VOLVO C70 QUICK GUIDE WEB EDITION WELCOME TO YOUR NEW VOLVO! Getting to know your new car is an exciting experience. Look through this Quick Guide in order to quickly and easily learn some of the most common functions. All warning texts, and other important and detailed information, are only available in the owner's manual –...
ADJUSTING THE FRONT SEAT ENTRY TO THE REAR SEAT MANUAL SEAT Move the seat forward Loosen the belt from the belt guide (A). Lift the handle (B) and fold the backrest forward to the locked position. Push the seat forward (C). Move the seat backward Push the seat back to the desired position (D).
Page 3
REMOTE CONTROL KEY Locks doors and boot lid and arms the alarm*. After 30 seconds, the doors are double-locked and cannot be opened from the inside. Unlocks the doors and boot lid, and disarms the alarm. Unlocks the boot lid – it does not open. Approach lighting.
LIGHT SWITCHES Manual headlamp levelling (automatic for Xenon lights*). Automatic dipped beam. Main beam flash works but not the fixed main beam. Parking lamps Dipped beam. Switches off when the engine is switched off. Main beam can be activated. Active Bi-Xenon lights*, the headlamp pattern follows the movement of the steering wheel.
AUDIO SYSTEM RADIO Turn to select the station. Searches for the next strong station. Search for station using Left/Right arrow. Store up to 20 stations by holding in 0–9 on FM1 or FM2 at the desired station until the display confirms the selection. Press for about 2 seconds to autostore the 10 strongest stations.
ELECTRONIC CLIMATE CONTROL – ECC* AUTOMATIC CONTROL MANUAL CONTROL In AUTO mode the ECC system controls all Turn to change the fan speed. functions automatically making driving simpler Max. defroster. Aim all air to the wind- with optimum air quality. screen and side windows with maximum airflow.
Page 7
TRIP COMPUTER AND TRIP METERS Low fuel level. When the symbol is illumi- nated, fill up with fuel as soon as possible. Fuel gauge. The symbol's arrow points out the side on which the fuel cap is located. Display for trip computer, messages, clock and outside temperature.
OPERATION, ROOF OPERATION PREPARATIONS No objects on parcel shelf, roof or boot lid. The car must be stationary. 2 m clearance and 0.2 m behind. The engine must be running at idling speed. Level ground. Depress the brake pedal. Outside temperature above -10 ˚C. Press and hold button (A) or (B) until a Closed cargo separator and boot lid.
