  • Page 1 DVD Player DPS-5.9 Instruction Manual...

  • Page 2: Important Safety Instructions

    WARNING: WARNING AVIS TO REDUCE THE RISK OF FIRE OR ELECTRIC RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the CAUTION: presence of uninsulated “dangerous voltage”...

  • Page 3: Precautions

    Precautions 1. Recording Copyright —Unless it’s for personal use • Do not expose this unit to direct sunlight or heat only, recording copyrighted material is illegal with- sources, because its internal temperature may out the permission of the copyright holder. rise, shortening the life of the optical pickup.
  • Page 4 Precautions—Continued Modèle pour les Canadien This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to REMARQUE: CET APPAREIL NUMÉRIQUE DE use this model properly, read this Instruction Manual LA CLASSE B EST CONFORME À LA NORME carefully.

  • Page 5: Table Of Contents

    Displaying Information....... 43 Rear Panel ...........14 Configuring the DPS-5.9 ......44 Remote Controller ........15 Using the On-screen Setup Menus ..... 45 Before Using the DPS-5.9....... 17 Picture Menu..........45 Installing the Remote Controller’s Audio Menu ..........47 Batteries ..........17 Language Menu .......... 48 Using the Remote Controller.......17...

  • Page 6: Introduction

    Keep this manual for future reference. Remote controller (RC-658DV) & 2 batteries (AA/R6) AV connecting cable (RCA) (4.9 ft., 1.5 m) cable (2.6 ft., 0.8 m) This cable is used to connect the DPS-5.9 to other compatible Integra/Onkyo components for (Remote Interactive) control. To use...

  • Page 7: Dps-5.9 Features

    • Last Memory function allows you to resume playback ing LLC. from a specific point on a DVD-Video disc, even if that disc has been removed from the DPS-5.9 • Supports 4:3 and 16:9 aspect ratio TVs RIHD is a trademark of Onkyo Corporation.

  • Page 8: Disc Notes

    DVD-Video, MP3, made labels or stickers. Doing so may damage the DVD-RW WMA, JPEG DPS-5.9 and you may not be able to remove the disc properly. Audio CD About playing copy-controlled CDs Some copy-controlled CDs may not conform to official Audio CD, MP3, WMA, CD standards.

  • Page 9: About Wma

    • The folder numbered “001” appears as “ROOT” in the Disc Navigator. Audio CD • The DPS-5.9 supports up to 255 folders and up to 255 files per folder. ■ MP3/WMA Files • If you try to play an incompatible file, the message MP3 and WMA files are typically organized into folders.
  • Page 10 Introduction —Continued Handling Discs Copyright • Never touch the underside of a disc. Always hold discs It is forbidden by law to copy, broadcast, show, broadcast by the edge, as shown. on cable, play in public, or rent copyrighted material without permission.

  • Page 11: Dps-5.9-Related Terminology

    Introduction —Continued ■ HDMI (High Definition Multimedia Interface): DPS-5.9-related Terminology A new connection format that greatly simplifies AV ■ CD-R (Compact Disc Recordable): A type of connections by carrying uncompressed SD or HD CD that can be recorded only once. Can be used to digital video and digital audio all in one cable.

  • Page 12: Controls & Connectors

    The page numbers in parentheses show where you can find the main explanation for each item. On/Standby button (25) Open/Close button (28) This button is used to set the DPS-5.9 to On or This button is used to open and close the disc tray. Standby.

  • Page 13: Display

    Controls & Connectors—Continued Display The page numbers in parentheses show where you can find the main explanation for each item. PROGRESSIVE indicator (27) D indicator This indicator appears when progressive video is D indicator appears when playing Dolby being output by the component video output. While Digital material.

  • Page 14: Rear Panel

    This HDMI jack outputs digital video and audio and the DPS-5.9 is located in another room, installed in can be connected to an HDMI input on a compatible a rack, or is out of range of the remote controller.

  • Page 15: Remote Controller

    Don’t turn on the DPS-5.9 until you’ve completed, and double checked all connections. Standby button (25) This button is used to set the DPS-5.9 to Standby. Number buttons (32, 33, 39, 49) These buttons are used to enter title, chapter, and track numbers and to enter times for locating spe- cific points in time.
  • Page 16 Controls & Connectors—Continued Menu button (29, 36) Enter button (45) This button is used to select the menu. This button is used to start playback of the selected title chapter, or track and to confirm settings. Aspect/Zoom button (42, 43, 46) Setup button (45) This button is used to change the view mode.

  • Page 17: Before Using The Dps-5.9

    DPS-5.9. • If another remote controller of the same type is used in the same room, or the DPS-5.9 is installed close to Close the battery compartment. equipment that uses infrared rays, the remote control- ler may not work reliably.

  • Page 18: Connecting The Dps-5.9

    Connecting the DPS-5.9 RCA AV Connection Color Coding This chapter explains how to connect the DPS-5.9 to your other AV components. RCA AV connections are usually color coded: red, Before Making Any Connections white, and yellow. Use red plugs to connect right-chan- nel audio inputs and outputs (typically labeled “R”).

  • Page 19: Connecting Your Tv Or Projector

    Connecting the DPS-5.9—Continued Connecting Your TV or Projector This section explains how to connect the DPS-5.9 to cable to connect the DPS-5.9’s VIDEO OUTPUT to a your TV or projector. composite video input on your TV. See page 22 for connecting a TV or projector that Compatibility of this unit with progressive-scan TVs.

  • Page 20: Connecting An Av Receiver

    27, 46), the DPS-5.9 cannot output progres- Analog Connection sive video. To output progressive video, you must Use an RCA audio cable to connect the DPS-5.9’s ANA- set the HDMI Output setting to Off (see pages 27, 46), and set the Progressive setting to Progressive LOG AUDIO OUTPUTs to a pair of analog audio inputs (see pages 27, 46).

  • Page 21: Connecting A Stereo Amp

    Use an RCA audio cable to connect the DPS-5.9’s ANA- output at all. LOG AUDIO OUTPUTs to a pair of analog audio inputs • Never connect the DPS-5.9 to the AC-3RF input on a on your stereo amp, as shown. Dolby Digital receiver. The AC-3RF format is not sup-...

  • Page 22: Connecting A Component With An Hdmi Input

    Content Protection), a protection system for digital video. HDMI components that you connect to the This section shows how to connect the DPS-5.9 to an AV DPS-5.9 must also support HDCP. receiver, HDTV, or projector with an HDMI input.

  • Page 23: Connecting -Compatible Components

    You must also connect the audio cables as well. • For remote control operation, you must make an ana- log RCA connection between your DPS-5.9 and the other AV component, even if they are connected digi- tally. • If you’re using RIHD, do not connect anything to the...

  • Page 24: Controlling Av Components That Are Out Of Range

    IR emitter Controlling the DPS-5.9 When It’s Out of Remote controller Range If the DPS-5.9 is located in another room, installed in a Other component cabinet, or out of range of its remote controller, you can use a commercially available IR receiver to pickup the remote controller signals and feed them to the DPS-5.9,...

  • Page 25: Dps-5.9

    Note: • The DPS-5.9 features a screen saver and an auto power off function. If the DPS-5.9 is stopped and no button is pressed for 15 minutes, the screen saver Plug the supplied power cord into starts (see page 48).

  • Page 26: Initial Setup

    • You can cancel the Initial Setup by pressing the [Setup] button and complete the settings later by using Here you need to make a few settings to get the DPS-5.9 the onscreen setup menus (see page 45). up and running. You can change these settings later (see •...

  • Page 27: Hdmi And Progressive Settings

    See page 22 for HDMI connection information. If your TV’s component video input supports progres- Press the DPS-5.9’s [HDMI] but- sive video, you can set the DPS-5.9 to progressive and ton to turn on HDMI. enjoy progressive video on your TV. If your TV’s com- ponent video input doesn’t support progressive video,...

  • Page 28: Basic Playback

    Basic Playback This chapter covers basic playback. Advanced playback Press Open/Close to open the functions are covered in the next chapter. disc tray. Important: • Throughout this manual, the term DVD refers to DVD-Video, DVD-R/RW, and DVD+R/RW discs. When a function is specific to a particular type of Remote controller DVD disc, it will be specified.

  • Page 29: Starting, Pausing & Stopping Playback

    (see page 41). and audio formats can usually be selected during play- • Do not move the DPS-5.9 or subject it to vibration back by using the remote controller’s [Audio] button during playback. Doing so may damage your discs or (see page 41).

  • Page 30: Using The Disc Navigation Window

    004. Integra 2 001. Track01 002. Track02 003. Track03 004. Track04 Pause Name: Integra Title Artist Name: Integra Artist Play Down Folder number and file number. Elapsed time, remaining time, and Stop total time of currently playing song. (Only elapsed time is shown Enter for WMA files.) (See also page 43.)
  • Page 31 Basic Playback—Continued Press the Down [ ] button to restart the current track. Press it again to select earlier tracks. Alternatively, the number button is used to select a track. For MP3, WMA, and JPEG discs: To open a folder, use the remote con- troller’s Up/Down [ ]/[ ] buttons to select it, and then press [Enter].

  • Page 32: Selecting Titles, Chapters & Tracks By Number

    Basic Playback—Continued Selecting Titles, Chapters & Tracks by Play Number This section explains how to select titles, chapters, and tracks by number. Load a disc. See page 28. Enter Press the [Search] button. The Search window appears on-screen, Remote controller as shown.

  • Page 33: Locating Specific Points In Time

    Basic Playback—Continued Notes: Locating Specific Points in Time • You can also select chapters by using the number but- tons, without opening the Search window. • If the current DVD-Video disc contains only one title, With the Time Search function you can locate specific you won’t be able to select other titles.

  • Page 34: Fast Forward & Reverse

    During playback, press the FR screen burn-in. To prevent this, don’t display the same reverse ] button to start fast reverse. frame for too long. Your DPS-5.9 features a screen Playback reverses and “ x 2” Remote controller saver to protect your TV from the effects of burn-in appears on-screen.

  • Page 35: Slow-Motion Playback

    Basic Playback—Continued Slow-motion Playback With the Slow-motion Playback function you can watch a scene slowly either forward or backward. ■ Forward During playback, press the Slow slow ] button. motion Forward slow-motion playback starts and “ 1/2” appears on-screen. Remote controller To change the slow-motion speed, press the Slow Forward [ ] button...

  • Page 36: Using Jpeg Cds

    Basic Playback—Continued Using JPEG CDs Pause Stop Play The DPS-5.9 supports JPEG CDs, so you can view your photos on TV either individually or as a slideshow. Load a CD containing JPEG pic- tures. Use the [ ], [ ], [ ], [ ] buttons to...

  • Page 37: Advanced Playback

    Advanced Playback Repeat Playback Play JPEG With the Repeat Playback function you can play the cur- rent disc, title, chapter, track, or folder of MP3/WMA/ JPEG files over-and-over again. Press the Play [ ] button to start repeat playback. Remote controller Press the [Repeat] button repeat- edly to select a repeat option.

  • Page 38: A-B Repeat Playback

    Advanced Playback—Continued Press the [A–B] button again to set the B point (i.e., the end of the Stop Play Remote controller section you want to repeat). Playback repeats between the A and B points, and “Repeat A-B” appears onscreen. A-B indicator and “R_AB”...

  • Page 39: Memory Playback

    Advanced Playback —Continued Press the [Enter] button. To cancel random playback, use The new item is added to the memory the [Random] button to select Remote controller Remote controller list as item 01. Off. Memory List Title/Folder Chapter/Track Chapter/Total 001 / 002 Current/Total --- / 008 001 / 002...
  • Page 40 “Memory Clear” is displayed on-screen. Notes: I I I I • The entire memory list is cleared when the DPS-5.9 is nserting New Items in the List set to Standby. • The Memory Playback function cannot be used with...

  • Page 41: Using Last Memory

    [ ] button once or twice. Notes: Now you may remove the disc • With some DVD-Video discs you may not be able to and turn off the DPS-5.9. select different camera angles even though the camera Remote controller indicator is displayed.

  • Page 42: Selecting Subtitles

    Advanced Playback—Continued Selecting Subtitles Some DVD-Video discs feature subtitles in several lan- guages. See the disc’s sleeve notes for details. During playback, press the [Sub- Remote controller title] button repeatedly to cycle through the available subtitles. Display The name of the selected subtitle appears on-screen for several seconds.

  • Page 43: Setting The View Mode

    Advanced Playback—Continued Notes: The information displayed depends on the type of disc, • The Zoom function may not work with some discs. as follows: • The Zoom function can also be used during slow- ■ DVD-Video motion playback. Onscreen: • The Zoom function cannot be used with HD JPEG •...

  • Page 44: Configuring The Dps-5.9

    Settings for the digital signal output by the optical, coaxial, and Digital/HDMI Audio Out Audio HDMI digital audio outputs. Select whether or not the DPS-5.9 downsamples 96 kHz digital Linear PCM Out audio. Dynamic Range Control Set the Dynamic Range function.

  • Page 45: Using The On-Screen Setup Menus

    TV menus. (4:3 aspect ratio). When you watch widescreen DVD-Video Turn on your DPS-5.9 and TV. movies, the entire picture will be On your TV, select the video input to visible and there will be black which the DPS-5.9 is connected.

  • Page 46: View Mode

    HDMI Output Setting Note: With this setting you can turn the HDMI video output on • If Auto selected but the DPS-5.9 doesn’t support the or off. See page 27 for more information. resolution preferred by the TV, the resolution will be 480p/576p.

  • Page 47: Audio Menu

    48 kHz, and video output will be PAL format. And when you play in some cases may not be output by the DPS-5.9’s dig- an NTSC disc, it’ll be NTSC format. Your TV must ital audio outputs.

  • Page 48: Language Menu

    With this setting you can select the color of the back- • If a DVD has only one menu language, that will be used. ground that’s displayed when the DPS-5.9 is stopped. • With some DVD-Video discs you can select languages from a menu.

  • Page 49: Operating Setting Menu

    Configuring the DPS-5.9—Continued • Not all discs use parental lock. See the disc’s sleeve Operating Setting Menu notes for details. • Discs with parental lock may cut certain scenes, Parental Lock replace certain scenes with children-friendly scenes, With the Parental Lock function you can block access to or prevent playback of the entire disc.

  • Page 50: Initial Setup Menu

    Use the remote controller’s Left/ HDMI Control setting is set to On. Right [ ]/[ ] buttons to select the • When set to On, the DPS-5.9 can be turned on or off Remote controller code boxes. automatically along with the other RIHD-compatible Use the Up/Down [ ]/[ ] buttons components in the system.

  • Page 51: Language Code List

    Configuring the DPS-5.9—Continued Language Code List Use this list when specifying other languages. Language Code Language Code Language Code Language Code Hebrew Japanese Kirghiz Yiddish Ukrainian English Latin Javanese Urdu French Lingala Georgian Uzbek German Laothian Kazakh Vietnamese Italian Lithuanian Greenlandic Volapük...

  • Page 52: Troubleshooting

    The power cord is not connected. Connect the power cord to a suitable wall outlet. Can’t turn Turn off the DPS-5.9, wait five seconds, then try turning it on on the External interference is affecting the DPS-5.9’s again. If that fails, disconnect the power cord from the wall out- DPS-5.9?
  • Page 53 Your TV or AV receiver doesn’t support Dolby Change the Digital/HDMI Audio Out setting to Digital. PCM (page 47). The DPS-5.9 will not be able to play DTS format audio or soundtracks. On your DVD-Video disc’s No sound? Your TV or AV receiver doesn’t support DTS.
  • Page 54 The DPS-5.9 is not connected with an analog and an analog audio connection (RCA) between work? audio connection. the DPS-5.9 and the AV receiver, even if they are connected digitally. The HDMI Control setting is set to Off. Set the HDMI Control setting to On.
  • Page 55 DPS-5.9’s [Display] button for 10 seconds until a message ID appears on the display. Look up the message ID in the following tables and check the HDMI connections and settings on both the DPS-5.9 and the connected component.

  • Page 56: Specifications

    Disc that have not been property finalized may only be par- tially playable or not playable at all. Specifications and features subject to change without notice. Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A.
