Built-In Cooktop
FPGC3685K S
Signature Features
PowerPlus® Boil
Boil water fast.
Pro-Select® Controls
Precise control at your fingertips.
PowerPlus® FullRange Burner
Go from a 500-BTU simmer to a
17,000-BTU boil quickly.
Continuous Grates
Continuous grates make it easy to
move heavy pots and pans between
burners without lifting.
36" Gas
Product Dimensions
Width
36"
Depth
21-3/4"
Height
4-1/4"
More Easy-To-Use Features
Heavy-Duty Grates and
Professional-Style Knobs
Low Simmer Burner
Perfect for delicate foods and sauces.
Fits-More™ Cooktop
The Fits-More™ cooktop features five
burners so you can cook more at once.
Stainless Steel Recessed Cooktop
Available in:
Stainless
(S)
Burners
BTU
Right Front
12,000
Right Rear
5,000
Left Front
9,500
Left Rear
9,500
Center
500 to 17,000
frigidaire.com
