Behringer B-CONTROL FADER BCF2000 Quick Start Manual page 2

BCF2000 Quick Start Guide
®
Note : Windows XP will load its own generic USB/MIDI driver when the BCF2000 is
connected via USB, but we recommend installing the
better performance and features.
Note : if v1.0.0.2 is already installed – please update driver to v1.1.1.0
The .dll file, set-up utility and read-me files can all be downloaded from :
http://www.behringer.com/05_support/bc_download/preset_download.cfm?lang=ENG
filename = Driver_1110.zip
USB MIDI driver (v1.1.1.0) for WINDOWS
BCF2000 port configuration : select one of the "USB" modes on the BCF2000. Check
this in the global menu. Press "EDIT" and then "STORE" keys together, the display will
read EG (edit global). Use the "TYPE" encoder to select the port status (mode) – for
best results select mode U-1. Exit the global menu.
Note : after setting the BCF2000 port configuration you must exit the global menu.
Note : you cannot access the global edit menu directly from the "emulation" modes in V1.06 or
higher. Restart, but keep the appropriate selection key held down for a few seconds.
Note : you cannot access the global edit menu directly from the default factory preset for
®
Cubase – in this case you will need to recall a different preset to enter the global menu.
Follow the
USB_MIDI_Driver_1110 _readme.pdf. Once the driver is installed and the device is
connected via USB, you will find that the BCF2000 is recognised within the computer's
OS. Windows
Note : It is OK to use a USB hub, but if you experience difficulties when installing the
hardware, try using a direct USB connection to the motherboard for the installation. You
can repeat the installation for each USB port which you are likely to use.
For further information please visit
instructions for
®
users will be able to check this in the device manager (control panel).
www.behringer.com
B
EHRINGER driver v1.1.1.0. for
®
XP/2000
your OS as described
Page 2
in attachment
BEHRINGER Spezielle Studiotechnik GmbH
#01
