1 6
Crossover Frequencies - Stereo: LOW/MID: 50 Hz to 5 kHz in two ranges,
MID/HIGH: 750 Hz to 7.5 kHz. - Mono: LOW/LOW-MID: 50 Hz to 5 kHz in two
ranges, LOW-MID/HIGH-MID: 50 Hz to 5 kHz in two ranges, HIGH-MID/HIGH:
2 kHz to 20 kHz.
Input Impedance: 20 k Ω unbalanced, 40 K Ω balanced.
Maximum Input Level: +21 dBu (ref.: 0.775 Vrms).
Output Impedance: 102 Ω..
Maximum Output Level: +21 dBu (ref.: 0.775 Vrms).
S
835 PECIFICATIONS
Crossover type: Stereo 2-way, Mono 3-way.
I/O Connectors: 835: Inputs: 1/4" tip-ring-sleeve phone jacks for
balanced/unbalanced connections. Outputs: 1/4" tip-ring-sleeve phone jacks
for balanced connections and 1/4" tip-sleeve phone jacks for unbalanced con-
nections. 835 XLR: Inputs: balanced female XLR, Outputs: balanced male
XLR.
THD+Noise: Less than 0.006%.
Signal-To-Noise Ratio: Greater than -90 dB
Filter Type: 18 dB/octave Butterworth state-variable filters.
Crossover Frequencies -
Stereo: LOW/HIGH: 100 Hz to 10 kHz in two ranges. -
Mono: LOW/MID 100 Hz to 10 kHz in two ranges. MID/HIGH 100 Hz to 10
kHz in two ranges.
Input Impedance: 20 k Ω unbalanced, 40 K Ω balanced.
Maximum Input Level: +21 dBu (ref.: 0.775 Vrms).
Output Impedance: 102 Ω..
Maximum Output Level: +21 dBu (ref.: 0.775 Vrms).
