1.
To make assembly easier, read the information
on page 5 before you begin assembling the
elliptical exerciser.
While another person lifts the Base (1), attach the
Front Stabilizer (6) to the Base with two M10 x 80mm
Carriage Bolts (82) and two M10 Nylon Locknuts (81).
2. Remove the indicated screw and the shipping bracket
from the Base (1). Discard the screw and the shipping
bracket.
Next, tighten the Base Foot (26) into the Base (1) as
far as possible.
3. Attach the Rear Stabilizer (7) to the Frame (2) with
two M10 x 127mm Button Screws (83).
Next, hold the handle on the Frame (2), press the
Latch Button (68), and lower the Frame until the Rear
Stabilizer (7) is resting on the floor.
1
82
6
2
1
26
3
Handle
6
81
81
1
Shipping
Bracket
Screw
83
7
2
68
