LifeSource UA-767T Instruction Manual

Oscillometric type

Hide thumbs Also See for UA-767T:

Specifications (2 pages)

Quick start (1 page)

Instruction manual (21 pages)

Table Of Contents

Table of Contents

Consejos para Medirse la Presión Arterial: Assessing High Blood Pressure the Following Standards for Assessing High Blood Pressure Relajarse Durante unos 5 a 10 Minutos Antes de Tomarse la (Without Regard to Age) Have Been Established by the National Presión. Institutes of Health JNCVI. Sacarse cualquier Ropa Ajustada y Colocar la Manga en el Brazo Desnudo. Systolic (Mmhg) Diastolic (Mmhg) Category Optimal a menos que el Médico Recomiende lo Contrario, Medirse la Normal Presión en el Brazo Izquierdo. 130 - 139 85 - 89 High Normal Ahora Ya Se Está Listo para Proceder con Estos Simples Pasos: Hypertension 140 - 159 Stage 1 90 - 99 Sentarse Cómodamente con el Brazo 160 - 179 100 - 109 Stage 2 Izquierdo Descansando en una Super- ≥110 ≥180 Stage 3 Ficie Plana de Manera que el Centro del Brazo (entre el Hombro y el Codo) What Is Hypertension? Esté a la Misma Altura del Corazón. Hypertension (High Blood Pressure) Is the Diagnosis Given Descansar el Brazo Izquierdo sobre la When Readings Consistently Rise above Normal. It Is Well Known Mesa con la Palma de la Mano Hacia that Hypertension Can Lead to Stroke, Heart Attack or Other Illness Arriba y Deslizar el Extremo de la Manga if Left Untreated. Referred to as a “Silent Killer” Because It Does a Través del Ojal de Metal Cerciorándose Not Always Produce Symptoms that Alert You to the Problem, que el Lado Plano Quede Hacia el Brazo. Hypertension Is Treatable When Diagnosed Early. Ahora, Colocar el Tubo Más Hacia el Can Hypertension be Controlled? Lado Interior del Brazo en Línea con in Many Individuals, Hypertension Can be Controlled by Altering el Meñique. Lifestyle and Minimizing Stress, and by Appropriate Medication Halar el Extremo del Manga para Prescribed and Monitored by Your Doctor. the American Heart Apretarlo, Doblar el Exceso de Tela Association Recommends the Following Lifestyle Suggestions to Hacia atrás y Fijarlo con la Tira de Prevent or Control Hypertension: Velcro. el Manga Debería Quedar Apretado pero no Demasiado. Se Have Regular Physical Don't Smoke. Checkups. Reduce Salt and Fat Intake. Debería Poder Colocar Dos Dedos Maintain Proper Weight. Monitor Your Blood entre la Manga y el Brazo. Pressure at Periodic Intervals. Exercise Routinely. IMPORTANTE: Medirse la Presión Arterial a la Misma Hora todos Los Días.
Para Medirse la Presion Arterial about Blood Pressure

Quick Links

Need help?

Do you have a question about the UA-767T and is the answer not in the manual?

Questions and answers

Summary of Contents for LifeSource UA-767T

Page 1 Congratulations. You have purchased a LifeSource state-of-the-art blood pressure monitor, one of the most technologically advanced yet easy to use products available in the marketplace today. This LifeSource monitor is designed to make your daily regimen useful, and convenient. Physicians agree that daily self-monitoring of blood pressure is an important way individuals can contribute to maintaining their cardiovascular health and preventing the serious consequences of hypertension left...
Page 2: Table Of Contents
TABLE OF CONTENTS WHAT DISPLAY SYMBOLS MEAN ....3 MONITOR COMPONENTS ......4 HOW 767T WORKS .
Page 3: What Display Symbols Mean
WHAT DISPLAY SYMBOLS MEAN Condition/ Recommended Display Cause Action Symbol Appears during measure- Remain still and refrain ment; blinks and beeps from talking; measure- when pulse is detected. ment in progress. MEASUREMENT IN PROGRESS Battery voltage is Replace all batteries too low for monitor with new ones.
Page 4: Monitor Components
A&D MEDICAL PRESSURE SYSTOLIC mmHg SWITCH DIASTOLIC SPEAKER DIASTOLIC mmHg START DISPLAY PULSE/min. START BUTTON DIGITAL BLOOD PRESSURE MONITOR UA-767T MEASUREMENT IN PROGRESS LOW BATTERY DISPLAY HEADPHONE SOCKET VOLUME CONTROL PULSE DISPLAY AIR CONNECTOR TUBE CUFF BATTERY COMPARTMENT ADJUSTMENT SCREW...
Page 5: How 767T Works
HOW 767T WORKS LifeSource Blood Pressure Monitors are easy to use, accurate and digitally display full measurement readouts. Our technology is based on the “oscillometric method” — a noninvasive blood pressure determination. The term “oscillation” refers to any measure of vibrations caused by the arterial pulse. The cuff is first inflated until the artery is fully blocked.
Page 6: Selecting The Correct Cuff
SELECTING THE CORRECT CUFF Using the correct cuff size is important for an accurate reading. A cuff that is too large will produce a reading that is lower than the correct blood pressure; a cuff that is too small yields a measurement that is higher.
Page 7: Taking Your Blood Pressure
TAKING YOUR BLOOD PRESSURE Tips for Blood Pressure Monitoring: Relax for about 5 to 10 minutes before measurement. Remove constricting clothing and place cuff on bare arm. Unless your physician recommends otherwise, use left arm to measure pressure. Now you are ready. Follow these simple steps: Sit comfortably with your left arm resting on a flat surface so that the center of your upper arm is at the...
Page 8 TAKING YOUR BLOOD PRESSURE Before taking your blood pressure, you will need to set the pressure switch to a number that is at least 30 mmHg higher than your expected systolic pressure. Use the chart below as a guide. For example, if you believe your blood pressure to be 140 (systolic) over 90 (diastolic), set the switch to 180.
Page 9 TAKING YOUR BLOOD PRESSURE It is normal for the cuff to feel very tight. You will see all the display symbols appear briefly. As the cuff pressurizes, blinking numerals—starting at zero—are displayed. When inflation is complete, the MEASUREMENT IN PROGRESS symbol blinks and beeps with each pulse beat.
Page 10: Taking Your Blood Pressure
TAKING YOUR BLOOD PRESSURE Remove cuff and make a note of your blood pressure and pulse rate on the chart (see page 16), indicating date and time of measurement. We advise that you record the date and time after each measure- ment because an accurate blood pressure history relies not on single or sporadic readings but on a pattern over time.
Page 11: Check/Adjust Exhaust Velocity
CHECK/ADJUST EXHAUST VELOCITY Exhaust velocity is the rate at which the air pressure in the cuff deflates during the course of measurement. It is preset at the factory and generally does not need any further adjustment. NOTE: The exhaust rate of your monitor was preset and tested at the factory to ensure proper measurement.
Page 12: Check/Adjust Exhaust Velocity
CHECK/ADJUST EXHAUST VELOCITY If the exhaust velocity range is not within 2 to 5 mmHg, make the following adjustment with the unit turned off: With the edge of your fingernail, peel off the thin black plastic disk covering the adjustment screw. If there is no thin plastic disk, proceed to step 2.
Page 13: About Blood Pressure
ABOUT BLOOD PRESSURE What Is Blood Pressure? Blood pressure is the force exerted by blood against the walls of the arteries. Systolic pressure occurs when the heart contracts; diastolic pressure occurs when the heart expands. Blood pressure is measured in millimeters of mercury (mmHg). What Affects Blood Pressure? Blood pressure is affected by many factors: age, weight, time of day, activity level, climate, altitude and season.
Page 14: About Blood Pressure
ABOUT BLOOD PRESSURE Assessing High Blood Pressure The following standards for assessing high blood pressure (without regard to age) have been established by the National Institutes of Health JNCVI. Category Systolic (mmHg) Diastolic (mmHg) Optimal <120 <80 Normal <130 <85 High Normal 130 - 139 85 –...
Page 15: About Blood Pressure
ABOUT BLOOD PRESSURE Why Measure Blood Pressure at Home? It is now well known that, for many individuals, blood pressure readings taken in a doctor’ s office or hospital setting might be elevated as a result of apprehension and anxiety. This response is commonly called “white coat hypertension.”...
Page 16: Blood Pressure Record
B L O O D P R E S S U R E R E C O R D Name: Age: Weight: DATE SYS/DIA PULSE SYS/DIA PULSE 1/14 9:30 132/98 P 69 6:30 128/87 P 63 E X A M P L E LifeSource Health Line (Toll-Free): 1-888-726-9966...
Page 17: Important Information
Remove and replace batteries if monitor is not used for more than six months. PRECAUTIONS UA-767T is designed to be used at home, by those who are eighteen (18) years and older, to monitor blood pressure (systolic and diastolic) and pulse rate. This monitor is not designed to measure the blood pressure of people with common arrhythmias, such as atrial or ventricular premature beats or atrial fibrillation.
Page 18: Specifications
SPECIFICATIONS Model ....UA-767T Type .....Oscillometric Display .
Page 19: Contact Information
CONTACT INFORMATION Our products are designed and manufactured using the latest scientific and technological methods, and offer accurate, easy to use, home monitoring and treatment options. The product line includes: Aneroid Blood Pressure Kits Blood Pressure Cuffs Digital Blood Pressure Monitors Digital Thermometers Stethoscopes This LifeSource product is covered by a...
