall outlet when the projector will not be used for an CAUTION extended period. -
Page 22: Adjustment Of The Projection Image
Adjust the projection image to the screen. Right angle • When the image is shifted to the left or right, move the projector horizontally. (Align the center of the screen with the center of the projector lens.) • When the image is shifted up or down, use the tilt foot to adjust the projector vertically. -
Page 23: Regular Operation
Please see the items on Page E-32 "Menu Operation Method" and Page E-35 "Menu Description" for information about operation using the menu. Select the Input When the power of the projector is switched on, the input selection (OHP / PC1 / PC2 / VIDEO) icon is displayed. VIDEO NOTE: •... -
Page 24: Enlarging And Reducing The Projection Image
During OHP input, adjustment from the same size to 6.25 times (length ratio 2.5 times) is permitted, while during PC or VIDEO input, adjustment from the same size to 16 times (length ratio 4 times) is permitted. Operation with the Projector Press the SCROLL ( tion image up or down. -
Page 25: Moving The Screen
Operation with the Remote Control Press the SCROLL ( ) buttons. Operation with the Projector A full-screen display of captured images is not available from the operation panel of the projector. Operation with the Remote Control Press the RESIZE button. Regular Operation... -
Page 26: Adjusting The Brightness
Once 32 pages have been stored, each time a new image is captured, an old image will be deleted. The Freeze icon is displayed at the time of image capture. Operation with the Projector Adjust using the BRIGHTNESS ( : Projection image becomes brighter... -
Page 27: Viewing Ohp History Images
• A press of the projector INPUT SELECT buttons or one of the remote control OHP / PC / VIDEO buttons during a still image display will cancel the still image of the PC or video deck. OHP will retain the still image. -
Page 28: Transferring Captured Images
Operation with the Projector A full-screen display of captured images is not available from the operation panel of the projector. Operation with the Remote Control Select the images that you would like to display full screen using the SCROLL ( POINTER/SET button. -
Page 29: Displaying The Pointer
NOTE: When a fixed period of time elapses (about 30 minutes) with the video/audio muted, a message will be displayed to check whether to shut down the projector. Selection of "Yes" will set the projector to the standby mode, while a selection of "No" will again delete the video/audio. -
Page 30: Method Of Ohp Operation
• When paper having luster such as magazine covers are placed on the projector, the internal fluorescent lamp light will be picked up and the edges of the projected document may be messy. -
Page 31: Menu Configuration
Menu Configuration The adjustment/setting items and content will differ depending on the input selection and the permitted information will be displayed on the menu for that input mode. Pointer • Screen OHP/ PC / VIDEO Common During OHP History List Display During OHP History Single-page Display Image adjustment During OHP Input... -
Page 32: Menu Operation Method
Menu Operation Method Names and Functions of the Buttons Used in Menu Operation MENU Button Used to display a menu and to close a menu. POINTER/SET Button Used to finalize a setting after making the setting or adjustment. Names and Functions of the Menu Parts Menu tab Switches to the various menus when selected. -
Page 33: Method Of Menu Operation
Method of Menu Operation This section describes the actual operation method. Adjustment of [Keystone] using the remote control is provided as an example. Press the MENU button and display the menu Select [Settings] with the SCROLL Each press of the SCROLL adjustment] →... - Page 34 Menu Operation Method Press the POINTER/SET Button Make the adjustment with the SCROLL Press the MENU button and close the menu This completes the [Keystone] adjustment. Switches the menu to the sub menu (i.e., the Keystone adjustment menu). buttons while checking the projection image Scroll button: Each press increases the value of the verti- cal orientation.
-
Page 35: Menu Description
Menu Description Pointer • Screen This selects the shape, color, and size of the pointer. Pointer shape ... Selects the shape of the pointer from 2 types. Pointer color ... Selects the color of the pointer from amongst 3 types (i.e., red, white, and blue). -
Page 36: Image Adjustment
Menu Description The following items will be displayed only during the projection of the page that was selected from the OHP history list. Back page in history ... Switches to the history screen that was stored before the currently pro- jected history screen. - Page 37 Sub menu: Sync adjustment Clock ... Adjusts the horizontal size of the pro- jected image in the range of -50 to Phase ... Adjusts the noise/flickering of the projected image in the range of -50 to 50. Horizontal ... Adjusts the horizontal position of the projected image in the range of -50 to 50.
-
Page 38: Setting Items
• When keystone compensation is performed, the resolution at the edges of the projected image is reduced, making small char- acters difficult to read. To prevent this, place the projector on as level a surface as possible, and set the Keystone menu to “0” (No compensation). - Page 39 Japanese, English, German, French, Spanish, Italian, Chinese, and Ko- rean. Projection mode ... Selects the projection system of the projector from between Front (front projection) and Rear (rear projec- tion). Economy mode ... ON (Economy mode): Sets the lamp to the economy mode.
-
Page 40: Maintenance
Maintenance Fault Protection The projector is equipped with a built-in protection circuit to prevent fire and breakdown due to faults. When the LAMP/COVER LED lights in red Measures to be taken 1. Disconnect the power plug from the outlet. 2. Properly install the air filter. See "Air Filter Cleaning" on Page E-45. - Page 41 Is the air filter blocked? Breakdown of an internal cir- cuit could be the problem. Please use the projector in an operation ambient tempera- ture of 0°C (32°F) to 35°C (95°F). Rearrange the setup location of the projector and separate the projector from surrounding objects.
-
Page 42: Replacement Of The Lamp Unit
• There is a large number of glass parts such as the lamp and mirrors that are used inside the projector. If a glass part breaks, please exercise due caution in handling so that you are not injured by fragments. -
Page 43: Lamp Unit Replacement Procedure
Tighten the 2 mounting screws of the lamp unit. Align the 2 tabs located on the lamp unit cover with the projector and attach from the side of the tabs. Tighten the mounting screws of the lamp unit cover. - Page 44 CAUTION therefore, be sure to reset the usage time after lamp replacement. When the indication exceeds 1500 hours, the projector will be forced to turn off the projection lamp. NOTE: • In the interest of safety, the lamp will not light when the lamp unit cover is off.
-
Page 45: Cleaning The Air Filter
CAUTION reduce the effectiveness of the air filter. • Do not forget to install the air filter. If the projector is left without the air filter installed, dust may enter the projector and cause dirty projected images. • When the air filter becomes damaged, be sure to replace it with a new one (sold separately). If the projector is used with the air filter damaged, dust may enter the projector and cause dirty projected images. -
Page 46: Troubleshooting
Troubleshooting When you think the projector may be out of order, please first check the following matters before requesting repair. Symptom Power does not come on Projection lamp does not light There is no image Image is distorted Image is blurred... -
Page 47: Repair Service
• When asking for repair service, provide your dealer with the following information: Description of the problem (as many details as possible) Date of purchase Your Name Your Address Telephone number Product name and model No. (written on the label at the bottom of the projector) -
Page 48: Specifications
• Specifications and designs are subject to change without prior notice in order to improve the product. LCD panels are inherently susceptible to pixel defects. The specifications are subject to change without notice. iP-55E 3 primary Color LCD Shutter Projection Type 1.0 inches x 3 Panels, Aspect Ratio 4:3...
