PITTBULL FORTY- FIVE 1X12 COMBO MODEL C-5084-T

SUPER THIRTY COMBO MODEL C-3084-S

REVISED 05/09/05

FRONT PANEL FUNCTIONS, LEFT TO RIGHT

1. INPUT HIGH- High sensitivity input (also has a brighter tone)

2. INPUT LOW- Low sensitivity input (also has a slightly darker tone)

3. GAIN- Amount of overdrive. Initial set-up: 2 O'clock

4. DRIVE- Toggles between Drive and Clean channel

5. VOLUME- Pre FX loop. Initial set-up: 10 O'clock

6. BOOST- Switches from low gain (clean to slightly dirty) to medium gain (crunch to medium

overdrive)

7. TREBLE- Initial set-up: 2 O'clock

8. EDGE- Frequency dependent gain boost; gain increases as you play up the neck.

9. MIDDLE- Initial set-up: 10 O'clock

10. SHIFT- Shifts Treble, Middle, and Bass shelving down

11. BASS- Initial set-up: 12 O'clock

12. VOLUME- Gain and volume for Clean channel, pre FX loop. Initial set-up: 9 O'clock

13. BOOST- Gain boost for Clean channel

14. TREBLE- Initial set-up: 2 O'clock

15. BRIGHT- High frequency boost ( becomes less active as Volume increases)

16. MIDDLE- Initial set-up: 10 O'clock

17. SHIFT- Low midrange boost between Middle and Bass frequencies

18. BASS- Initial set-up: 12 O'clock

19. STANDBY- 1=operate , 0= standby

20. MAINS- Lovely emerald green, don't you think?

Need help?

Do you have a question about the C-5084-T and is the answer not in the manual?

Page 1 PITTBULL FORTY- FIVE 1X12 COMBO MODEL C-5084-T SUPER THIRTY COMBO MODEL C-3084-S REVISED 05/09/05 FRONT PANEL FUNCTIONS, LEFT TO RIGHT 1. INPUT HIGH- High sensitivity input (also has a brighter tone) 2. INPUT LOW- Low sensitivity input (also has a slightly darker tone) 3.
Page 2 PITTBULL FORTY- FIVE 1X12 COMBO MODEL C-5084-T SUPER THIRTY COMBO MODEL C-3084-S REVISED 05/09/05 FRONT PANEL FUNCTIONS, RIGHT TO LEFT 1. REVERB- Initial set-up: 8 O’clock 2. EFFECTS MIX/LEVEL- Initial set-up: 5 O’clock (not provided on earlier models). 3. EFFECTS SEND- Send level set by preamp volumes 4.
Page 3 TUBE FUNCTION AND LOCATION CHART Each 12AX7 has two sections/functions. Section A is shown first, Section B is second. Factory recommended tubes are listed under each location. Numbering sequence is right to left looking at back of amp starting with the row closest to front panel of amp. V1 (shielded tube) Reverb return amplifier.
Page 4: Limited Warranty
LIMITED WARRANTY Subject to the obligations and exclusions found below, this product is warranted by Steven Fryette Design, Inc., (herein SFD) against manufacturing defects in materials and workmanship for the period of Five (5) Years from the date of purchase, with the exception of the tubes, fuses and speakers where applicable, which carry a 90 day warranty.
