Runco XP-65DHD Quick Manual

The Runco XP-65DHD plasma establishes a higher threshold for flat panel
display products. Runco's XP-65DHD's outstanding performance is so good
that it was the first plasma to meet stringent THX certification standards.
Native Resolution:
Screen Size:
Screen Aspect Ratio:
Image Area (W x H inches)
DTV Compatibility:
Contrast Ratio:
ISF Settings:
Data/Graphics Compatibility:
Power Requirements:
Power Consumption:
Operating Environment:
Dimensions (w/o stand)
R U N C O
Weight:
Regulatory Approvals:
Limited Warranty:
The XP-65DHD ships with:
Aspect Ratios:
Video Processing:
Video Standards:
Supported Signal Timings:
Output:
Inputs:
Communications Control Ports:
Screen Trigger/ Masking Output:
Power Requirements:
Dimensions:
Features:
BRiC Tool:
Specifications are subject to change without notice.
1920 x 1080
65 in. (diagonal)
16:9
57" x 32"
480i, 480p, 576i, 576p, 720p, 1080i, 1080p (24,50,60 Hz)
400:1 (measured at 100 lux); 5000:1 maximum
Yes
Up to 1920 x 1200
100-240V AC, 50/60Hz
790 W (.1 watts in standby), maximum
40°- 95º F (5º- 35ºC), 20–80% Humidity (non-condensing)
Altitude = up to 9,100 feet (2,800m)
Width: 62.33 in (1582.4 mm
Depth: 4.16 in. (104.1 mm)
Height: 39.7 in (958 mm)
163lbs. (73.98 kg)
FCC Class B, CE, C-Tick
Two years parts and labor from the date of shipment from Runco.
RuncoCare™ and Runco RedCarpet™ plans are also available.
Power cords (US, EU), remote control and two batteries (AAA), warranty
information and registration card, Runco Operating manual, cable ties.
Runco DHD Controller Specifications
4:3, 16:9, Letterbox, VirtualWide™ , Native, VirtualCinema™ and Cinema
ViVix III™ 1080p output
NTSC, PAL, ATSC and SECAM
1080p (23.98, 24, 50, 59.94, 60), 1080i (50, 50 Australia, 59.94, 60), 720p
(23.98, 24, 25, 29.97, 30, 50, 60), 576p/i, 480p/i, SCART RGB,
standard PC timings
(1) HDMI v1.3 w/ HDCP and Deep Color up to 12 bits/channel; (1) RJ-11
for display control; (1) RJ-11 for display control
(1) Composite; (2) S-Video; (1) Component; (2) HD - R (Pr), G (Y),
B (Pb), H, V; (2) HDMI v1.3 w/HDCP and Deep Color up to 12 bits/channel
Discrete infrared remote, (1) RS-232 9 pin connector; front panel
(3) +12 VDC, each rated at 250 mA with over-current protection
100-240V AC (auto sensing) 50/60 Hz, 40W
Width: 17 1/2 in. (444.50 mm); Depth: 11 3/16 in. (284.10 mm);
Height:3 3/4 in. (95.25 mm), Weight: 13 lbs. (5.9 kg)
Highly-compatible with today's video sources, fully-compliant HDMI/HDCP
repeater, full ISF™ calibration controls, easy firmware upgrades via USB or
serial, customizable splash screen and side-curtain colors
Backup, Recovery and Clone tool for ease of saving, restoring or cloning
calibrations settings
R u nc o • 8 7 7- 4 8 7 - 5 6 7 1
www. Ru n c o . co m
Runco ® CinemaWall
XP-65DHD Plasma
™
© 2009 Runco, All rights reserved
