Precor 842i Product Specification

842i Recumbent Cycle
Recumbent bike for commercial use.
Features
•
Resistance
Magnetic, no-contact generator system provides a wide range of resistance. 25 different resistance
settings let users maximize workouts. Resistance levels range from 18 watts (level 1 at 20 RPM) to 750
watts (level 25 at 150 RPM).
•
Drive
3-piece crank tightens positively, reducing the need for periodic adjustments. The 9/16" crank arm
system
accepts any standard road or mountain bike pedal.
•
Double step up drive system yields smooth, comfortable, quiet operation.
•
3-phase generator/eddy current brake system requires no backup battery in order to power the bike.
•
Belt drive (Primary drive: 10 groove poly-V. Secondary drive: 8 groove poly-V) for smoother, quieter
operation and reduced maintenance.
•
25mm Clutch resists slipping at even the highest level of resistance.
•
Display
Ability to switch between courses during workout without losing user feedback.
•
Membrane display.
•
Power jack in upper display to run entertainment systems.
•
Frame
Two-step powder-coating process applies rust-resistant undercoat and cosmetic topcoat to steel frame.
•
Both sets of handlebars are covered with sweat-resistant fused-cell foam that remains pliable and helps
keep the underlying steel dry.
•
Adjustable straps on pedals fit a wide range of shoe sizes, and low-profile crank arms position feet for
unrestricted movement.
•
Comfortable ergonomically correct seat fits a wide range of body types. Seat is angled for proper thigh
clearance.
•
Diagnostics
Ability to set club parameters, e.g., limit exercise time and pause time.
•
Heart Rate
Equipped for heart rate telemetry reading using Polar® technology.
•
SmartRate® shows actual heart rate in relation to the target zone for weight loss and cardio training.
•
Other
QuickStart™ lets users conveniently begin workout with the push of a single button.
•
Features
Accessory holder for water bottle, reading material and portable music.
•
Transport wheels located in front for easy movement.
•
Warranty
Seven years frame, 1 year battery, 2 years parts and 1 year labor. Warranties outside the U.S. and
Canada may vary.
•
6 Programs
Cross Country, Heart Rate Control**, Hill Climb, Interval, Manual, Weight Loss
Electronic Readouts
• •
Calories
• •
Distance
Recumbent Measurements
•
Length
•
Width
•
Height
•
Maximum user weight
•
Resistance levels
•
Distance from seat-back
cushion to crank
•
Regulatory approvals
Power
Self-powered. Cordless, so it can be placed anywhere on the floor.
Commercial Sales (425) 486-9292
•
Heart Rate** Resistance Level
•
Profile RPM
57 in (145 cm)
24 in (61 cm)
48 in (122 cm)
350 lbs. (159 kg)
25
30 in (76 cm) minimum
42.5 in (108 cm) maximum
FCC, ETL, CE
October 5, 2004
Product Specification
* Polar® is a registered trademark of Polar Electro Oy.
•
SmartRate®
•
Speed
•
Weight
•
Shipping Weight
•
Maximum pause time
•
Maximum workout time
•
Resistance range
•
Distance from front of
seat to crank axle
** Requires a heart rate chest strap.
•
Time
•
Watts
** Requires a heart rate chest strap.
160 lbs (73 kg)
220 lbs (100 kg)
30 seconds
Unlimited
18 – 750 watts
18 in (46 cm) minimum
30.5 in (77.5 cm) maximum
www.precor.com
