EverFocus ECOR960-16X1 Specifications

Features
• 16 CH WD1 recording and playback
• WD1 capability provides higher resolution (960x480
compared to traditional D1 recording (704x480)
• H.264 compression format for enhanced recording
capacity and improved network image transmission
speed
• Separately configured HDMI or VGA (1080p) main-
monitor outputs
• Sequenced call monitor view through composite
BNC output
• Free EverFocus DDNS Service: static IP address is
not required for remote access
• Supports one eSATA port for external HDDs
(EDA450)
• Supports live monitoring and playback of video from
mobile devices via MobileFocus and MobileFocus
Plus Apps
• Multiple Control Inputs: mouse / front panel / remote
controller/ EKB500 Keyboard
• Built-in record-time calculator for fast recording
estimation
• Multiple intelligent video query functionality, including
snapshot and smart search
• Powerful archive functionality from both remote and
DVR sites
• Simplified access to common features such as setup,
archive, playback and search functions through
Express menus
• Remote configuration support from built-in web
interface
• Gigabit Ethernet interface for remote network viewing
and control
• On-screen PTZ control via mouse, front panel, or
over web
• Built-in DVD burner
• Dual USB 2.0 ports for video archive and mouse
control
• Integration with Free PowerVideo Plus CMS for
multisite viewing
• Multi-language support
• 19" Rack mountable-rack ears included
• Dual stream capability for recording and remote
viewing conserves HDD space and LAN/WAN band-
width while delivering full image detail on demand
Product specifications are subject to change without notice. Models vary in different countries. Visit www.everfocus.com and select your country for accurate ordering information.
16 Channel WD1 / 960H DVR
OS
Analog Video Inputs
Looping Outputs
Compression
Video Interface
Input / Ouput
Main Monitor Outputs
Call Monitor Output
Rate/Resolution
Recording Mode
Rate/Resolution
Search Mode
Video Loss Detection
Video Motion Detection
Alarm Inputs / Outputs
Network/Protocol
Max User Access
Smart Phone Support
Internal HDD
External HDD
HDD Max Total
DVD Burner
USB Interface
RS-232 / RS-485
PTZ Protocols Supported
Power Source
Working Temperature
(Humidity)
Dimension (W x D x H)
Weight
Certificates
Ordering Information
ECOR960-16X1/1T: 16 Ch 960h DVR, DVD, 1TB
ECOR960-16X1/2T: 16 Ch 960h DVR, DVD, 2TB
ECOR960-16X1/4T: 16 Ch 960h DVR, DVD, 4TB
ECOR960-16X1/6T: 16 Ch 960h DVR, DVD, 6TB
ECOR960-16X1
960H Digital Video Recorder
Main stream H.264 / M-JPEG for substream
Same as recording rate and resolution
Selectable areas and sensitivity within field of view
Gigabit Ethernet; TCP-IP / DHCP/ PPPoE / Everfocus DDNS
/ RTSP / RTP / HTTP / SMTP / POP3 / SSL
MoblieFocus apps for iOS and Android devices
1 x ESATA (optional: EDA450 up to 4 HDD's)
2 x USB 2.0 ports (1 on front panel. 1 on back panel)
Everfocus, Pelco D, Pelco P, Samsung, Transparent
12 VDC / 60 W MAX from included Power Supply,
Supply input 100-240 VAC, 47 - 63 HZ
0°C~40°C / 32°F~104°F (20~80% humidity)
355 x 353 x 70 mm / 13.97" x 13.89" x 2.75"
Embedded Linux
16 CH BNC
16 CH BNC
NTSC/PAL
4 / 1 (Line Level)
VGA/HDMI
BNC
120 NTSC / 100 PAL (WD1)
240 NTSC / 200 PAL (Half WD1)
120 NTSC / 100 PAL (4CIF / D1)
240 NTSC / 200 PAL (2CIF)
480 NTSC / 400 PAL (CIF)
Continuous, Schedule and Event
Time search, Event search,
Smart search, Snapshiot search
Yes
16 / 4 Form C (SPDT)
3 Levels of User Access Defined
MobileFocus HD for iPad
Up to 2 X SATA HDD
12 TB
Built in DVD Burner
1/1
3.9 kgs / 8.56 lbs (without HDDs)
CE, FCC, UL
