Installation and Operation Manual
For Hunter Ceiling Fans
41457-01 7/2000
1
41457-01 7/2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 41457-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Hunter 41457-01

Summary of Contents for Hunter 41457-01

  • Page 1 ® ® SINCE 1886 Installation and Operation Manual For Hunter Ceiling Fans 41457-01 7/2000 41457-01 7/2000...
  • Page 2 ® 41457-01 7/2000...
  • Page 3 ® CONGRATULATIONS! Your new Hunter ceiling fan is an Model Name __________________ addition to your home or office that Catalog No. ___________________ will provide comfort and perfor- Attach Your Receipt Serial No. _____________________ mance for many years. This manual or a Copy of...

  • Page 4: Table Of Contents

    Step 9 - Assembling Fan Blades ........................21 Step 10 - Attaching the Switch Housing ......................23 Step 11 - Installing Light Fixture ........................26 Operating Your Hunter Fan and Remote ......................30 Cleaning and Maintenance ..........................32 Troubleshooting .............................. 33...

  • Page 5: Important Information

    If you need help installing the fan, let box and associated wall your Hunter fan dealer can direct you switch location. If you can- to a licensed installer or electrician. 41457-01 7/2000...

  • Page 6: Step 1 - Getting Ready

    For quiet and optimum performance the step in which each part is used. “Guide to Choosing and Preparing of your Hunter fan, use only Hunter If any parts are missing or damaged, a Ceiling Fan Site” to pick the fan speed controls.
  • Page 7 You can Standard Mounting (Figure 1b) install your Hunter fan in one of three hangs from the ceiling by a connec- ways. The steps in this manual in- tor pipe (included), for ceilings 8 feet...

  • Page 8: Step 2 - Installing The Ceiling Plate

    Figure 2b - Correct Position of Ceiling Figure 2a - Adding Isolators to Ceiling and ceiling by inserting the raised Plate Plate for Angle Mounting areas on each isolator into the holes in the ceiling plate. Refer to Figure 2a. 41457-01 7/2000...
  • Page 9 Do not over- tighten. Ceiling Joist 2 x 4 Brace Ceiling Ceiling Plate Outlet Box Flat Washer 3" Wood Screw Figure 2c - Attaching Ceiling Plate to 2 x 4 Brace 41457-01 7/2000...

  • Page 10: Step 3 - Assembling Pipe/Ball Assembly

    STEP 3 - ASSEMBLING PIPE/BALL ASSEMBLY As discussed in STEP 1 - GETTING 3. Remove the ball from the pipe. READY, your Hunter fan can be in- 12" Pipe 4. Remove the pin from the pipe. stalled in a standard mounting posi- tion.
  • Page 11 WARNING WARNING • Failure to complete the • To avoid possible electrical steps above properly could shock, the ground screw result in the fan falling. must be tightened securely. 41457-01 7/2000...

  • Page 12: Step 4 - Assembling The Fan

    Pipe FLUSH MOUNTING Setscrew Top of Fan For Low Ceilings 1. Tighten or remove pipe setscrew. Figure 4b - Placing Canopy and Figure 4a - Inserting Pipe through Fit the canopy over the hanger Washer Over Adapter Canopy 41457-01 7/2000...
  • Page 13 Figure 4c. as shown in Figure 4d. Threaded Assembly Screw Adapter Hole and Lockwasher Assembly Washer Figure 4c - Positioning Assembly Figure 4d - Attaching Canopy to Fan Washer Slots over Threaded Holes Assembly 41457-01 7/2000...

  • Page 14: Step 5 - Hanging The Fan

    Figures 5a and 5b. Ceiling Plate Figure 5a - Attaching Slots on Canopy Figure 5b - Assembled Fan Hanging to Ceiling Plate Hooks from Ceiling Plate Hooks 41457-01 7/2000...

  • Page 15: Step 6 - Installing The Remote

    Battery Cover ence that may cause undes- electrician. ired operation. • To avoid overheating and possible damage to other equipment, do not install Figure 6a - Setting the Code on the to control a receptacle, Transmitter continued 41457-01 7/2000...
  • Page 16 5. Mount the remote holder using the two screws provided with the remote kit. Slide out center piece Figure 6b - Mounting the Remote Figure 6c - Setting the Code on the on the holder to see screw holes. Holder Receiver 41457-01 7/2000...
  • Page 17 White wire from receiver ............White wire from fan Black wire from receiver ............Black wire from fan NOT pull the fan or light chains Black/White wire from receiver ........Black/White wire from light while power is connected. 41457-01 7/2000...

  • Page 18: Step 7 - Wiring The Fan

    (two wall switches re- the wires gently into the outlet quired) box. Use connection 2 on page 19 if there is no separate wall switch power wire for the light fixture. Note: Wall switches not included. continued 41457-01 7/2000...
  • Page 19 Connect Blk/Wht Wire from fan Pipe (not present 3 Wires to Ceiling Black Wire if there with flush mounting From Fan is no separate Wall Switch Wire option) for the light fixture. Figure 7a - Wiring The Fan 41457-01 7/2000...

  • Page 20: Step 8 - Attaching The Canopy

    Ceiling in Hanger Ball Plate WARNING Failure to complete sub-steps Canopy 1 through 3 could cause fan to fall. (Sub-step 3 not applicable for flush mounting.) Figure 8a - Attaching Canopy to Ceiling Plate 41457-01 7/2000...

  • Page 21: Step 9 - Assembling Fan Blades

    ® STEP 9 - ASSEMBLING FAN BLADES Hunter fans use several styles of fan feature a decorative medallion as If you used grommets, the blades blade irons (brackets that hold the well as a blade iron. Insert the may appear slightly loose after blade to the fan).
  • Page 22 Figure 9d, and attach lightly to the fan. In- sert the second blade mounting screw, then securely tighten both mounting screws. Figure 9d - Attaching Blade Irons to Hub of Fan Assembly 41457-01 7/2000...

  • Page 23: Step 10 - Attaching The Switch Housing

    Connector into the third hole in the upper Upper switch housing. Tighten all three Switch screws firmly. Housing Figure 10b - Mounting the Upper Figure 10a - Attaching Upper Switch Switch Housing Housing to Switch Housing Mounting Plate 41457-01 7/2000...
  • Page 24 Table 10-1 SWITCH HOUSING Fan with no light See Figure 10c fixture included Your hunter fan includes one of two lower switch housings. Both lower Fan with acces- switch housings are shown in Figures sory light kit in- See Figure 10c 10c and 10d.
  • Page 25 FIXTURE. Figure 10e - Plug Connection and one way. Make sure that both Lower Switch Housing Installation connectors are properly aligned before connecting them together. Incorrect connection could cause improper operation and damage to the product. 41457-01 7/2000...

  • Page 26: Step 11 - Installing Light Fixture

    INSTALLING INCLUDED ACCES- WARNING Information for wiring and installing SORY LIGHT KIT • To avoid possible electrical all included Hunter light fixtures fol- 1. Remove the plug and switch shock, before installing lows. housing caps from the lower light fixtures, disconnect Note: If you purchased a fan with- switch housing.
  • Page 27 Switch Housing Cap Wires From Wires From The Fan The Light Kit 4. Screw the fixture into the lower switch housing. Thread the lockwasher and nut provided over Figure 11b - Wiring Connections for Light Kit continued 41457-01 7/2000...
  • Page 28 #6-32 Locking Ring x 3/8" housing assembly screws. Notch in Ring See Figure 10e on page 25. Threaded Lamp Holder Figure 11d - Assembling the Locking Ring Threaded Locking Ring Globe Figure 11c - Installing the Globes 41457-01 7/2000...
  • Page 29 23 to reattach the lower switch Do not overtighten. housing. 3. Install and tighten thumbscrews manually. Do not overtighten. Thumbscrew 4. Install bulbs. Thumb- Globe screw Silencer Band Bulb Globe Figure 11e - Single-Globe Fixture Figure 11f - Multi-Light Fixture 41457-01 7/2000...

  • Page 30: Operating Your Hunter Fan And Remote

    ® OPERATING YOUR HUNTER FAN AND REMOTE Your Hunter Fan comes with an • The chain uses a breakaway causing a draft. Refer to Figure acessory pull chain pendant for both connector that separates if the 12a. fan and light operation. To install the chain is jerked.
  • Page 31 ® OPERATING YOUR HUNTER FAN brighten the light. Release the WITH A REMOTE light button when the desired light level is reached. The light Display WARNING dimmer range is 20% to 100%. HIGH Once receiver is installed and The Light key has auto resume,...

  • Page 32: Cleaning And Maintenance

    An artistic agent may be used, but never use abrasive cleaning agents as they will damage the finish. 41457-01 7/2000...

  • Page 33: Troubleshooting

    5. Remove shipping bumpers. Noisy operation. 1. Blade brackets screwed loosely to 1. Tighten screws until snug. motor. 2. Blade screwed loosely to blade iron. 2. Tighten screws until snug. 3. Blade cracked. 3. Replace all blades. continued 41457-01 7/2000...
  • Page 34 4. Turn power off, support the fan canopy tabs. very carefully, and check that the hanger ball is properly seated. If you have tried these troubleshooting solutions and still have trouble, call 901-248-2222 or visit our Web site at http://www.hunterfan.com. continued 41457-01 7/2000...
  • Page 35 2. RF interference. 2. Turn OFF wall switch for 5 seconds, then turn back ON. 3. Continuing RF interference. 3. Change dip switch settings to a different code in both Transmit- ter and Receiver. 41457-01 7/2000...
