Personal Safety System; To Remove The Second Row Cushion; To Install The Second Row Cushion - Ford Escape Owner's Manual

Seating and Safety Restraints

To remove the second row cushion

1. Lift the yellow tab to release the
hinges.
2. Pull the cushion to the outboard
side of the vehicle.

To install the second row cushion

1. Push the cushion to the inboard
side of the vehicle.
2. Make sure that the hinges are
locked into place.

PERSONAL SAFETY SYSTEM™

The Personal Safety System provides an improved overall level of frontal
crash protection to front seat occupants and is designed to help further
reduce the risk of airbag-related injuries. The system is able to analyze
different occupant conditions and crash severity before activating the
appropriate safety devices to help better protect a range of occupants in
a variety of frontal crash situations.
Your vehicle's Personal Safety System consists of:
• Driver and passenger dual-stage airbag supplemental restraints.
• Front safety belts with pretensioners, energy management retractors,
and safety belt usage sensors.
• Driver's seat position sensor
• Front passenger sensing system
• "Passenger airbag off" or "pass airbag off" indicator lamp
• Front crash severity sensor.
• Restraints Control Module (RCM) with impact and safing sensors.
124
2012 Escape (204)
Owners Guide, 1st Printing
USA (fus)
