Release Note for Quarter 1 2012 SD DVR Firmware Releases
Release Date: 1/27/2012
January 27, 2012: Paragon264-16X4 and ECOR-4D (MPEG4) Internet Explorer 9 for Windows 7
operating system web interface compatibility
This firmware release adds several new features and functions which fall into three general
categories: (1) Applies to remote access via LAN or WAN only; (2) Applies to local control at the
DVR front panel; and (3) Applies to both LAN/WAN and local/Front Panel operation:
(1)

1. Windows7 IE9 (32-bit) Compatibility Network Connectivity

Windows7 64-bit operating
system has two versions of Internet Explorer 9 (32-bit and 64-bit). When accessing the DVR please
use Internet Explorer 9 32-bit browser.
(2) (1)

2. Remote Reboot

– (optional) users can enable a remote command to reboot the DVR via
the web interface. The check box to enable this feature appears only in the DVR local System
Menu at the bottom of the "Misc." screen. The button which reboots the DVR is located only in the
web interface System Menu at the top of the "Misc." screen. If the Internet Explorer window is left
open after clicking on "Reboot Now", the screen will indicate a break in the network connection
during the reboot process, after which the DVR will reconnect. Change screens to refresh the
display and view updated information.
(2)

3. Network Test

–To verify basic network connectivity
between the DVR and some other LAN or WAN node, the user
can issue an ICMP Ping to a valid IP address. The Ping utility is
useful in diagnosing connectivity problems by obtaining
responses from nodes progressively farther along the network.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Paragon264 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EverFocus Paragon264

  • Page 1 Release Note for Quarter 1 2012 SD DVR Firmware Releases Release Date: 1/27/2012 January 27, 2012: Paragon264-16X4 and ECOR-4D (MPEG4) Internet Explorer 9 for Windows 7 operating system web interface compatibility This firmware release adds several new features and functions which fall into three general categories: (1) Applies to remote access via LAN or WAN only;...
  • Page 2 DNS functionality can also be confirmed by entering a valid DNS name instead of an IP address. 4. 2X and 4X Zoom on live and playback – in a live or playback full screen view, the operator can choose 2X or 4X zoom. A portion (1/4 or 1/16 of the image) is expanded to fill the screen. In Live or Playback view select a camera (either call up a full screen view or click on the camera in a multi-camera view);...
  • Page 3 LAN. This utility can be downloaded from Item 7 IP Utility program or http://www.everfocus.com/tools.cfm http://www.everfocus.com/downloads/product_software/IPUtility.exe Launch the utility, click the “Find Devices” button. DVRs on the LAN will be listed. The Machine Name is the DDNS name of the DVR. To change values, first select a device; then click “Login”. In the popup window enter the admin ID and password of the DVR and click “OK”;...
  • Page 4 7. Quick Archive function – Press and hold a single button to copy the previous 10 (or 20, 30, 60, 90) minutes of video prior to the current time for all cameras, even if front panel keys are locked. Leave a blank DVD in the drive in case of events/emergencies. At the DVR, press and hold the COPY key;...
  • Page 5 9. Main/Sub stream setting – Improve network transmission speed by switching the web interface to display a lower bandwidth subsidiary stream. The Main stream will attempt to transmit to the web interface the video in the format recorded to the hard drive according to the settings in the DVR’s camera menu and other record configuration parameters.
  • Page 6 The more efficient H.264 format requires a special decoder which is found in the standard Internet Explorer web interface and in the MobileFocus application for Android and iPhone/iPod Touch devices. When viewing from MobileFocus in this case, the JPEG mode setting for the DVR should be “Off”.
  • Page 7 Model Specific (1,3) 13. Disable Record Stop (P2, Paragon 264X4) On this model, pressing the STOP button will end playback, but could also direct the DVR to stop recording; to prevent terminating recording by accident, two changes have been made. One is a check box which limits the STOP button function to ending playback, and not effecting recording.
  • Page 8 The following chart shows the firmware release versions and the related features for each model series.
