in that frequency range, thus reducing the sibilance of the program material.
Attack and Release times should be set fairly short, and the compression ratio
should be below 8:1.
S
PECIFICATIONS
Frequency Response: 10 Hz - 30 kHz, ±0.5 dB.
THD+Noise: 0.06%.
Signal-To-Noise Ratio: -97 dB.
Input Impedance: 20 KΩ unbalanced, 40kΩ balanced.
Maximum Input Level: +21 dBu (ref.:0.775 Vrms).
Output Impedance: 51Ω unbalanced, 102Ω balanced.
Maximum Output Level: +21 dBu (ref.: 0.775 Vrms).
Side Chain Input Impedance: 10 kΩ.
Side Chain Maximum Input Level: +21 dBu (ref.: 0.775 rms).
Side Chain Output Impedance: 51Ω unbalanced, 102Ω balanced.
Side Chain Maximum Output Level: +21 dBu (ref.: 0.775 Vrms).
Gate Threshold: Adjustable from -55 dBu to -10 dBu.
