Personal active speaker system

Advertisement

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PM0.5d and is the answer not in the manual?

Questions and answers

Summary of Contents for Fostex PM0.5d

  • Page 1: Table Of Contents

    PM0.5d - Owner's Manual - WARNINGS and PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS FCC (U.S.A.) & ICES-003 (Canada) INFORMATION Introduction Unpacking Setup Instructions Back Panel Overview Product Specifications Product Cleaning Instructions Cable and Wiring Information Use of Mounting Bracket p-10 Declaration of EC Directive...
  • Page 2: Warnings And Precautions

    WARNINGS and PRECAUTIONS • CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH • CAUTION: Danger of explosion if battery is incorrectly WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. replaced. Replace only with the same or equivalent ATTENTION: POUR PREVENIR LES CHOCS ELEC- type.
  • Page 3: Important Safety Instructions

    The lightning flash with arrowhead symbol, The exclamation point within an equilat- within an equilateral triangle, is intended to eral triangle is intended to alert the user to alert the user to the presence of non-insulat- the presence of important operating and ed “dangerous voltage”...
  • Page 4: Fcc (U.s.a.) & Ices-003 (Canada) Information

    FCC and ICES-003 requirements. Changes or modifications not on, the user is encouraged to correct the interference by expressly approved by Fostex Company for compliance one or more of the following measures: could void the user’s authority to operate the equipment.
  • Page 5: Introduction

    Please take the time to thoroughly read this manual so that you may take full advantage of all the benefits of the Fostex PM0.5d Personal Active Speaker System. Unpacking Prior to unpacking your Fostex PM0.5d Personal Active Speaker System, carefully inspect the pack- ing material for excessive damage.
  • Page 6: Setup Instructions

    Once the speakers have been placed in their final location, it is time to proceed to connecting your PM0.5d to the mixing console or digital workstation. Connection to the PM0.5d can be made using the XLR balanced connector, TS phone or RCA pin unbalanced jacks. The connection of PM0.5d to the console/digital workstation should be done in the following order.
  • Page 7: Back Panel Overview

    Connects the supplied AC cord. • Auto Stand-by Mode When no input signal continues for about 13 minutes or so, the PM0.5d will go into the stand-by mode automatically and reduce the power consumption. This is indicated by the red lighting power LED.
  • Page 8: Product Specifications

    3/4” soft dome tweeter Low frequency driver 5” woofer Dimensions 270 (H) x 165 (W) x 214.5 (D) mm 10.6” (H) x 6.5” (W) x 8.5” (D) INPUT VOLUME PM0.5d Personal Active Speaker System CAUTION ATTENTION RISK OF ELECTRIC SHOCK RISQUE Dʼ ÉLECTROCUTION NES PAS OUVRIR DO NOT OPEN WARNING : ...
  • Page 9: Product Cleaning Instructions

    0.5 W or less Product Cleaning Instruction Prior to the cleaning the PM0.5d Personal Active Speaker System, the power must be turned off and the AC cord is disconnected from the AC IN connector. Once the power has been terminated, clean- ing can be accomplished using a dry cleaning rag.
  • Page 10: Use Of Mounting Bracket

    Use of Mounting Bracket Usage de Monter le Support <CAUTION> The PM0.5d has 4 implanted nuts on the bottom that can be When attaching a mounting bracket and installing the used to install with a wall mounting bracket. Fix the bracket PM0.5d into a wall, etc., we highly recommend that...
  • Page 11: Declaration Of Ec Directive

    In the electrical fast transient/burst requirements, surge, conducted disturbances by radio-frequency fields, power frequency magnetic field, radiate electromagnetic field requirements and static electricity discharging environment, this could be affected by generation of noise in some cases. FOSTEX DISTRIBUTORS LIST IN EUROPE * Including non-EU countries (as of May 2013) <AUSTRIA>...
