Model No. WLTL19013
Serial No.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing or damaged parts,
we will guarantee complete
satisfaction through direct assis-
tance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The trained technicians on our
Customer Hot Line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weslo Cadence 200cs
Summary of Contents for Weslo Cadence 200cs
- Page 1 CUSTOMER HOT LINE: 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Save this manual new products, prizes, for future reference. fitness tips, and much more!
-
Page 2: Table Of Contents
4. Keep the treadmill indoors, away from mois- page 7. To purchase a surge suppressor, see ture and dust. Do not put the treadmill in a your local WESLO dealer or call 1-800-806- garage or covered patio, or near water. 3651 and order part number 146148. - Page 3 15. Never start the treadmill while you are stand- 20. Do not change the incline of the treadmill by ing on the walking belt. Always hold the placing objects under the treadmill. handrails while using the treadmill. 21. Inspect and properly tighten all parts of the 16.
-
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the WESLO ® CADENCE 200 please call our Customer Service Department toll-free CS treadmill. The CADENCE 200 CS treadmill com- at 1-800-999-3756, Monday through Friday, 6 a.m. bines advanced technology with innovative design to until 6 p.m. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 6 4. See inset drawing 4c. If there is a plastic tie in the square hole in the bottom of the Right Handrail (6), remove it. Remove the five screws holding the Console Base (1) and Console Plate (4) together. Attach the Console Plate (4) to the Right and Left Handrails (6, 7) by pushing the Handrails inward and tightening two Console Bolts (9) and Handrail Washers (11) into the Console Plate and...
-
Page 7: Operation And Adjustment
Adapter drawing 1 at the right). To purchase a surge sup- Surge Suppressor pressor, see your local WESLO dealer or call 1-800- 806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). -
Page 8: Diagram Of The Console
DIAGRAM OF THE CONSOLE Monitor Display Water Bottle Holder Speed Control (Water bottle is not included) Note: If there is a thin sheet of clear plastic on the console, remove it. Clip CAUTION: Before operating the console, read the following precautions. •... - Page 9 Follow the steps below and to operate the console. Follow your progress with the monitor modes. Insert the key fully into the console. When the power is turned on, the con- Inserting the key will sole will automatically not turn on the dis- scan through five play.
-
Page 10: How To Fold And Move The Treadmill
HOW TO CHANGE THE INCLINE OF THE TREADMILL To vary the intensity of your exercise, the incline of the treadmill can be changed. There are three incline levels. Before changing the incline, remove the key and unplug the power cord. Next, fold the treadmill to the stor- age position (see HOW TO FOLD THE TREADMILL FOR STORAGE on page 10). -
Page 11: To Lower Treadmill For Use
HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the stor- age position as described above. Make sure that the latch pin is fully inserted into the hole in the handrail and locked into place as described above. 1. -
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that meets all of the specifications described on page 7. b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 2”–3”...
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning If your goal is to strengthen your cardiovascular sys- this or any exercise program, consult your tem, your exercise must be “aerobic.” Aerobic exercise physician. This is especially important for in- is activity that requires large amounts of oxygen for dividuals over the age of 35 or individuals prolonged periods of time. - Page 15 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
- Page 16 PART LIST—Model No. WLTL19013 R0103A Key No. Qty. Description Key No. Qty. Description Console Storage Latch Speed Control Wheel Nut Key/Clip Motor Assembly Console Plate Power Cord Screw Large Warning Decal Right Handrail Reed Switch Left Handrail Wire Tie Clamp Battery Cover Reed Switch Clip Console Bolt/Motor Tension Bolt...
- Page 17 PART IDENTIFICATION CHART Remove this chart and use it to identify small parts during assembly. Save this chart and the EXPLODED DRAWING/PART LIST for future reference. Screw (5)–3 Console Bolt (9)–2 Star Washer (33)–2 Formed Washer (31)–4 Handrail Bolt (12)–4 Handrail Nut (17)–4 Handrail Washer (11)–4 Wheel Bolt (14)–2...
- Page 18 EXPLODED DRAWING—Model No. WLTL19013 R0103A...
-
Page 19: Ordering Replacement Parts
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAW- ING in the center of this manual) WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
Need help?
Do you have a question about the Cadence 200cs and is the answer not in the manual?
Questions and answers
The dispaly for speed, distance, etc is not working. Showing 0 on everything and not changing when using the threadmill. How can this be corrected to show all options?
To fix the display on the Weslo Cadence 200cs treadmill when it shows 0 and does not change:
1. Check the console batteries (see assembly step 7). Replace them if drained.
2. Remove the key and unplug the power cord.
3. Remove the screws from the hood and carefully take off the hood.
4. Locate the Reed Switch and Magnet on the left side of the pulley.
5. Turn the pulley until the Magnet aligns with the Reed Switch.
6. Ensure the gap between them is about 1/8 inch.
7. If needed, loosen the screw and adjust the Reed Switch position.
8. Retighten the screw, reattach the hood, plug in the treadmill, insert the key, and run it for a few minutes to check if the speed reading works.
