GE Profile PDW8700N Dimensions And Installation Information

PDW8700L
GE Profile Built-In Dishwasher
™
Dimensions and Installation Information (in inches)
Electrical Rating
Voltage AC.......................................................... 120
Hertz.....................................................................
Total connected load amperage............. 9.1
Calrod heater watts max........................ 875
®
For use on adequately wired 120-volt,
15-amp circuit having 2-wire service
with a separate ground wire. This appliance
must be grounded for safe operation.
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
with Stainless Interior
Wood Insert Cutout Dimensions (in inches)
See Detail E for 3/4" Panel
See Detail E for 3/4" Panel
60
Door insert
A
Door insert
A
B
B
Kit
GPF825
GPF875
or
™
service,
Detail E for 3/4 panel only
1-7/8
Detail E for 3/4 panel only
F 20
1-7/8 1-7/8
F
Section F-F
F 20
F
Section F-F C
Front View Back View
C
3/8
Front View Back View
3/8
3/4
3/4
Thickness
A B C
25-1/16" 23-1/2" N/A
25-7/16" 23-3/4" 1/4"
Hot
water
line on
left
25-1/4
MAX.
22-1/2
1-7/8
33-13/16" MIN.
adj. to 35"
21-1/4
Panel
1/4"
3/4"
4
This wall area
must be free of
90°
pipes or wires
24"
4
MIN.
5
34" to 34-3/4"
6
Underside
of countertop
to floor
Plumbing and electrical
2
service must enter
inside shaded area
19" MIN. from wall
24" MIN.
R
Specification Created 7/05
24
27-1/2
4 (Adjustable)
Countertop
90°
Electrical
4
wiring is
4 3" from
cabinet
5
Electrical
wiring on
6
right
24" From wall
As an ENERGY STAR
Listed by
partner, GE has determined
Underwriters
that this product meets the
Laboratories
ENERGY STAR guidelines
for energy efficiency.
250201
®
