Specifications - Samsung iPolis SNP-5200 Specifications

Dimensions
Unit : mm (inch)
155 (6.1")
155 (6.1")
SNP-5200
248 (9.76")
162 (6.38")
248 (9.76")
SNP-5200H
Accessories (Optional)
SBP-300WM1 SBP-300WM SBP-300CM SBP-300LM
SBP-300HM1
SBP-300KM
SBP-300PM
not needed for
"H" models
SHP-3700F
not needed for
"H" models
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Road, Suite 700, Ridgefield Park, NJ 07660, UNITED STATES
Tol Free : 1-877-213-1222 Fax : 1-201-373-0124
www.samsungsecurityusa.com
1.3Megapixel HD 20x PTZ Dome Network Camera
SNP-5200/5200H
1.3M
20x
D&N ICR

Specifications

Video
imaging device 1/3" 1.3M PS CMOS
Total Pixels 1,384(H) x 1,076(V)
effective Pixels 1,329(H) x 1,049(V)
Scanning System Progressive
Color : 0.7Lux (F1.6, 50IRE), 0.01Lux (Sens-up 60x, 50IRE)
Min. illumination
B/W : 0.08Lux (F1.6, 50IRE), 0.001Lux (Sens-up 60x, 50IRE)
S / N Ratio 52dB
Video output CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
LeNS
Focal Length (Zoom Ratio) 4.45 ~ 89mm (20x)
Max. Aperture Ratio F1.6(Wide) / F2.9(Tele)
Angular Field of View H : 56.56˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
Min. object distance 1m (3.28ft)
Focus Control AF / One-shot AF / Manual
Lens Type DC auto iris
Mount Type Board-in type
PAN / TiLT / RoTATe
Pan Range 360˚ Endless
Pan Speed Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Tilt Range 190˚(-5˚ ~185˚ )
Tilt Speed Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Preset 255ea
Preset Accuracy ±0.1˚
oPeRATioNAL
Camera Title
Off / On (Displayed up to 15 characters)
day & Night
Auto (ICR) / Color / B/W
Backlight Compensation Off / BLC / HLC
Contrast enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
digital image Stabilization Off / On
Motion detection Off / On (4 programmable zones)
Privacy Masking Off / On (8 programmable zones)
Sens-up (Frame integration) Off / Auto (2x ~ 60x)
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / AWC / Manual / Indoor / Outdoor
electronic Shutter Speed Auto / A.FLK / Manual (1/30 ~ 30,000sec)
digital Zoom 16x
Flip / Mirror Off / On
intelligent Video Analytics Scene Change, Virtual Line, Enter / Exit, Appear / Disappear
Alarm i/o Input 4ea / Output 2ea (Relay)
Remote Control interface RS-485/422
RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Bosch, Vicon, GE
NeTWoRk
ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264, MPEG-4, MJPEG
Resolution 1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
Max. Framerate 30fps at all resolutions
Video Quality Adjustment H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
Bitrate Control Method H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 10 profiles)
Audio i/o Mic / Line in, Line out
Audio Compression Format G.711 u-law
Audio Communication Bi-directional audio
iP IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
Protocol
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
Security
IP address filtering, User access log, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 10 users at unicast mode
Memory Slot SD/SDHC memory slot
oNViF Conformance Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Webpage Language
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Web Viewer
Supported Browser : Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Apple Safari
Central Management Software NET-i viewer
eNViRoNMeNTAL
operating Temperature / Humidity -10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
ingress Protection N/A
eLeCTRiCAL
input Voltage 24V AC, PoE+ (IEEE802.3at)
Power Consumption Max. 21W
MeCHANiCAL
Color / Material Ivory / Plastic
dimensions (WxH) Ø155.0 x 243.4mm (Ø6.1" x 9.58")
Weight 2.1Kg (4.63 lb)
Design and specifications are subject to change without notice.
PoE+
SNP-5200N/P
Eco mark
The represents
Samsung Techwin's will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
SNP-5200HN/HP
-50°C ~ +50°C (-58°F ~ +122°F) / up to 100% RH
IP66 and IK10 Grade (Waterproof)
Max. 25W (Heater off), Max. 52W (Heater on)
* Heater works at AC input only.
Ivory / Aluminum / Plastic sun-shield
Ø248.0 x 316.5mm (9.76" x 12.46")
4.6Kg (10.14 lb)
DISTRIBUTED BY
I.E-1104
