Glastender FRM-2 Specifications

A family company manufacturing in the USA

Specifications

Capacity
• Two 3-gallon containers
Electrical
• 120V, 1 phase, 60 Hz, 4.2 full load amps
• Dedicated 15 amp circuit is recommended
• Includes 6 foot grounded cord and plug
Refrigeration
• Operating range -5°F (-20°C) to 10°F (-12°C)
• 1/5 HP, R404A refrigerant
Casters
• Four 3" heavy duty rubberized casters
• The two server side casters are locking
Materials
• 20 gauge stainless steel parts include: all components
unless otherwise noted
• 16 gauge galvanized steel parts include: cabinet floor,
condensing unit floor, and base channels
Glastender, Inc. • 5400 North Michigan Road • Saginaw, MI • 48604-9780
989.752.4275 • 800.748.0423 • Fax 989.752.4444
www.glastender.com
Specifications subject to change without notice. For current specifications please visit our website.
Printed in USA
FRM-2
Conforms to ANSI/UL STD 471
Certified to CSA STD
C22.2 No. 120
18"
6.10
Project:
Item #:
Model #:
Mobile Ice Cream
Freezer
Standard Features
• All stainless steel exterior with 16 gauge galvanized steel
exterior bottom.
• Completely integrated design - not just a cabinet with separate
drop-in module
• All stainless steel interior liner with radius corners for easy
cleaning
• One-piece, seamless top
• Includes four 3" casters, with two locking casters
• CFC free foamed-in-place insulation
• Six foot grounded cord and plug provided, exits at rear
• Designed to accommodate outlet behind unit and still sit flush
against the wall
• Holds two 3-gallon containers
Dimensional Information
24"
PLAN VIEW
Approval/Notes:
AIA#
Qty:
SIS#
FRM-2
12"
SIDE ELEVATION
Rev 08-26-13
36"
