GE Profile PDW8700JBB Dimension Manual

TM
PDW8700JWW/CC/BB – GE Profile

Built-In Dishwasher Dimensions

(in inches)
25-1/4
24
22-1/2
34" MIN.
adj. to 35"
21-1/4
4 (Adjustable)
4

Electrical Rating

Voltage AC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Hertz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Total connected load amperage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9.1
Calrod ® heater watts max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 875
For use on adequately wired 120-volt, 15-amp circuit having 2-wire
service with a separate ground wire. This appliance must be
grounded for safe operation.
Specification Created 9/03
250122
™ Stainless Built-In Dishwasher
Wood Insert Cutout Dimensions (in inches)
Kits: GPF825 and GPF875
See Detail E for 3/4" Panel
Door insert
B
Kit
GPF825
27-1/2
GPF875
Hot
water
34-1/2±1/4"
line on
left
of countertop
For answers to your Monogram,
GE ® appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center
Detail E for 3/4 panel only
1-7/8
F
F
Section F-F
C
Front View
A
3/8
3/4
A B C
25-1/16" 23-1/2" N/A
25-7/16" 23-3/4" 1/4"
This wall area
must be free of
90°
pipes or wires
24"
4 4
MIN.
4
5 5
6 6
Underside
to floor
Plumbing and electrical
2
service must enter
inside shaded area
19" MIN. from wall 24" From wall
24" MIN.
Listed by
Underwriters
R
Laboratories
® GE Profile ™ or
® service, 800.626.2000.
1-7/8
20
Back View
Panel
Thickness
1/4"
3/4"
Countertop
90°
Electrical
wiring is
3" from
cabinet
Electrical
wiring on
right
As an ENERGY STAR ® partner,
GE has determined that this product
meets the ENERGY STAR ®
guidelines for energy efficiency.
