Schwinn 270 Recumbent Bike Assembly Manual

Assembly and owner's manual
Hide thumbs Also See for 270 Recumbent Bike:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Manual en Español Latino Americano:
http://www.schwinnfitness.com
270 /
230 /
430 /
470 /
ASSEMBLY MANUAL / OWNER'S MANUAL
2.5

Advertisement

Table of Contents
loading

Related Manuals for Schwinn 270 Recumbent Bike

Summary of Contents for Schwinn 270 Recumbent Bike

  • Page 1 270 / 230 / 430 / 470 / Manual en Español Latino Americano: ASSEMBLY MANUAL / OWNER’S MANUAL http://www.schwinnfitness.com...

  • Page 2: Table Of Contents

    Table of ConTenTs Important Safety Instructions - Assembly Operations Safety Warning Labels / Serial Number Adjustments Specifications Power Up / Idle Mode Before Assembly Quick Start Program Parts User Profiles Hardware Pausing or Stopping Tools Results / Cool Down Mode Assembly GOAL TRACK Statistics Moving the Machine Console Service Mode Leveling the Machine...

  • Page 3: Important Safety Instructions - Assembly

    ImporTanT safeTy InsTruCTIons -assembly This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Obey the following warnings: Read and understand all warnings on this machine. Carefully read and understand the Assembly instructions. • Keep bystanders and children away from the product you are assembling at all times.

  • Page 4: Safety Warning Labels / Serial Number

    safeTy WarnIng labels and serIal number Serial Number • Read, understand and obey all warnings on this machine. • Keep children away. • Not intended for use by anyone under 14 years of age. • Prior to use, read and understand the Owner’s Manual.

  • Page 5: Specifications

    speCIfICaTIons Maximum User Weight: 300 lbs. (136 kg) Power Requirements: 49.9” (126.8 cm) Operational Voltage: Operational Voltage 9VDC Operating Current: 1500 mA Regulatory Approvals: 64” (162.5 cm) A C Power Adapter: U L listed, CEC certified (or equivalent), Rated 120V 60Hz Input, 9VDC, 1500mA Output. 27.7” Class 2. (70.3 cm) This product, its packaging, and components contain chemicals known to the State of California to cause cancer, birth defects, or reproductive harm. This Notice is provided in accordance with California’s Proposition 65. If you would like additional information, please refer to our website at www.nautilus.com/prop65.

  • Page 6: Parts

    parTs Item Description Item Description Console AC Adapter Water Bottle Holder Left Pedal Seat Back Front Stabilizer Seat Cover Right Pedal Seat Frame Assembly Upper Shroud Seat Bottom Shroud Cap Seat Adjustment Handle Console Mast Rear Stabilizer MP3 Cord Frame...

  • Page 7: Hardware

    HardWare / Tools Item Description Item Description Button Head Hex Screw, M8x20 Phillips Head Screw, M5x12 Button Head Hex Screw, M6x12 Lock Washer, M6 Flat Washer, M8 Curved Washer, M6 Lock Washer, M8 Phillips Head Screw, M6x25 Flat Washer, M6 Curved Washer, M8 Tools Included Not Included (recommended) 4 mm 6 mm...

  • Page 8: Assembly

    assembly 1. Attach Stabilizers to Frame Note: Hardware is pre-installed and not on the Hardware Card. *...
  • Page 9 2. Attach the Seat Frame Assembly to the Seat Rail NOTICE: Do not crimp the Heart Rate Cable. Once all hardware has been inserted, be sure to fully tighten it.
  • Page 10 3. Attach Seat Pads to Seat Frame Assembly...
  • Page 11 4. Attach Cover to Frame Assembly...
  • Page 12 5. Attach Seat Adjustment Handle to Frame Assembly...
  • Page 13 6. Connect the Cables and Attach the Console Mast to Frame Assembly NOTICE: Do not crimp Console Cables.
  • Page 14 7. Remove Hardware from Console NOTICE: Do not crimp the cable. Note: Hardware is pre-installed and not on the Hardware Card. * 8. Connect Cables and Attach Console to Frame Assembly NOTICE: Align the clips on the cable connectors and make sure the connectors lock. Do not crimp cables.
  • Page 15 9. Attach Pedals to Frame Assembly NOTICE: The Left Pedal is reverse-threaded. Be sure to attach Pedals on the proper side of the Bike. Orientation is based from a seated position on the bike. The Left Pedal has an “L”, the Right Pedal an “R”.
  • Page 16 10. Attach Water Bottle Holder to Frame Assembly...
  • Page 17 11. Connect AC Adapter to Frame Assembly 12. Final Inspection Inspect your machine to ensure that all hardware is tight and components are properly assembled. Be sure to record the serial number in the field provided at the front of this manual. Do not use until the machine has been fully assembled and inspected for correct performance in accordance with the Owner’s Manual.

  • Page 18: Moving The Machine

    before you sTarT Moving the Machine The machine may be moved by one or more persons depending on their physical abilities and capacities. Make sure that you and others are all physically fit and able to move the machine safely. Remove the power cord.

  • Page 19: Leveling The Machine

    Leveling the Machine Levelers are found on each side of the Rear Stabilizer and on the Frame Rail. On the Rear Stabilizer, turn the knob to adjust the stabilizer foot. Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or damage to the machine can occur. To adjust the leveler on the Frame Rail: 1. L oosen the upper locking nut. Turn the leveler to adjust the height. Do not adjust the levelers to such a height that they detach or unscrew from the machine. Injury to you or damage to the machine can occur.

  • Page 20: Important Safety Instructions

    ImporTanT safeTy InsTruCTIons This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Before using this equipment, obey the following warnings: Read and understand the complete Manual. Keep the Manual for future reference. R ead and understand all warnings on this machine. If at any time the Warning stickers become loose, unreadable or dislodged, contact Nautilus Customer Service for replacement stickers. ® • Children must not be let on or near to this machine. Moving parts and other features of the machine can be dangerous to children. • Not intended for use by anyone under 14 years of age. • Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only.

  • Page 21: Features

    feaTures Console Transport Wheel MP3 Input Fully Shrouded Flywheel USB Port Pedal Water Bottle Holder Storage Bin Transport Handle Seat Adjustment Handle Stabilizer Handlebar, Upright Leveler Speakers Handlebar, Side Contact Heart Rate (CHR) Sensors Media Tray Power Connector Telemetry Heart Rate (HR) Receiver...

  • Page 22: Console Features

    Console Features The Console provides important information about your workout and lets you control the resistance levels while you exercise. The Console features the Schwinn Dual Track display with touch control buttons to navigate you through the exercise ™ programs. Upper Display 40% 70% 40% 70% PAUSE/ QUICK ST ART Lower Display GOAL TRACK PROGRAMS Resistance Level Quick Buttons Resistance Level Quick Buttons CURRENT WORKOUT LAST 30 DA YS LONGEST WORKOUT LAST WORKOUT CALORIE RECORD LAST 7 DA YS Achievement Indicator Lights Keypad Functions Resistance Increase () button- Increases the workout resistance level...
  • Page 23 Achievement Indicator Lights- when an achievement level is reached or a result is reviewed, the achievement indicator light will activate. Schwinn Dual Track™ Display Upper Display Data Program Display User Display 40% 70% Achievement Display Program Display The Program Display shows information to the User and the grid display area shows the course profile for the program. Each column in the profile shows one interval (workout segment). The higher the column, the higher the resistance level. The flashing column shows your current interval. Intensity Display The Intensity Display shows the level of work at that moment based on the current resistance level. RKOUT Heart Rate Zone Display The Heart Rate Zone shows which zone the current heart rate value falls into for the current User. These Heart Rate Zones can be used as a workout guide for a certain target zone (anaerobic, aerobic, or fat burn). Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. The heart rate displayed is an approximation and should be used for reference only.
  • Page 24 40% 70% Lower Display Data The Lower Display shows the Workout Values. and can be customized for each User (Consult the “Edit User Profile” section PAUSE/ of this manual). GOAL TRACK Speed The Speed display field shows the machine speed in miles per hour (mph) or kilometers per hour (km/h). CURRENT WORKOUT LAST WORKOUT LAST 7 DA YS Time The TIME display field shows the total time count of the workout, the average Time for the User Profile, or the total operational time of the machine. Note: If a Quick Start workout is performed for more than 99 minutes and 59 seconds (99:59), the units for Time will shift to hours and minutes ( 1 hour, 40 minutes ). Distance The Distance display shows the distance count (miles or km) in the workout. Note: T o change the measurement units to English Imperial or metric, refer to the “Console Setup Mode” section in this manual. Level The LEVEL display shows the current resistance level in the workout. The RPM display field shows the pedal revolutions per minute (RPM). Heart Rate (Pulse) The Heart Rate display shows the beats per minute (BPM) from the heart rate monitor. When a heart rate signal is received by the Console, the icon will flash.
  • Page 25 Remote Heart Rate Monitor Monitoring your Heart Rate is one of the best procedures to control the intensity of your exercise. Contact Heart Rate (CHR) sensors are installed to send your heart rate signals to the Console. The Console can also read telemetry HR signals from a Heart Rate Chest Strap Transmitter that operates in the 4.5kHz - 5.5kHz range. Note: The heart rate chest strap must be an uncoded heart rate strap from Polar Electro or an uncoded POLAR compatible model. (Coded PO- ®...
  • Page 26 Heart Rate Calculations Your maximum heart rate usually decreases from 220 Beats Per Minute (BPM) in childhood to approximately 160 BPM by age 60. This fall in heart rate is usually linear, decreasing by approximately one BPM for each year. There is no indication that training influences the decrease in maximum heart rate. Individuals of the same age could have different maximum heart rates. It is more accurate to find this value by completing a stress test than by using an age related formula. Your at-rest heart rate is influenced by endurance training. The typical adult has an at rest heart rate of approximately 72 BPM, whereas highly trained runners may have readings of 40 BPM or lower. The Heart Rate table is an estimate of what Heart Rate Zone (HRZ) is effective to burn fat and improve your cardiovascular system. Physical conditions vary, therefore your individual HRZ could be several beats higher or lower than what is shown. The most efficient procedure to burn fat during exercise is to start at a slow pace and gradually increase your intensity until your heart rate reaches between 60 – 85% of your maximum heart rate. Continue at that pace, keeping your heart rate in that target zone for over 20 minutes. The longer you maintain your target heart rate, the more fat your body will burn. The graph is a brief guideline, describing the generally suggested target heart rates based on age. As noted above, your opti- mal target rate may be higher or lower.

  • Page 27: Operations

    operaTIons What to Wear Wear rubber-soled athletic shoes. You will need the appropriate clothes for exercise that allow you to move freely. How Often Should You Exercise Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only. The heart rate displayed on the console is an approximation and should be used for reference only. • 3 times a week for 30 minutes each day. • Schedule workouts in advance and try to follow the schedule. Seat Adjustment Correct seat placement encourages exercise efficiency and comfort, while reducing the risk of injury. 1. W ith a Pedal in the forward position, place the ball of your foot over the center of it. Your leg should be bent slightly at the knee.

  • Page 28: Quick Start Program

    Initial Setup During the first power-up, the Console should be setup with the date, time and your preferred measurement units. 1. D ate: Push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (month / day / year). 2. P ush OK to set. 3. T ime: Push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (hour / minute / AM or PM). 4. P ush OK to set. 5. U nits of Measurement: Push the Increase/Decrease buttons to adjust between “MILES” (Imperial English) or “KM” (metric). 6. Push OK to set. The Console goes back to the Power-Up / Idle Mode screen. Note: To adjust these selections, consult the “Console Set-Up Mode” section. Quick Start ( Manual ) Program The Quick Start ( Manual ) program lets you start a workout without entering any information. During a Manual Workout, each column represents a 2 minute time period. The active column will advance across the screen every 2 minutes. If the workout lasts for more than 30 minutes, the active column is fixed on the farthest column on the right and pushes the previous columns off the display.
  • Page 29 User Profiles are assigned the default values until they are customized by editing. Be sure to edit the User Profile for more accurate calorie and heart rate information. From the Power-Up Mode screen, push the Increase() or Decrease() buttons to select one of the User Profiles. The Console will display the name of the User Profile and the User Profile Icon. Edit User Profile 1. F rom the Power-Up Mode screen, push the Increase() or Decrease() buttons to select one of the User Profiles. 2. P ush the OK button to select the User Profile. 3. T he Console display shows the EDIT prompt and the current User Profile name. Push OK to start the Edit User Profile option. T o exit the Edit User Profile option, push the PAUSE/END button and the console will go back to the Power-Up Mode screen. 4. T he Console display shows the NAME prompt and the current User Profile name. Note: The User name will be blank if this is the first edit. The name of a User Profile is limited to 10 characters. T he currently active segment will flash. Use the Increase/Decrease buttons to move through the alphabet and blank space (found between A and Z). To set each segment, use the Left() or Right() buttons to shift between segments. P ush the OK button to accept the displayed User name.
  • Page 30 Reset a User Profile 1. F rom the Power-Up Mode screen, push the Increase() or Decrease() buttons to select one of the User Profiles. 2. P ush the OK button to select the User Profile. 3. T he Console display shows the current User Profile name and the EDIT prompt. Push the Increase() or Decrease() buttons to change the prompt. Note: To exit the Edit User Profile option, push the PAUSE/END button and the console will go back to the Power-Up Mode screen. 4. T he Console display shows the RESET prompt and the current User Profile name. Push OK to start the Reset User Profile option. 5. The Console will now confirm the request to reset the User profile (the default selection is ‘NO’). Push the Increase() or Decrease() buttons to adjust the selection. 6. P ush OK to make your selection. 7. The Console will go to the Power-Up Mode screen.
  • Page 31 Pyramids Pyramids Summit Pass Summit Pass CHALLENGES Uphill Finish Uphill Finish Cross-Training Cross-Training Interval Interval Stairs Uphill Finish Cross-Training Interval Interval Interval Stairs Stairs Stairs Workout Profile and Goal Program The Console lets you select the Profile Program and type of Goal for your workout (Distance, Time or Calories), and set the REVED : 122612 REVED : 122612 Goal value. 1. Sit on the machine. 2. Push the Increase() or Decrease() buttons to select the correct User profile. 3. P ush the Programs button.
  • Page 32 Recovery Test Program Recovery Test shows how quickly your heart recovers from an exercise state to a more restful state. Improved recovery is an indicator of increasing fitness. Note: The Console must be able to read the heart rate information from the Contact Heart Rate (CHR) sensors or Heart Rate Monitor (HRM) to work correctly. From an elevated heart rate, select the Recovery Test Program. The Console will show “STOP EXERCISING” and the goal will begin to count down. Stop exercising but continue to grip the contact heart rate sensors. After 5 seconds, the display will show “RELAX” and will continue to count down to 00:00. For the entire minute the console will also show your heart rate. You must grip the heart rate sensors for the duration of the test if not using a Remote Heart Rate Monitor. The display will continue to show “RELAX” and your heart rate until the goal reaches 00:00. The console will then calculate your recovery score. Recovery Score = Your heart rate at 1:00 (the beginning of the test) minus your heart rate at 00:00 (the end of the test). The higher the Recovery Test score value, the quicker your heart rate is returning to a more restful state and is an indication of improving fitness.

  • Page 33: Pausing Or Stopping

    A User can set a Heart Rate zone instead of a value by selecting the Heart Rate Control - User program. The Console will adjust the workout to keep the User in the desired Heart Rate zone. 1. S elect HEART RATE CONTROL - USER, and push OK. 2. P ush the Increase() or Decrease() buttons to set the Heart Rate zone for the workout, and push OK. The Console shows the Heart Rate zone (percent) on the left, and the Heart Rate range for the User on the right side of the display. Consult a physician before you start an exercise program. Stop exercising if you feel pain or tightness in your chest, become short of breath, or feel faint. Contact your doctor before you use the machine again. Use the values calculated or measured by the machine’s computer for reference purposes only. The heart rate displayed on the console is an approximation and should be used for reference only. 3. Push the Increase() or Decrease() buttons to select the Goal type, and push OK. 4. P ush the Increase() or Decrease() buttons to set the value for the workout. 5. P ush OK to start the workout.

  • Page 34: Results / Cool Down Mode

    S PEED (average), RPM (average), and HEART RATE (average) c.) T IME (average), LEVEL (average), and CALORIES (average). Push the Left() or Right() buttons to move through the result channels manually. During the Cool Down period, the Resistance Level will adjust to a third of the average Level of the workout. The Cool Down resistance level can be adjusted with the Resistance Increase and Decrease buttons, but the Console will not display the value. You can push PAUSE/END to stop the Results / Cool Down period and go back to Power-Up Mode. If there is no RPM or HR signal, the Console automatically goes into Sleep Mode. GOAL TRACK Statistics (and Achievements) The statistics from every workout are recorded to a User Profile. The Schwinn Dual Track Console shows the Goal Track workout Statistics on the Lower Display in three channels: ™ a.) T IME (total), DISTANCE (total), and CALORIES (total) b.) S PEED (average), RPM (average), and HEART RATE (average) c.) T IME (average), DISTANCE (average) / or LEVEL (average) *, and CALORIES (average) * If the Goal Track Statistic is a single workout, LEVEL (average) is displayed. If the Goal Track Statistic is a combination of multiple workouts, DISTANCE (average) is displayed instead of LEVEL (average).
  • Page 35 7. P ush the Increase() button to move to “BMI”, or Body Mass Index. The Console will display the BMI value based on the User settings. Be sure the height value is correct for your User Profile, and the weight value is current. The BMI Measurement is a useful tool that shows the relationship between weight and height that is associated with body fat and health risk. The table below gives a general rating for the BMI score: Underweight Below 18.5 Normal 18.5 – 24.9 Overweight 25.0 – 29.9 Obesity 30.0 and above Note: The rating may overestimate body fat in athletes and others who have a muscular build. It may also underestimate body fat in older persons and others who have lost muscle mass. Contact your doctor for more information about Body Mass Index (BMI) and the weight that is appropriate for you. Use the values calculated or measured by the machine’s computer for reference purposes only. 8. P ush the Increase() button to move to the “SAVE TO USB - OK?” prompt. Push OK, and the “ARE YOU SURE? -NO”...

  • Page 36: Console Service Mode

    Console seTup mode The Console Setup Mode lets you input the date and time, set the units of measurement to either English or Metric, change the machine type, control the sound settings ( on/ off), or see maintenance statistics (Error Log and Run Hours – for service technician use only). 1. H old down the PAUSE/END button and Right button together for 3 seconds while in the Power-Up Mode to go into the Console Setup Mode. Note: Push PAUSE/END to exit the Console Setup Mode and return to the Power-Up Mode screen. 2. T he Console display shows the Date prompt with the current setting. To change, push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (month / day / year). 3. P ush OK to set. 4. T he Console display shows the Time prompt with the current setting. Push the Increase/Decrease buttons to adjust the currently active value (flashing). Push the Left/Right buttons to change which segment is the currently active value (hour / minute / AM or PM). 5. P ush OK to set. 6. T he Console display shows the Units prompt with the current setting. To change, push OK to start the Units option. Push the Increase/Decrease buttons to change between “MILES” (Imperial English units) and “KM” (metric units). Note: I f the units change when there is data in User Statistics, the statistics convert to the new units. 7. Push OK to set.

  • Page 37: Maintenance

    maInTenanCe Read all maintenance instructions fully before you start any repair work. In some conditions, an assistant is required to do the necessary tasks. Equipment must be regularly examined for damage and repairs. The owner is responsible to make sure that regular maintenance is done. Worn or damaged components must be repaired or replaced immediately. Only manufacturer supplied components can be used to maintain and repair the equipment. To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and the machine and wait 5 minutes before cleaning, maintaining or repairing the machine. Place the power cord in a secure location. Daily: Before each use, examine the exercise machine for loose, broken, damaged, or worn parts. Do not use if found in this condition. Repair or replace all parts at the first sign...

  • Page 38: Maintenance Parts

    Maintenance Parts...

  • Page 39: Seat Back

    Console Shroud, Left Speed Sensor Magnet Seat Back Transport Wheel Console Cable, Lower Seat Cover Stabilizer, Front Shroud, Right Water Bottle Holder Heart Rate Cable, Lower Pedal, Right Handlebar, Side Speed Sensor Shroud, Upper Seat Bottom Crank Arm Shroud Cap Seat Adjustment Handle Servo Motor Console Cable, Upper Frame Assembly Brake Assembly Heart Rate Cable, Upper Rear Stabilizer Flywheel Console Mast Pedal, Left Drive Belt...

  • Page 40: Troubleshooting

    TroublesHooTIng Condition/Problem Things to Check Solution No display/partial display/ Check electrical (wall) Make sure unit is plugged into a functioning wall outlet. unit will not turn on outlet Check connection at front Connection should be secure and undamaged. Replace adapter of unit or connection at unit if either are damaged. Check data cable integrity All wires in cable should be intact. If any are visibly crimped or cut, replace cable. Check data cable Be sure cable is connected securely and oriented properly. Small connections/orientation latch on connector should line up and snap into place.
  • Page 41 No speed/RPM reading, Check data cable integrity All wires in cable should be intact. If any are cut or crimped, Console displays “Please replace cable. Pedal” error code Check data cable Be sure cable is connected securely and oriented properly. Small connections/orientation latch on connector should line up and snap into place. Check magnet position Magnet should be in place on pulley. (requires shroud removal) Check Speed Sensor (re- Speed sensor should be aligned with magnet and connected to quires shroud removal) data cable. Realign sensor if necessary. Replace if there is any damage to the sensor or the connecting wire. Console shuts off (enters Check electrical (wall) Make sure unit is plugged into a functioning wall outlet.

  • Page 42: Warranty

    WarranTy Who Is Covered ( Sears Customers - see “SEARS CUSTOMER WARRANTY” ) This warranty is valid only to the original purchaser and is not transferable or applicable to any other person(s). What Is Covered Nautilus, Inc. warrants that this product is free from defects in materials and workmanship, when used for the purpose intended, under normal conditions, and provided it receives proper care and maintenance as described in the Product’s Assembly and Owner’s manual.

  • Page 43: Sears Customer Warranty

    sears CusTomer WarranTy Who Is Covered This warranty is valid only to the original purchaser and is not transferable or applicable to any other person(s). What Is Covered Sears, Roebuck and Co. warrants that this product is free from defects in materials and workmanship, when used for the purpose intended, under normal conditions, and provided it receives proper care and maintenance as described in the Product’s Assembly and Owner’s manual.
  • Page 44 Nautilus Bowflex Schwinn Fitness Universal ® ® ® ® 8002160.090113.C...
