Model No. WETL49710.2

Serial No.

USER'S MANUAL

Write the serial number in the space

above for reference.

Serial Number

Decal

CUSTOMER SERVICE

UNITED KINGDOM

Call: 08457 089 009

From Ireland: 053 92 36102

Website: www.iconsupport.eu

E-mail: csuk@iconeurope.com

Write:

ICON Health & Fitness, Ltd.

c/o HI Group PLC

Express Way

CASTLEFORD

WF10 5QJ

UNITED KINGDOM

AUSTRALIA

Call: 1800 993 770

E-mail: australiacc@iconfitness.com

Write:

ICON Health & Fitness

PO Box 635

WINSTON HILLS NSW 2153

AUSTRALIA

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Keep this manual

for future reference.

www.iconeurope.com

Table of Contents

Summary of Contents for Weslo WETL49710.2

Page 1 Model No. WETL49710.2 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd.
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4 20. Never leave the treadmill unattended while it 24. Never drop or insert any object into any is running. Always remove the key, unplug opening on the treadmill. the power cord, and press the power switch to the off position when the treadmill is not 25.
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the new WESLO CADENCE reading this manual, please see the front cover of this ® 21.0 treadmill. The CADENCE 21.0 treadmill offers a manual. To help us assist you, note the product model selection of features designed to make your workouts number and serial number before contacting us.
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly.
Page 7: Assembly
ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
Page 8 3. Attach the Handrails (69) to the Uprights (73) with four M10 x 45mm Bolts (2). Start all four Bolts, and then tighten each of them. 4. With the help of a second person, hold the con- sole assembly near the Uprights (73). Remove Console Assembly the tie from the Upright Wire (71).
Page 9 6. Attach the Latch Housing (72) to the left Upright (73) with two #10 x 1" Tek Screws (83); start both Screws, and then tighten each of them. Place the treadmill in the storage position (see HOW TO FOLD THE TREADMILL on page 17).
Page 10 8. Remove the Spring Clip (86) from the lower end of the Gas Spring (85). Press the lower end of the Gas Spring onto the Mount (92) on the bracket in the cen- ter of the Base (80). Note: It may be necessary to pivot the Frame (not shown) forward or backward slightly (see HOW TO LOWER THE TREADMILL FOR USE on...
Page 11: Operation And Adjustment
OPERATION AND ADJUSTMENT HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
Page 12 CONSOLE DIAGRAM Thumb Pulse Sensor Clip FEATURES OF THE CONSOLE IMPORTANT: If there is a sheet of plastic on the face of the console, remove the plastic. To prevent The treadmill console offers a selection of features damage to the walking platform, wear clean ath- designed to make your workouts more effective.
Page 13 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not See HOW TO TURN ON THE POWER at the left.
Page 14 4. Change the incline of the treadmill as desired. To reset the displays, press the Stop button, re- move the key, and then reinsert the key. To change the incline of the treadmill, press the 6. Measure your heart rate if desired. Incline increase and decrease buttons.
Page 15 HOW TO USE A PRESET WORKOUT At the end of each segment, a series of tones will sound and the next segment of the profile will begin 1. Insert the key into the console. to flash. If a new speed and/or incline setting is programmed for the next segment, the speed and/ See HOW TO TURN ON THE POWER on or incline will appear in the display and the tread-...
Page 16 THE INFORMATION MODE into the console. However, when you remove the key, the displays will remain lit, although the buttons will The console features an information mode that allows not function. If the demo mode is turned on, a “d” will you to turn on and turn off the demo mode and to appear in the left display while the information mode is select miles or kilometers as the unit of measurement.
Page 17: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL Before folding the treadmill, adjust the incline to Before moving the treadmill, fold it as described at the the lowest position. If you do not do this, you may left.
Page 18: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by fol- SYMPTOM: The console displays remain lit when lowing the steps below. Find the symptom that you remove the key from the console applies, and follow the steps listed. If further assis- tance is needed, please see the front cover of this a.
Page 19 Remove the five indicated M4.2 x 19mm Washer b. If the walking belt is overtightened, treadmill per- Head Screws (9). Then, carefully remove the Motor formance may decrease and the walking belt may Hood (56). become damaged. Remove the key and UNPLUG THE POWER CORD.
Page 20 SYMPTOM: The walking belt is off-center or slips b. If the walking belt slips when walked on, first when walked on remove the key and UNPLUG THE POWER CORD. Using the hex key, turn both idler roller a. If the walking belt has shifted to the left, first bolts clockwise, 1/4 of a turn.
Page 21: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 22 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
Page 23 NOTES...
Page 24: Part List
PART LIST Model No. WETL49710.2 R0413A Key No. Qty. Description Key No. Qty. Description M10 x 65mm Bolt Right Foot Rail M10 x 45mm Bolt Frame M4.2 x 19mm Screw Right Idler Roller Bracket M8 x 35mm Bolt Incline Motor M4.2 x 13mm Washer Head Screw...
Page 25: Exploded Drawing
EXPLODED DRAWING A Model No. WETL49710.2 R0413A...
Page 26 EXPLODED DRAWING B Model No. WETL49710.2 R0413A 23 11...
Page 27 EXPLODED DRAWING C Model No. WETL49710.2 R0413A...
Page 28: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, see the front cover of this manual. To help us assist you, please be prepared to provide the following information when contacting us: • the model number and the serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) RECYCLING INFORMATION This electronic product must not be disposed of in municipal waste.
