Aprilaire 5000 Installation Insructions

Electronic air cleaner
Hide thumbs Also See for 5000:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual

SAFETY INSTRUCTIONS

Read the safety and installation instructions carefully. They will help ensure a correct and SAFE installation of the
Aprilaire
®
Electronic Air Cleaner.
WARNING
120 Volts may cause serious injury from electrical shock.
Disconnect power to the furnace/air handler before
starting installation. Leave power disconnected until
installation is completed.
Arcing in electrical components may cause an explosion.
Do not install unit where explosive gasses will be present.
Sharp edges may cause injury from cuts. Use care when
cutting and handling sheet metal.
To reduce the risk of electrical shock, this equipment
has a grounding-type (three prong) plug. This plug will fit
only into a grounding-type power outlet. If the plug does
not fit into the outlet, contact qualified personnel to install
the proper outlet. Do not alter this plug in any way.
To reduce the risk of electrical shock, locate product
so that the power cord can be plugged into an electrical
outlet without the use of an extension cord.

TABLE OF CONTENTS

Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Locating the Air Cleaner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the Outer Housing and Inner Housing Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wiring and Startup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Install the LED Base. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Install the Air Cleaner Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Troubleshooting Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Maintenance Recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Applications with a Humidifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Model 5000 Electronic Air Cleaner
Installation Instructions
CAUTION
To prevent component failure, do not install the air
cleaner on the warm air supply or in an area where
the temperature may exceed 140°F. This may include
areas above heat exchangers in downflow furnaces or
above exhaust flues in lowboy furnace cold air returns.
The air cleaner must be installed where the ambient
air temperature remains between 32°F and 140°F
[0°C and 60°C].
Installation must conform to all applicable codes.
Do not install an atomizing humidifier upstream of the
air cleaner. Water or mist will cause power supply to
shut down.
Do not plug the air cleaner into an outlet that is always
live. The outlet must only be live when the furnace/air
handler blower is operating. Failure to properly wire
the outlet can result in excessive ozone production.
1

Advertisement

Table of Contents
loading

Related Manuals for Aprilaire 5000

Summary of Contents for Aprilaire 5000

  • Page 1: Table Of Contents

    Model 5000 Electronic Air Cleaner Installation Instructions SAFETY INSTRUCTIONS Read the safety and installation instructions carefully. They will help ensure a correct and SAFE installation of the Aprilaire ® Electronic Air Cleaner. WARNING CAUTION 120 Volts may cause serious injury from electrical shock.

  • Page 2: Specifications

    Do not wire the Control to EAC terminals of HVAC system. These terminals are 120 Volts and will damage the Air Cleaner Control. DIMENSIONS FIGURE 1 – Dimensions of the Model 5000 Electronic Air Cleaner 12" 31" with Door 28-1/8" without Door 23-7/8"...

  • Page 3: Components

    COMPONENTS FIGURE 2 – Model 5000 Electronic Air Cleaner Control & LED Base Inner Housing Assembly Control Electrode Ionizer Frame Outer Housing with Door Retainers Inner Latches Housing #501 Media On/Off Switch Power Pack/Door Assembly Pleat Spacers (6) 90-1152...

  • Page 4: Locating The Air Cleaner

    LOCATING THE AIR CLEANER The Model 5000 can be installed in a FIGURE 3 – Clearance for Inner Housing Removal variety of ways. The figures below show some of the possibilities. The air cleaner may be installed on the It is important to leave enough room to remove left or right side of the air handler.

  • Page 5: Installing The Outer Housing And Inner Housing Assembly

    INSTALLING THE OUTER HOUSING AND INNER HOUSING ASSEMBLY WARNING 120 Volts may cause serious injury from electrical shock. Leave power disconnected until installation is complete. 1. Turn the system OFF at the thermostat by changing the mode selector to OFF – FIGURE 10 this may be a switch or a pushbutton, depending on the type of thermostat.

  • Page 6: Wiring And Startup

    For 120-volt equipment without EAC terminals: A. Use an Aprilaire Model 51 Current Sensing Relay to wire a single receptacle outlet as shown in Figure 13. Refer to the instructions provided with the Model 51 for details on wiring requirements.
  • Page 7 FIGURE 12 FIGURE 13 IT IS COMMON TO SEE SPADE LINE TERMINALS ON THE HVAC VOLTAGE EQUIPMENT CONTROL CENTER CIRCUIT BOARD. REFER TO THE WIRE USE ONLY FULLY INSULATED INSTRUCTIONS PROVIDED FITTINGS (FEMALE QUICK WITH THE MODEL 51 FOR DISCONNECTS SHOWN). WIRING DETAILS HVAC Equipment WIRE...

  • Page 8: Install The Led Base

    STOP! Complete installation and checkout of the air cleaner before proceeding with installation of the controls. INSTALL THE LED BASE 1. Disconnect power to the furnace or air handler at the electrical service panel. WARNING 120 Volts may cause serious injury from electrical shock. Disconnect power to the furnace/air handler before starting installation.

  • Page 9: Install Air Cleaner Control Near Thermostat

    OPTION 1 – INSTALL THE AIR CLEANER CONTROL NEAR THE THERMOSTAT Run a 3-conductor cable between the LED Base and the FIGURE 18 low voltage controls of the HVAC equipment. Remove the cover from the LED Base and wire the LED Base to the low voltage controls of the HVAC equipment as shown in Diagram 1.
  • Page 10 OPTION 1 – INSTALL THE AIR CLEANER CONTROL NEAR THE THERMOSTAT (CONTINUED) DIAGRAM 2 – Single Transformer Systems THERMOSTAT DISCONNECT EXISTING WIRE FROM THERMOSTAT G (FAN) TERMINAL AND USE WIRE NUT TO CONNECT TO GF WIRE FROM AIR CLEANER CONTROL HEATING COOLING SEE NOTE 2...
  • Page 11 OPTION 2 – AIR CLEANER CONTROL MOUNTED ON THE AIR CLEANER FIGURE 20 FIGURE 21 Run a 5-conductor cable between the LED Base and the low voltage controls of the HVAC equipment. Remove the cover from the LED Base and wire to the low voltage controls of the HVAC equipment as shown in Diagram 4.
  • Page 12 OPTION 3 – INSTALL THE AIR CLEANER CONTROL NEAR THE HVAC SYSTEM Remove the backplate from the Air Cleaner Control, and install FIGURE 22 the backplate at the desired location for the Air Cleaner Control. Do not install the Air Cleaner Control on supply ductwork. Run a 5-conductor cable between the Air Cleaner Control and the LED Base.
  • Page 13 INSTALL THE AIR CLEANER CONTROL SET UP FILTER LIFE INDICATOR – SETTING THE REPLACEMENT FREQUENCY FIGURE 23 Set the jumper on the back of the Air Cleaner Control circuit board, as shown in Figure 23, to the desired frequency for filter changes. TABLE 2 –...

  • Page 14: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE(S) SOLUTION(S) ON/OFF switch not in ON position Turn switch ON Air cleaner not plugged in Plug in air cleaner Light does not come on at all after Insufficient current to activate Wrap blower common wire around relay bracket more - see 90 seconds Model 51 relay Figure 14 on page 7 for wire wrapping method...

  • Page 15: Maintenance Recommendations

    FIGURE 27 – Maintenance Bus Bar Ionizer Wires Control Electrode Ionizer Frame Control Electrode Media Ground Contacts Inner Housing Ionizer Frame Control Electrode Ground 90-1151 Contact MAINTENANCE RECOMMENDATIONS Whenever performing maintenance on the air cleaner, turn off the HVAC system, then turn off and unplug the air cleaner. Before performing any maintenance item listed below: 1.

  • Page 16: Applications With A Humidifier

    • Replace the media no less often than once per year. • Always use Genuine Aprilaire Model 501 Replacement Media. The Model 5000 is designed to work only with Genuine Aprilaire 501 Replacement Media. Use of other media will damage your Model 5000 Electronic Air Cleaner.
