Glastender MFV24 Product Features And Specification

A family company manufacturing in the USA
MFV24-SS(L)
MFV48-SS(LR)

Specifications

Electrical

• 120V, 1 phase, 60 Hz, MFV24 - 5.0 full load amps, MFV48 - 5.5
full load amps
• Dedicated 15 amp circuit is required
• Includes a 6 foot grounded cord and plug which exits the back of
refrigeration compartment

Refrigeration

• 1/5 HP, R404A refrigerant

Operating Range

• 0ºF (-18ºC) to 35ºF (2ºC)

Plumbing

• Automatic condensate evaporator. No drain connection required

Shelving

• Bottom rack and two shelves included

Capacity

• 10-oz mugs: MFV24 - 108, MFV48 - 252
• 6" high pint glass: MFV24 - 75, MFV48 - 180
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
989.752.4275 • 800.748.0423 • Fax 989.752.4444
www.glastender.com
Specifications subject to change without notice. For current specifications please visit our website.
Printed in USA
Conforms to ANSI/UL STD 471
Certified to CSA STD
C22.2 No. 120
4.18
Project:
Item #:
Model #:
Reach-in Mug Frosters
One & Two Door
Self-contained
MFV__-_
Size:
24 = 24" One Door
Door Style:
B = Black vinyl clad
48 = 48" Two Door
U = Unlaminated
L = Laminated
S = Stainless
G = Glass
X = Stainless Glass
Y = Laminated Glass

Standard Features

• Self-contained high capacity refrigeration system
• Digital thermostat control with automatic defrost is easily visible
• Removable refrigeration module for easy maintenance
• All stainless steel interior
• Bottom rack and two adjustable shelves per door
• Includes LED interior lights with on/off switch
• Completely front venting - can be built into a back bar or used
as a free standing unit
• Galvanized steel sub top (available with stainless steel or lami-
nated finished top)
• Stainless steel sides
• Automatic condensate evaporator
• Foamed-in-place insulation
• Six foot grounded cord and plug (exits at rear)
• 180° swinging doors
• Optional 3-3/4" casters or 6" legs are available

Legs

• Optional 6" legs, specify accessory #CLS-4
• 1-5/8" diameter
• Stainless steel bullet feet

Materials

• 22 gauge stainless steel parts include: interior floor, walls, ceiling,
front of cabinet, and evaporator housing
• 22 gauge black vinyl-clad parts include: standard door(s), and
compressor compartment cover
• 22 gauge galvanized steel parts include: exterior sub-top and back
• 20 gauge stainless steel parts include: sides and optional top
• 16 gauge stainless steel parts include: legs
• 16 gauge galvanized steel parts include: base
• 12 gauge stainless steel parts include: hinges, hinge brackets, and
lock brackets
Approval/Notes:
AIA#
Qty:
SIS#
_ (_ _)
Door Hinge Location:
(from left to right)
L = Left or R = Right
Top Style:
N = No finished top
L = Laminated
S = Stainless
Rev.11-13-13
