Icom IC-7100 Finger Touch Operation page 3

HF/50/70/144/430MHz Multi-band, Multi-mode
The IC-7100 fully covers the HF, 50, 70, 144, 430 MHz amatuer bands in
multiple modes, providing 100W on HF/50MHz bands, 50W on 70/144MHz
bands and 35W on 430MHz band.
Digital Features Controlled by the IF DSP
A high-performance 32-bit floating point IF
DSP delivers rich digital signal processing
features, including digital IF filter, digital
twin PBT, noise reduction, CW auto tune, etc.
Those digital features work on all bands from
HF to V/UHF bands.
DSP Controlled AGC Function Loop
The digital signal processing is incorporated into the AGC function loop.
The results of signal processing provide feedback to the AGC function.
The AGC function works on the
intended signal and produces
455kHz
a constant audio output.
IF
AMP
The AGC time constants are
flexibly adjustable from slow,
middle, fast ( or AGC off ) for
each operating mode.
(
D-STAR Ready Digital Voice + Data
The IC-7100 provides D-STAR ( Digital Smart Technology for Amateur
Radio ) DV mode digital voice and low speed data communication.
( )
DR D-STAR Repeater Mode Operation
The DR mode operation makes the D-STAR operation
simple and straight forward, even if you are new to
D-STAR operation.
Near Repeater Function
With an external, 3rd party GPS*, search the internal
database based on your location.
* External GPS receiver or manual data input required.
SD Memory Card Slot for Saving Data
When used with an SD card, the SD card can
store various contents including voice memory,
memory channels, D-STAR repeater memories
and other personal settings can be saved to the
SD card and can be loaded to the transceiver.
HF/VHF/UHF ALL MODE TRANSCEIVER
32-bit floating point IF DSP
DSP
36kHz
IF
AD BPF DA
AMP
AMP
AGC
DET
AGC
DA DET
AGC loop
AGC function loop
)
DR mode display
Near repeater function
SD memory card slot
Easy Vehicle Mounting with Optional MBF-1
The combination of the optional MBF-1 suction
cup mounting base and MBA-1 controller bracket
provides easy tilt and swivel adjustments for
mobile operation. The large suction
cup can mount to dashboards or
other flat surfaces and can be
removed easily.
Optional RS-BA1 IP Remote Control Software
The optional RS-BA1 software allows you
to operate the IC-7100 from a remote PC
over the Internet or local home network.
IP Remote Control
through your Home Network
IC-7100
RC-28
AF
RS-BA1
Built-in RTTY Functions
The built-in RTTY decoder allows you to instantly read an RTTY message on
the display. No external TNC or PC required for reading. The eight RTTY
memories can memorize and transmit often used RTTY sentences. The RTTY
memory is 70 character per memory channel.
Other Features
●
CW full break-in, CW receive reverse, CW auto tuning
●
HM-151 Band scope and SWR graphic display
●
DSP Voice memory function
900 DR mode repeater channels
● ●
Auto reply function* Digital callsign squelch and digital code squelch*
DRM ( Digital Radio Mondiale
* D-STAR DV mode only
acket
ts for
ion
MBF-1
IP Remote Control
over the Internet
RS-BA1
Remote location
RC-28
Internet
RS-BA1
●
Optional multi-function microphone,
●
RF speech compressor controlled by the
● ●
Multi-function Meter 495 regular, 4 call, 6 scan edge and
● ●
4 channels TX voice memories ±0.5ppm frequency stability
) receive
Transceiver location
IC-7100
RS-BA1
IP Network
●
12kHz IF output for
