The Belt Clip Accessory
Kit Contents:
Clip Knob:
Attaches to the
back of the
NavTalk Unit.
Belt Clip:
Clip Knob
Press this tab
to release the
Clip Knob.
Plug
Attaches to the
belt or waistband.
Slot accepts the
Clip Knob and
locks it into place.
Installing the Clip Knob:
1. Remove the plug from the
back of the NavTalk unit.
2. Insert the threaded post
into the hole in the back
of the unit and turn the
knob clockwise until snug.
NavTalk GSM
Section 6
Section 4
Appendix A
Using the Belt Clip:
1. Squeeze the Belt Clip
to open the clip and
insert over a belt or
waistband.
2. Slide the Clip Knob into
the slot on the Belt Clip
until it "clicks" into place.
3. Press Down on the
Release Tab to remove
the NavTalk from the
Belt Clip.
Release Tab
Press Clip to open.
Clip Knob Slot
101
