Samsung iPolis SNP-5200H Technical Specifications

SNP - 5200H/5200
1.3Megapixel HD 20x Network PTZ Dome Camera
SNP-5200H
1.3M
20x

Key Features

• Max. 1.3M (1280 x 1024) resolution
• 16 : 9 HD (720p) resolution support
• 4.45 ~ 89mm (20x) optical zoom, 16x digital zoom
• H.264, MPEG-4, MJPEG multiple codec
• PoE plus, SD memory, IP66, bi-directional audio support
Accessories (Optional)
SBP-300WM1
SBP-300WM SBP-300CM
SBP-300HM1 SBP-300PM
SBP-300KM
not needed for
"H" models
Dimensions
155.0 (6.1")
SNP-5200H
162.0 (6.38")
248.0 (9.76")
FIRST EDITION 09-2011
SNP-5200
PoE+
D&N ICR
SBP-300LM
SHP-3700F
not needed for
"H" models
Unit : mm (inch)
155.0 (6.1")
248.0 (9.76")

Technical Specifications

SNP-5200N/P
VIDEO
Imaging Device 1/3" 1.3M PS CMOS
Total Pixels 1,384(H) x 1,076(V)
Effective Pixels 1,329(H) x 1,049(V)
Scanning System Progressive
Color : 0.7Lux (F1.6, 50IRE), 0.01Lux (Sens-up 60x, 50IRE)
Min. Illumination
B/W : 0.08Lux (F1.6, 50IRE), 0.001Lux (Sens-up 60x, 50IRE)
S / N Ratio 52dB
Video Output
CVBS : 1.0 Vp-p / 75Ω composite, 704 x 480(N), 704 x 576(P), for installation
LENS
Focal Length (Zoom Ratio) 4.45 ~ 89mm (20x)
Max. Aperture Ratio F1.6(Wide) / F2.9(Tele)
Angular Field of View H : 56.56˚(Wide) ~ 3.10˚(Tele) / V : 43.32˚(Wide) ~ 2.34˚(Tele)
Min. Object Distance 1m (3.28ft)
Focus Control AF / One-shot AF / Manual
Lens Type DC auto iris
Mount Type Board-in type
PAN / TILT / ROTATE
Pan Range 360˚ Endless
Pan Speed Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Tilt Range 190˚(-5˚ ~185˚ )
Tilt Speed Preset : 500˚/sec, Manual : 0.024˚/sec ~ 120˚/sec
Preset 255ea
Preset Accuracy ±0.1˚
OPERATIONAL
Camera Title Off / On (Displayed up to 15 characters)
Day & Night Auto (ICR) / Color / B/W
Backlight Compensation Off / BLC / HLC
Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On)
Digital Noise Reduction SSNRIII (2D+3D noise filter) (Off / On)
Digital Image Stabilization Off / On
Motion Detection
Off / On (4 programmable zones)
Privacy Masking Off / On (8 programmable zones)
Sens-up (Frame Integration) Off / Auto (2x ~ 60x)
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed Auto / A.FLK / Manual (1/30 ~ 30,000sec)
Digital Zoom 16x
Flip / Mirror Off / On
Intelligent Video Analytics Scene Change, Virtual Line, Enter / Exit, Appear / Disappear
Alarm I/O Input 4ea / Output 2ea (Relay)
Remote Control Interface RS-485/422
RS-485 Protocol Samsung-T/E, Pelco-P/D, Panasonic, Honeywell, AD, Bosch, Vicon, GE
NETWORK
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.264, MPEG-4, MJPEG
Resolution 1280 x 1024, 1280 x 720P (HD), 1024 x 768, 800 x 600, 640 x 480, 320 x 240
Max. Framerate 30fps at all resolutions
Video Quality Adjustment H.264, MPEG-4 : Compression level, Target bitrate level control
MJPEG : Quality level control
Bitrate Control Method H.264, MPEG-4 : CBR or VBR, MJPEG : VBR
Streaming Capability
Multiple streaming (Up to 10 profiles)
Audio I/O
Mic / Line in, Line out
Audio Compression Format G.711 u-law
Audio Communication Bi-directional audio
IP IPv4, IPv6
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE
Protocol
FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, ONVIF
HTTPS(SSL) login authentication, Digest login authentication
Security
IP address filtering, User access log, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 10 users at unicast mode
Memory Slot SD/SDHC memory slot
ONVIF Conformance Yes
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish,
Webpage Language
Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatian, Hungarian, Greek
Supported OS : Windows XP / VISTA / 7, MAC OS
Web Viewer
Supported Browser : Internet Explorer 6.0 or Higher, Firefox, Google Chrome, Apple Safari
Central Management Software NET-i viewer
ENVIRONMENTAL
Operating Temperature / Humidity -10°C ~ +50°C (+14°F ~ +122°F) / 20% ~ 80% RH
Ingress Protection N/A
ELECTRICAL
Input Voltage
24V AC, PoE+ (IEEE802.3at)
Power Consumption Max. 21W
MECHANICAL
Color / Material
Ivory / Plastic
Dimensions (WxH)
Ø155.0 x 243.4mm (Ø6.1" x 9.58")
Weight 2.1Kg (4.63 lb)
SNP-5200HN/HP
-50°C ~ +50°C (-58°F ~ +122°F) / up to 100% RH
IP66 Grade (Waterproof)
Max. 25W (Heater off), Max. 52W (Heater
on)
* Heater works at AC input only.
Ivory / Aluminum / Plastic sun-shield
Ø248.0 x 316.5mm (9.76" x 12.46")
4.6Kg (10.14 lb)
