Ken A Vision PupilCAM®1402KRM Specifications

PupilCAM
1402KRM
Camera Image Sensor
Pixel Count
Frame Rate
OSD
Output
Resolution
Output
RS232
USB Connection
USB Cable
Operating
Temperature
Lighting
Power Source
Cross Platform OS Yes Windows, Mac, LINUX
UVC Driverless
MSI support
Memory
Advance Imaging
Average Set up
time
Free Updates
IWB Compliant
Viewing Angle
Connect to
Microscope
Lens
Controls Digital Zoom
Focus
White Balance
Color/B&W
Gamma
Adjustment
Negative/Positive
Image Rotation
Capture/Freeze
Audio Recording
Compression
Annotation
®
Detailed Specifications (July 2013)
KAV CMOS 3.2 Megapixel
ACT 2048(H) X 1536(V)
Yes Variable with selected screen size
Default 13 fps at max resolution of 2048 X 1536 (3.2)
VGA 30 fps at resolution of 640 X 480
Yes Controlled by software buttons
Yes HD 1080P
Yes VGA, RGB (DVI, HDMI depending on your computer's configuration)
Yes via Software interface of computer
Yes USB 2.0 compliant
Yes Factory installed 1.7 m USB 2.0
Use 0° C - 50° C
Use Low Lighting to work with electtrical microscopes
N/A 5 VDC, 200 mA from USB port ONLY meeting green initiative
Yes Works on Windows, MAC, and Linux
Yes installation, maintenance, and removal of software via Microsoft server
Yes Image / Video
Image Recording: 400 minimum* average 132,000 images per standard hard
drive space of 20GB at 2048 X 1536
Video Recording: 8 minutes minimum* OR 4 hours per standard hard drive
space of 20 GB at AVI resolution 640 X 480
Yes For Science Studies to include 3D rendering, measurement of varied angles,
counting, and much more
N/A less than 5 minutes for 1 – 1,000 units using MSI for Cross platform software
installations
Yes For the life of the product on software and hardware
Yes Interactive White Board Compliant for most current boards.
Yes 60 degree: diagonal, 50 degree: Horizontal
Yes Built-in rubber eyepiece adapter; fits over most microscope eyepieces
(25mm - 34mm)
N/A
Yes Controlled by software buttons up to 16x
Factory Set for optimal viewing
Yes Auto or manual controlled by software buttons
Yes Black and White controlled by software buttons
Yes Auto or manual controlled by software buttons
Yes Controlled by software buttons
Yes 360° in both directions controlled by software buttons
Yes Freeze image via software button
Yes Synchronized recording via software buttons
Yes JPEG
Yes in software or working with Interactive Whiteboard interfaces
EduCam
optimized
