DVD Audio/Video Player
DPS-7.3
Instruction Manual
Thank you for purchasing the Integra DVD
Audio/Video Player.
Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will
enable you to obtain optimum performance
and listening enjoyment from your new DVD
Audio/Video Player.
Please retain this manual for future reference.
Table of Contents
Getting Started
Connecting
Setting Up the Player
Basic Playback
Advanced Playback
Function Setup
Toubleshooting
Others
E

Advertisement

Table of Contents
loading

Related Manuals for Integra DPS-7.3

Summary of Contents for Integra DPS-7.3

  • Page 1 DVD Audio/Video Player DPS-7.3 Instruction Manual Thank you for purchasing the Integra DVD Audio/Video Player. Please read this manual thoroughly before making connections and plugging in the unit. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new DVD Audio/Video Player.

  • Page 2: Table Of Contents

    Setting Up the Player Setting Up the Player ... 17 • Various sound formats and sound effects ... 20 Basic Playback Getting Started Using Your DVD Player ... 21 Others Pre-programming remote controller ... 60 Operating components not reached by the remote controller signals (IR IN/OUT)...

  • Page 3: Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 4: Precautions

    Precautions This unit contains a semiconductor laser system and is classified as a “CLASS 1 LASER PRODUCT”. So, to use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.
  • Page 5 Regional restriction codes are built into DVD Players and DVD- Video media for each sales region. If the regional code of the DVD Player does not match one of the regional codes on the DVD-Video, playback is not possible. The regional number can be found on the rear panel of the DVD Player.

  • Page 6: Notes On Discs

    You can enjoy two playback variations depending on the type of disc. • VIDEO CD not equipped with PBC function (Version 1.1) Sound and movies can be played on this DVD Player in the same way as an audio CD.

  • Page 7: Handling Discs

    MP3 compatibility information • The CD-ROM must be ISO 9660 compatible. • Files should be MPEG1 Audio Layer 3 format, 44.1 or 48kHz, fixed bit-rate. Incompatible files will not play and “UNPLAYABLE MP3 FORMAT” will be displayed. • Not compatible with variable bit-rate (VBR) files. •...

  • Page 8: Features/Supplied Accessories

    Remote controller (RC-451DV) [1] Batteries (size AA/UM-3) [2] z cable [1] Cable used for system connections to an Integra/ Onkyo component with an z jack. (The components will not function as a system with only z connections. Be sure to connect the audio connection cables correctly as well.)

  • Page 9: Preparing The Remote Controller

    Preparing the Remote Controller Inserting the Batteries 1 Open the battery compartment cover. 2 Insert the two R6 (size AA) batteries. Be sure to match the + and – ends of the batteries with the diagram inside the battery compartment. 3 Close the battery compartment cover.

  • Page 10: Index To Parts And Controls

    2 Standby/On button [16, 17, 21, 24, 41, 59] When Standby/On button is pressed to On while the Power switch is set to On, the DPS-7.3 turns on and the Standby indicator turns off. The indicator around Open/Close button lights up.

  • Page 11: Rear Panel

    S VIDEO 1 IR IN If the DPS-7.3 is located inside a rack or cabinet that will not allow infrared beams to reach the IR sensor, you will need to connect a remote sensor to IR IN input to be able to use the remote controller.
  • Page 12 Index to Parts and Controls Remote controller OPEN /CLOSE ON / STANDBY STANDBY ANGLE AUDIO SUBTITLE LAST M COND. M DIMMER DISPLAY TOP MENU MENU CH - CH + VOL + ENTER VOL - RETURN SETUP TV/ VCR PAUSE STOP PLAY DOWN STEP/ SLOW...

  • Page 13: Connecting

    Before connecting • Refer also to the instruction manual of the TV. • When you connect the DVD Player to the TV, be sure to turn off the power and unplug both units from the mains before making any connections.

  • Page 14: Using The Supplied Audio/Video Connection Cable

    Note Be sure to match the colors of the plugs on the cable with the corresponding jacks on the DVD Player and the TV: yellow for video, red for R (right) audio and white for L (left) audio. : Signal flow...

  • Page 15: Connecting To An Amplifier (To Enjoy The Sound Advantage Of The Dvd Player)

    Connecting to an Amplifier (To Enjoy the Sound Advantage of the DVD Player) Although you can reproduce the DVD Player’s sound from the TV speakers with the connections on pages 13 and 14, connecting with an amplifier provides you high quality dynamic sounds.

  • Page 16: Connecting The Power/Turning On The Dvd Player

    Connecting the Power/Turning on the DVD Player Before connecting • The DPS-7.3 is shipped with the main power (Power) switch in the on position (_ On). When the power cord is plugged in for the first time, the DPS-7.3 will automatically enter the standby state and the Standby indicator will light (same condition after step 2 below).

  • Page 17: Setting Up The Player

    Setting Up the Player The Setup Navigator has been designed to simplify the process of getting the DVD player ready to perform. Designed as a series of on-screen multiple-choice questions, the Setup Navigator automatically sets the audio, video, and language settings according to how the questions are answered.

  • Page 18: Setting The Osd Language

    Setting Up the Player Using the Setup Navigator I Setting the OSD Language (On-Screen Display Language) The [OSD Language] screen establishes the OSD language, or on-screen display language, which refers to the language that is used by the player in menus and on-screen messages.
  • Page 19 I Setting digital audio connections to an AV amplifier or decoder The [Digital Jack] screen establishes whether digital connections have been made to an AV amplifier, receiver, or external decoder. As there are numerous options available, please refer to the instructions supplied with the component the player is connected to determine what digital audio formats can be decoded.

  • Page 20: Various Sound Formats And Sound Effects

    Setting Up the Player Various sound formats and sound effects Minimum speaker configuration for DTS/Dolby Digital/MPEG2 surround sounds Left front speaker Center Speaker Left surround speaker The 5.1-channel digital surround format of DOLBY DIGITAL/ DTS/MPEG2 enables you to individually play five full-range (20 Hz-20 kHz) channels (left and right front, center, two surround channels) plus an LFE (Low Frequency Effect) channel for the low-range effect sound.

  • Page 21: Basic Playback

    • Do not move the DVD Player during playback. Doing so may damage the disc. • Use 0 on the remote controller or DVD Player to open and close the disc tray. Do not touch the disc tray while it is moving. Doing so may cause the DVD Player to malfunction.

  • Page 22: When A Menu Screen Is Displayed

    Getting Started Using Your DVD Player When a Menu Screen is Displayed Menu screens are displayed for DVDs that have menu screens or Video CDs that include Playback Control (PBC). DVDs often contain extra information that can be accessed in the DVD menu and sometimes makes navigating DVD menu screens as enjoyable as watching the feature presentation.

  • Page 23: Forward And Reverse Scanning

    Chapter (Track) Skip Forward/Skip Back Advancing to the next chapter (track) Press ¢. Press to skip forward to the next chapter (track). Skipping back to the previous chapter (track) DOWN Press 4. • Press once to skip back to the start of the chapter (track) currently playing.

  • Page 24: Resuming Playback From Where You Stopped

    Getting Started Using Your DVD Player DVD-V Resuming playback from where you stopped Use the resume feature to restart playback from the point that the disc was stopped last time. This features cannot be used with DVD Audio discs, MP3s and CDs.

  • Page 25: Advanced Still Frame/Slow Play

    Advanced Playback Still Frame/Slow Play The video images on DVD and Video CD can be viewed as a still frame, played back at slow speeds and even advanced frame by frame. Viewing a still frame PAUSE Press 8, STEP/SLOW +/–. When viewing a DVD, if the paused picture shakes, select the [Field] setting in the Setup screen Video 2 menu [Still Picture]...

  • Page 26: Features Locating A Specific Title/Folder/Chapter/Track/Location

    Locating a Specific Title/Group/Folder/ Chapter/Track/Location Searching for a Title, Group, Folder, Chapter, Track, or Location on a Disc This player offers different ways of accessing the information on a DVD, Video CD, CD or MP3. Using SEARCH, you can search for titles or chapters on a DVD-Video, groups or tracks on a DVD-Audio, tracks on a Video CD, CD or folders or tracks on a MP3 and even select the point in time to start playback.

  • Page 27: Using The Mp3 Navigator

    Using the MP3 Navigator Use the MP3 Navigator to make searching for the track(s) you want to play easier. You can also use it to add or clear tracks from the program list. Load a CD-ROM containing MP3 tracks. MENU Press MENU to enter the MP3 Navigator screen.

  • Page 28: Repeat Play

    Repeat Play You can repeat an entire title, group, folder, chapter or track, or just a part. Repeating a Title, Group, Folder, Chapter or Track Repeat play of a chapter/track REPEAT Press REPEAT once during playback of the chapter or track you want to repeat.

  • Page 29: Random Play

    Random Play Play titles, groups, chapters, or tracks on a disc in random order. Playing in Random Order Random playback of chapters within RANDOM one title or tracks within one group Press RANDOM once. “Random Chapter” appears on the screen, and chapters within the title will be played back in random order.

  • Page 30: Playing In A Favorite Order

    Playing in a Favorite Order You can combine your favorite titles, groups, folders, chapters or tracks and play them in any order. Programming DVDs A program with a maximum of 24 steps can be memorized. PROGRAM Press PROGRAM. The Program screen appears. Program Chapter Program Title Current:...

  • Page 31: Programming Mp3S

    Programming MP3s A program with a maximum of 24 steps can be memorized. Press PROGRAM to enter the [MP3 PROGRAM Program] screen. If you added tracks to the program list from the ‘Using the MP3 navigator’ on page 27, the tracks are displayed here. Total number of folder and track Folder name MP3 Program...
  • Page 32 Playing in a Favorite Order Programming Video CDs, CDs A program with a maximum of 24 steps can be memorized. Press PROGRAM. PROGRAM The program screen appears. When a Video CD or CD is loaded, the cursor appears in the program window. Program Track Track 1(/10)
  • Page 33 I To add a title/group/chapter/track to a program Press and hold PROGRAM for about 2 seconds. The current title/group/chapter/track number appears on-screen together with the program step number. If there isn’t already a program then a new one will be created. 07 3 Program 03 Chapter I To confirm the contents of a program:...

  • Page 34: Selecting The Camera Angle

    Selecting the Camera Angle You can select a camera angle when viewing DVDs with the multi-angle option. DVD-V Viewing from a Desired Camera Angle (Multi-Angle) Press ANGLE during playback. ANGLE The camera angle changes each time you press the button. Angle : 1/4 »...

  • Page 35: Selecting The Audio/Subtitle Language

    Selecting the Audio/ Subtitle Language DVD-V Changing the Audio Language (Multi-Language Function) Dolby Digital, PCM, and other audio data can be recorded on DVDs in a number of languages or audio tracks, letting you choose the desired language or audio. Press AUDIO repeatedly to select AUDIO the desired language.

  • Page 36: Continuing Playback From A Specified Location (Last Memory)

    Continuing Playback from a Specified Location (Last Memory) The Last Memory function is convenient when you want to continue viewing a disc from the point where you were watching before. Unlike the resume function, the Last Memory function is effective even if the DVD is removed from the player (Last Memory locations saved for Video CDs are effective only if the disc remains loaded in the player).

  • Page 37: Memorizing Settings For Often Viewed Dvds (Condition Memory)

    Memorizing Settings for Often Viewed DVDs (Condition Memory) You can store in memory settings for DVDs you often watch. Settings remain in memory even if you remove the disc from the player, or switch power to the player to standby. If you load a disc that has its settings memorized, “COND.”...

  • Page 38: Turning Off The Video Signal Output

    Turning Off the Video Signal Output The DVD Player can be set playing audio exclusively. In this case, you can obtain sound of better quality, as the DVD Player does not process video signals. (All the video output jacks send no video signals.)

  • Page 39: Viewing Disc Information

    Viewing Disc Information Use DISPLAY to get current information about the disc currently loaded. You can get information about the titles and chapters on a DVD-Video, groups and tracks on a DVD-Audio or tracks on a Video CD or CD or folders and tracks on a MP3.
  • Page 40 Viewing Disc Information I Using DIMMER function Press DIMMER to change the display brightness. Each time DIMMER is pressed, the display brightness of the unit changes as shown below. Normal → Dim → Very Dim → Off → Normal (When the display is off, operating the player or remote controller turns on the display for about 3 seconds.) Viewing Disc Information during while a disc is playing...

  • Page 41: Adjusting Audio And Video Settings

    The Setup screen closes. Notes • If you turn off the DVD player during setup, the settings are canceled. Press SETUP to finish the setup. • The memorized resume position may be erased by setup. • The Setup screen always shows the latest settings.

  • Page 42: Changing To The Setup Screen "Expert" Menu Mode

    Adjusting Audio and Video Settings Using the Setup Screen Menus I When setting up for the first time It is recommended to set up player using the Setup Navigator (page 17). If you selected [Auto Start Off] when the Setup Navigator appeared, you may still set up the player using the Setup Navigator in the General menu screen.

  • Page 43: Changing To The Setup Screen "Expert" Menu Mode 42 Setting The Audio 1 Options

    Setting the Audio 1 Options I Audio DRC Audio DRC stands for Audio Dynamic Range Compression. When Audio DRC is on, soft sounds such as dialog can be heard more clearly without making loud sounds even louder. When Audio DRC is set to [Off], there is no effect on the audio source.

  • Page 44: Dts Out

    Adjusting Audio and Video Settings Setting the Audio 1 Options I DTS Out This player is capable of outputting DTS digital audio for DVDs recorded in DTS. When this player is connected to an AV component that has a built-in DTS decoder, select [DTS]. If your system is not equipped to decode DTS, select [DTS 3 PCM].

  • Page 45: Setting The Audio 2 Options

    Setting the Audio 2 Options I Audio Out If you connected this player to your amplifier using the 5.1 channel analog outputs (front, surround, center and subwoofer outs), set this to [5.1 Channel]; if you connected only the stereo outs, set to [2 Channel]. Language General Audio2 Video1...
  • Page 46 Adjusting Audio and Video Settings Setting the Audio 2 Options I Gain Settings Expert You may want to make this setting if you connected this player to your amplifier using the 5.1 channel analog outputs. Under the default setting, all channels are output at the relative volumes they were recorded at.

  • Page 47: Setting The Video 1 Options

    Setting the Video 1 Options I Setting the TV Screen Size The width-to-height ratio of conventional TVs is 4:3, while the width-to-height ratio of wide screen and high-definition TVs is 16:9. This width-to-height ratio is called the aspect ratio. When viewing software recorded in different aspect ratios, the image’s height to width ratio can be switched to match the TV or monitor being used.

  • Page 48: Setting The Component Video Output

    Adjusting Audio and Video Settings Setting the Video 1 Options I Setting the Component Video Output Compared to a standard interlaced TV picture, a progressive scan TV is capable of stable, flicker-free images. Set only if you connected the COMPONENT VIDEO OUT jacks to a progressive scan-compatible TV or monitor.

  • Page 49: Adjusting The Video Quality

    Adjusting the Video Quality You can either select a preprogrammed setting designed to match certain program types or make adjustments to match your own preferences and save them in the player’s memory. Make changes to the [Video Adjust] setting in the Setup screen Video 2 menu.
  • Page 50 Adjusting Audio and Video Settings Adjusting the Video Quality You can adjust any or all of the following picture quality factors: Prog. Motion When using progressive scan, this adjusts the motion and still picture quality. PureCinema When watching DVD movies, PureCinema optimizes the picture quality.

  • Page 51: Setting The Video 2 Options

    Setting the Video 2 Options I Changing the Background of the Screen You can select a background to appear when the player is in the stop mode. Make changes to the [Background] setting in the Setup screen Video 2 menu. Language General Audio1 Video2...

  • Page 52: Setting The Language Options

    Adjusting Audio and Video Settings Setting the Language Options DVDs have the capacity to contain a great deal of audio information, which includes the ability to hold up to 8 different language tracks and subtitle information in as many as 32 different languages.
  • Page 53 I Selecting a subtitle language preference The subtitle language that you will normally display can be selected from the subtitles programmed on a disc. Even when the subtitle language is changed during playback by pressing SUBTITLE, the language selected at this setting will be selected when the disc is changed.
  • Page 54 Adjusting Audio and Video Settings Setting the Language Options I Selecting subtitles, assist subtitles or no Expert subtitles Use this function to turn the subtitles on or off. Additionally, some DVDs provide assist subtitles that provide additional explanations of scenes in addition to the standard subtitles for viewers who are hard of hearing.

  • Page 55: Language Code List

    Language Code List Language codes are used when setting the audio and subtitle language preferences (page 52, 53). Language Input-code Japanese (ja) 1001 English (en) 0514 French (fr) 0618 German (de) 0405 Italian (it) 0920 Spanish (es) 0519 Chinese (zh) 2608 Dutch (nl) 1412...

  • Page 56: Setting The Parental Lock Level

    Adjusting Audio and Video Settings Setting the Parental Lock Level This player lets you set the Parental Lock if the DVD has a parental lock level recorded on it. With Parental Lock capable discs, you can block access to material you feel is inappropriate for your children.

  • Page 57: Setting The Country Code

    I Setting the Parental Lock Level Change the Parental Lock level to a higher or lower level according to the settings printed on the DVD disc jacket or accompanying documentation. If you use the Condition Memory function to save the settings for a particular disc, the Parental Lock level is saved as well.

  • Page 58: Country Code List

    Adjusting Audio and Video Settings Country Code List Country Input-code ARGENTINA 0118 0121 AUSTRALIA 0120 AUSTRIA BELGIUM 0205 0218 BRAZIL 0301 CANADA CHILE 0312 0314 CHINA 0411 DENMARK FINLAND 0609 0618 FRANCE 0405 GERMANY HONG KONG 0811 0914 INDIA 0904 INDONESIA ITALY 0920...

  • Page 59: Memorizing Settings (Function Memory)

    Memorizing Settings (Function Memory) Up to 5 settings can be memorized. SETUP Press SETUP. The Setup screen appears. Use the cursor buttons (2/3) to select the menu you want. Use the cursor buttons (5/∞) to select the setting to be memorized. As each menu is selected with the cursor, the settings appear below the menu heading.

  • Page 60: Others

    Pre-programming remote controller Learning a Pre-programming Code You can make RC-451DV remote controller to operate a TV from other brand than Integra/ONKYO by storing the pre- programming code of the brand in the RC-451DV. Set the DVD/TV switch to TV.

  • Page 61: Operating Components Not Reached By The Remote Controller Signals (Ir In/Out)

    In this situation, you will need to use a commercially available IR emitter. Connect the mini plug of the IR emitter to the IR OUT terminal on the DPS-7.3 and then place the IR emitter on the remote sensor of the component or facing it.

  • Page 62: Troubleshooting

    • Switch off the main power, then switch it on again. If not recovered, disconnect the mains lead, then connect it again. • Contact your nearest Integra/ONKYO service center. • Use the disc tray guide to align the disc. • Refer to ‘Notes on Discs’.
  • Page 63 • The batteries are worn out. controller do not operate. • The remote controller is not pointed at the remote sensor of the DVD Player. • The remote controller is too far from the DVD Player. Because the unit contains a microcomputer to provide advanced functions, it may malfunction due to external noise or static electricity.
  • Page 64 Audio output (5.1 channel analog audio) 2.0 V (rms), 440 Ω, pin jack (FRONT L, FRONT R, CENTER, SURR L, Specifications and features are subject to change without notice. Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A.
