2.2 System Overview

This chapter describes the functions and operating principal of the main component.

2.2.1 Front View

This illustration may differ from your machine depending on its model.
1 Control panel
2 Top cover
3 Toner cartridge
4 Tray
Service Manual
Product spec and feature
5 Paper length guide
6 Paper width guides
7 Output support
8 Output tray (face down)
