Altuscn KL3116T Quick Manual

KL3116T
16-Port Dual Rail Touchscreen KVM Switch
The KL3116T Dual Rail Touchscreen KVM Switch is an integrated LCD console and KVM (keyboard, video,
and mouse) switch that offers secure access to 16 attached computers with a dual USB or PS/2 interface,
and mounts in only 1U of rack space. It features an independently retractable 17" touchscreen LCD monitor
and keyboard with built-in touchpad. To maximize space in your data center the keyboard "hides away"
when not in use, while the thin profile LCD monitor reclines flush against the rack to enable continuous
monitoring of computers.
The KL3116T is ideal for industrial environments such as factory production lines, laboratories, and sever
rooms, or anywhere else an LCD KVM switch is required. Anyone working on a production line while
wearing gloves knows the difficulty of trying to control on-screen testing programs with the use of a
mouse. The KL3116T touchscreen is the easiest and most convenient way to solve problems with user
interactive production line testing programs. You can use the touchscreen, as well as additional on-screen
icons, to operate the OSD menu or apply hotkey functions. As many as 31 additional switches can be
daisy-chained together, so that up to 512 computers can be controlled from a single keyboard,
touchscreen, and mouse console. You can also conveniently share USB peripherals attached to the KL3116T
with computers on the same level. The KL3116T is the first Dual Rail Touchscreen KVM switch of its kind
that requires no additional software to operate; simply
connect the KL3116T to your installation and begin using it
immediately.

FEATURES

• Integrated KVM console with 17" LCD monitor in
a Dual Rail housing
• Space saving technology – up to two consoles
(sharing one bus) can control up to 16 computers
• Touchscreen offers convenient operation without
extending the keyboard module or using a mouse
• Touchscreen on-screen icons enables quick and full operation of the OSD menu or apply
hotkey functions
• Supports touchscreen for control without drawing out the keyboard
• Simple one-point and two-point touchscreen calibration including separate methods for
calibrating the OSD (on-screen display) and attached computers with varying resolutions
• Dual interface supports computers and KVM Switches with PS/2 or USB keyboards and mice
• USB peripheral support for attached
• Conveniently located station and port selectors with LED displays to quickly switch to target
computers
• Dual Rail housing is slightly less than 1U with top and bottom clearance for smooth operation
in 1U of rack space
• LCD module rotates up to 120 degrees for a more comfortable viewing angle
• Console lock – enables the console drawer to remain securely locked away in position when
not in use
• Dedicated Hotkey Mode and OSD invocation Keys reduce the number of keystrokes and
provide quick access to these functions
• Daisy-chain up to 31 additional KVM switches** to control up to 512 computers
computers*
