Page 1: Table Of Contents
PM0.4d - Owner's Manual - WARNINGS and PRECAUTIONS IMPORTANT SAFETY INSTRUCTIONS FCC (U.S.A.) & ICES-003 (Canada) INFORMATION Introduction Unpacking Setup Instructions Back Panel Overview Product Specifications Product Cleaning Instructions Cable and Wiring Information Use of Mounting Bracket p-10 Declaration of EC Directive... -
Page 2: Warnings And Precautions
WARNINGS and PRECAUTIONS • CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH • CAUTION: Danger of explosion if battery is incorrectly WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT. replaced. Replace only with the same or equivalent ATTENTION: POUR PREVENIR LES CHOCS ELEC- type. -
Page 3: Important Safety Instructions
The lightning flash with arrowhead symbol, The exclamation point within an equilat- within an equilateral triangle, is intended to eral triangle is intended to alert the user to alert the user to the presence of non-insulat- the presence of important operating and ed “dangerous voltage”... -
Page 4: Fcc (U.s.a.) & Ices-003 (Canada) Information
FCC and ICES-003 requirements. Changes or modifications not on, the user is encouraged to correct the interference by expressly approved by Fostex Company for compliance one or more of the following measures: could void the user’s authority to operate the equipment. -
Page 5: Introduction
Fostex PM0.4d Personal Active Speaker System. Unpacking Prior to unpacking your Fostex PM0.4d Personal Active Speaker System, carefully inspect the pack- ing material for excessive damage. Once it has been determined that the packing material has not been compromised, carefully unpack the PM0.4d and inspect it carefully for obvious damage. Fostex takes great care in designing packing materials that will survive most expected impacts during ship- ping and transportation. -
Page 6: Setup Instructions
Once the speakers have been placed in their final location, it is time to proceed to connecting your PM0.4d to the mixing console or digital work- station. Connection to the PM0.4d can be made using the TS phone or RCA pin jacks. The connec-... -
Page 7: Back Panel Overview
Step 6: Adjust the gain of both monitors for balance and for best signal to noise ratio. Once the above steps have been completed, you are ready to use your PM0.4d. It is recommended that you now play some familiar audio material and make any final adjustments, as far as placement or level, to get the optimum performance in your monitoring environment. -
Page 8: Product Specifications
Product Specifications Drivers High Frequency Driver 3/4" soft dome tweeter Low Frequency Driver 4" woofer Dimensions 220 (H) x 130 (W) x 169 (D) mm 8.8” (H) x 5.2” (W) x 6.8” (D) Weight 2.8 kg (/pc. net), 7.1 kg (/pair, gross) 6.2 lbs (/pc, net), 15.6 lbs (/pair, gross) Frequency Response 60 ~ 30 kHz... -
Page 9: Product Cleaning Instructions
Product Cleaning Instruction Prior to the cleaning the PM0.4d Personal Active Speaker System, the power must be turned off and the AC cord is disconnected from the AC IN connector. Once the power has been terminated, clean- ing can be accomplished using a dry cleaning rag. A light common household cleaner can also be used, but care must be taken not to use harsh cleaning fluids. -
Page 10: Use Of Mounting Bracket
Use of Mounting Bracket Usage de Monter le Support <CAUTION> The PM0.4d has 4 implanted nuts on the bottom that can be When attaching a mounting bracket and installing the used to install with a wall mounting bracket. Fix the bracket PM0.4d into a wall, etc., we highly recommend that... -
Page 11: Declaration Of Ec Directive
In the electrical fast transient/burst requirements, surge, conducted disturbances by radio-frequency fields, power frequency magnetic field, radiate electromagnetic field requirements and static electricity discharging environment, this could be affected by generation of noise in some cases. FOSTEX DISTRIBUTORS LIST IN EUROPE * Including non-EU countries (as of November 2011) <AUSTRIA>... - Page 12 FOSTEX CO. 1-1-109, Tsutsujigaoka, Akishima city, Tokyo, 196-8550, Japan 568128 © PRINTED IN CHINA January 2013 8588120000...
