Model No. WLTL19011
Serial No.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing or damaged parts,
we will guarantee complete
satisfaction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for Weslo WLTL19011
Summary of Contents for Weslo WLTL19011
- Page 1 USER'S MANUAL Model No. WLTL19011 Serial No. Serial Number Decal QUESTIONS? If you have questions, or if there are missing or damaged parts, we will guarantee complete satisfaction through direct assis- tance from our factory. TO AVOID UNNECESSARY DE- LAYS, PLEASE CALL DIRECT TO OUR TOLL-FREE CUSTOMER HOT LINE.
-
Page 2: Table Of Contents
15 amps. To purchase a surge suppressor, see administered. your local WESLO dealer or call 1-800-999- 3756 and order part number 146148. 6. Keep children under the age of 12 and pets away from the treadmill at all times. - Page 3 15. The treadmill is capable of high speeds. 20. Inspect and properly tighten all parts of the Adjust the speed in small increments to avoid treadmill regularly. sudden jumps in speed. 21. Never drop or insert any object into any 16.
-
Page 4: Before You Begin
The model when you’re not exercising, the unique CADENCE 200 number of the treadmill is WLTL19011. The serial CS can be folded up, requiring less than half the floor number can be found on a decal attached to the tread- space of other treadmills. -
Page 5: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials; do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 6 4. Loosen the two Console Bolts (9) underneath the Console (1), and rotate the Console to the position shown. Push the Right and Left Handrails (6, 7) inward while you tighten the two Console Bolts. 5. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to do this step.
-
Page 7: Operation And Adjustment
To purchase a surge suppressor, see your local The temporary adapter should be used only until a WESLO dealer or call toll-free 1-800-999-3756 and properly grounded outlet (drawing 1) can be installed order part number 146148. Use only a single-outlet by a qualified electrician. - Page 8 DIAGRAM OF THE CONSOLE Monitor Display Speed Control Water Bottle Holder (Water bottle is not included) Note: If there is a thin sheet of clear plastic on the console, remove it. Clip Step onto the foot pads on the treadmill. Find the clip CAUTION: attached to the key (see the drawing above), and slide Before operating the...
- Page 9 Reset the console and start the walking belt. When you are finished exercising, stop the walking belt and remove the key. Turn the speed control to the RESET Step onto the foot pads, stop the walking belt and position. Note: Each remove the key from the console.
-
Page 10: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right. - Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, slide the latch pin to the right. Lock the pin in place by pressing the end of the pin into the slot in the storage latch as shown in the inset drawing.
-
Page 12: Maintenance And Trouble-Shooting
MAINTENANCE AND TROUBLE-SHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department toll- free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). PROBLEM: The power does not turn on SOLUTION: a. - Page 13 PROBLEM: The walking belt slows when walked on SOLUTION: a. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS). The surge suppressor must have a UL suppressed voltage rating of 400 volts or less and a minimum surge dissipation of 450 joules.
-
Page 14: Conditioning Guidelines
CONDITIONING GUIDELINES Aerobic Exercise WARNING: Before beginning If your goal is to strengthen your cardiovascular sys- this or any exercise program, consult your tem, your exercise must be “aerobic.” Aerobic exercise physician. This is especially important for in- is activity that requires large amounts of oxygen for dividuals over the age of 35 or individuals prolonged periods of time. - Page 15 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
- Page 16 PART LIST—Model No. WLTL19011 R1101A Key No. Qty. Description Key No. Qty. Description Console Frame Pivot Nut Speed Control Motor Assembly Key/Clip Power Cord Console Plate Large Warning Decal Screw Reed Switch Right Handrail Wire Tie Clamp Left Handrail Reed Switch Clip...
-
Page 18: Ordering Replacement Parts
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and the EXPLODED DRAW- ING in the center of this manual). WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health & Fitness, Inc. (ICON), warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of ninety (90) days from the date of pur- chase.
