02
uNpACKING
NVIDIA Quadro Plex 7000
The NVIDIA Quadro plex 7000 contains two (2)
NVIDIA Quadro Gpus driving one (1) to four (4)
channels and one (1) NVIDIA Quadro G-Sync II
board. The four (4) dual-link DVI-I connectors
are standard connections for high-speed, high-
resolution digital displays. The DVI-I connectors
support both digital and analog signals. The
3-pin mini-DIN is a standard VeSA connector
used for stereo connections.
one (1) NVIDIA Quadro
G-Sync II board
one (1) BNC house
sync connector
9
Two (2) 3-pin
mini-DIN connectors
Four (4) dual-link DVI
connectors
one (1) interconnect
cable connector
