Rheem RANL-JEZ Brochure

CONDENSING UNITS

RAPL- JEZ
14 SEER Models
Efficiencies up to 15.50 SEER
Nominal Sizes 1 1 / to 5 Tons
2
[5.28 kW] to [17.6 kW]
Seven Models
Cooling Capacities
18,200 to 59,500 BTU/HR
[5.33 kW] to [17.44 kW]
RANL- JEZ
13 SEER Models
Nominal Sizes 2 to 5 Tons
[7.03 kW] to [17.6 kW]
Six Models
Cooling Capacities
23,200 to 62,000 BTU/HR
[6.80 kW] to [18.17 kW]
Equipped with
Comfort Control System
• Increased Reliability
• On-Board Diagnostics
• Fault Recall
• Active Protection
e a r t h f r i e n d l y r e f r i g e r a n t
e a r t h f r i e n d l y r e f r i g e r a n t
™
™
13.0
The Rheem Prestige Series High Efficiency RAPL- JEZ and
®
RANL- JEZ Condensing Units were designed with performance in
mind. These units offer comfort, energy conservation and depend-
ability for single, multi-family and light commercial applications.
These units also contain the most advanced alternate refrigerant
which contains no chlorofluorocarbons (CFCs), or hydrochloroflu-
orocarbons (HCFCs), or other compounds that may leak from air-
conditioning systems and potentially harm the protective ozone
layer of the Earth's atmosphere.
The Rheem Prestige ® Series RAPL- JEZ and RANL- JEZ Con-
densing Units are the result of an ongoing development program
for improved efficiencies. These units are flexible enough to
achieve up to 15.50 SEER in specific match-ups, continuing a
tradition of high efficiency.
I
The Comfort Control System
and fault history for condensing units with single-phase com-
pressors by detecting system and electrical problems without
adding sensors. It can also communicate "fault codes" to
enabled "L terminal" thermostats. The integrated diagnostics
with Active Protection ™ prevents compressor operation when
potentially harmful conditions are detected.
I
7-Segment LED Display is exclusive only to Rheem products. The
information-display quickly and accurately shows technicians the
source of malfunctions.
I
Five-year conditional unit replacement warranty.
I
Compressor sound blanket is standard to provide quiet operation.
I
Attractive, louvered wrap-around jacket protects the coil from
yard hazards and weather extremes. Top grille is steel rein-
forced for extra strength. Cabinet is powder painted for all-
weather protection.
I
Air is discharged upward away from bushes and shrubs. The dis-
charge pattern of the top grille provides minimum air restriction.
I
Combination Grille/Motor Mount secures the motor to the
underside of the discharge grille. The grille protects the motor
windings and bearings from rain and snow.
I
Removable top grille provides access to the condenser fan
motor and condenser coil.
I
Single speed 8-pole fan motor designed for low speed, quiet,
energy-saving operation.
I
All models meet or exceed a 1000-hour salt spray test per
ASTM B117 Standard Practice for Operating Salt Spray Testing
Apparatus.
14 SEER MODELS &
13 SEER MODELS
(IN CERTAIN MATCHED SYSTEMS)
FORM NO. A11-187 REV. 2
Supersedes Form No. A11-187 Rev. 1
™ provides on-board diagnostics
