Wiring
8
2
28 28
1.015 0.985
5.429 5.225
1.248 1.214
3.024 3.015
0.356 0.356
1.8 7.2
1200W/2400W 1200W/2400W
94 94
Please take every precaution to wire your DVC woofers
for the correct impedance
-
+
+
2 ohms
12" (305mm) Subwoofer
(1200 Watts RMS Sealed Enclosure)
12" (305mm) Dual Voice Coil Subwoofer
2400 Watts Peak Power/1200 Watts RMS
Frequency Response: 28Hz-1.5kHz
Sensitivity: 94 dB (1 Watt/1 Meter)
Impedance: Dual 4 OHMS
Cone Material: Color Chrome Treated Poly Injection
Butyl Rubber Surround
Dual 2" (51mm) High Temperature KAPTON Voice Coil
Mounting Depth: 5-3/16" (132mm)
+ -
-
+
8 ohms
-
