2. CONNECTING THE SYSTEM

Wiring Diagram

ISO
CONNECTOR
1 3 5 7
B
2 4 6 8
5 7
4
8
A
Figure 2
ISO CONNECTOR WIRING CHART
PIN WIRE COLOR
YELLOW
A4
A5 BLUE
A7 RED
A8
BLACK
B1 VIOLET
B2 VIOLET/BLACK
B3 GREY
B4 GREY/BLACK
B5 WHITE
B6 WHITE/BLACK
B7 GREEN
B8 GREEN/BLACK
L
REAR
R
ANTENNA
JACK
FUNCTION/LABEL
BATTERY(+)
CONNECT TO SYSTEM CONTROL
TERMINAL OF THE POWER AMP OR
AUTO ANTENNA RELAYCONTROL
TERMINAL(max 150mA 12VDC)
IGNITION(ACC)
GROUND
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (+)
RIGHT FRONT SPEAKER (-)
LEFT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
E - 2
WHITE
FRONT LINE OUT
BLACK
RED
AUX-IN WHITE
YELLOW
RED
BLUE
SUBWOOFER
